PROPANE GAS HEATER
MODEL NO: DEVIL 3000
PART NO: 6920027
OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
DL0425 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEVIL 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke DEVIL 3000

  • Page 1 PROPANE GAS HEATER MODEL NO: DEVIL 3000 PART NO: 6920027 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0425 Rev 2...
  • Page 2: Environmental Recycling Policy

    INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase.
  • Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 Contact Details: Clarke International Ltd, Hemnall St, Epping, Essex, CM16 4LG Tel: 0208 988 7400 DEVIL 3000 Model Number Indirect Heating Functionality Direct Heat Output 73kW Indirect Heat Output Minimum permissible total flue length (vertical + horizontal)
  • Page 4: Function And Operating Parameters

    Type of heat output/room temperature control (select one) Single stage heat output, no temperature control Two or more manual stages, no temperature control With mechanical thermostat temp control With electronic temperature control Electronic temperature control with day timer Electronic temperature control with week timer Other control options (multiple selections possible) Room temperature control with presence detection Room temperature control with open window detection...
  • Page 5: Safety Information

    SAFETY INFORMATION Read, and make sure you fully understand the following precautions and the hazards associated with this type of equipment. 1. ONLY use with the voltage specified and ensure the heater is properly earthed. 2. Use only the hose and factory preset regulator provided with the heater. 3.
  • Page 6: Safety Symbols

    23. To prevent injury wear gloves when handling the heater. 24. NEVER attach duct work to front or rear of the heater. 25. DO NOT alter the heater. Keep the heater in its original state. 26. Turn off the propane supply and unplug the heater when not in use. 27.
  • Page 7: General Precautions

    GENERAL PRECAUTIONS Even though this heater operates very close to 100 percent combustion efficiency, it still produces small amounts of carbon monoxide. • Carbon Monoxide (CO) is toxic. • Pregnant women, persons with a heart or lung condition, anaemia or under the influence of alcohol, or those at high altitude, are more likely to be effected by Carbon Monoxide.
  • Page 8: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved BS1363 plug fitted with a BS1362 13 amp fuse. If the plug has to be changed because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below.
  • Page 9: Propane Gas Supply

    PROPANE GAS SUPPLY WARNING: THE FITTING AND CHANGING OF THE GAS CYLINDERS MUST BE CARRIED OUT IN A FLAME FREE ATMOSPHERE. WARNING: YOU SHOULD ONLY USE PROPANE GAS CYLINDERS AVAILABLE FROM BUILDERS MERCHANTS OR GAS SUPPLIERS. This portable, direct-fired gas heater is designed to give safe, efficient and reliable operation, and is for use with propane gas only.
  • Page 10: Size And Capacity Of Propane Cylinders

    PREPARATION ASSEMBLY 1. Check the heater for possible shipping damage. If any is found do not use the heater. 2. Stand the heater on end as shown, on a soft surface to avoid scratches. We recommend the help of an assistant to lift and steady the heater during assembly.
  • Page 11 CONNECTING THE GAS BOTTLE 1. Follow all of the “General Safety” precautions on pages 3/4. 2. Connect a POL (Prest-o-Lite) fitting on hose/regulator assembly to the propane bottle(s). • Turn the POL fitting anti-clockwise into the threads on the bottle Tighten firmly using a wrench.
  • Page 12: Heater Start Up

    OPERATING INSTRUCTIONS WARNING: BEFORE STARTING THE HEATER, YOU MUST ENSURE THAT THE MINIMUM VENTILATION REQUIREMENTS ARE OBSERVED TO AVOID THE RISK OF CARBON MONOXIDE POISONING. HEATER START UP 1. Make sure the power switch is in the OFF (O) position. 2.
  • Page 13: Maintenance, Storage And Servicing

    MAINTENANCE, STORAGE AND SERVICING WARNING: TO PREVENT PERSONAL INJURY, UNPLUG THE HEATER FROM THE MAINS SUPPLY BEFORE SERVICING. MAINTENANCE AND STORAGE The heater should be inspected at least annually by a qualified person. 2. Before each use, check the soft “0” ring seat at the bullnose of the POL fitting. If the “0”...
  • Page 14: Specifications

    SPECIFICATIONS Gas Type Propane Regulator H30-1.5 Hose Length 3.6m Rated Heat Output 50-82kW(170,000-279,700 BTU/HR) Maximum Pressure Bottle Pressure Minimum Pressure 1.5 Bar Regulator Output 1.5 Bar Operating Voltage/Frequency 220-240V/50Hz Output Rated Input Power 170W Rated Input Current 0.75A RPM@230V, No Load 2600 Electrical Insulation Class Duty Cycle...
  • Page 15: Wiring Diagram

    WIRING DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 16: Component Parts

    COMPONENT PARTS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 17: Parts List

    PARTS LIST Handle Extension fitting Handle mounting clips Inlet connector Outer shell Solenoid valve assembly Middle cylinder Solenoid valve knob Front guard Control box front panel Burner outer plate Control box left panel Burner grid Thermostat knob Burner mixing tube Thermostat mounting bracket High limit switch Thermostat assembly...
  • Page 18 DECLARATIONS OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 19 DECLARATIONS OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
