Page 1: User Instructions
GAS HEATERS MODEL NOS: DEVIL 700, 900/910SS,1600/ 1610SS & 2100 PART NOS: 6920182, 6920186, 6920188, 6920190, 6920192, &6920194 USER INSTRUCTIONS GC0816... -
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Gas Powered Heater. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Information
SAFETY INFORMATION WARNING: LACK OF VENTILATION CAN CAUSE CARBON MONOXIDE POISONING. WARNING: CARBON MONOXIDE POISONING CAN KILL. Signs of Carbon Monoxide poisoning are headaches, dizziness and/or nausea. Should anyone show these signs, they must GET FRESH AIR IMMEDIATELY. Turn off the heater and have it serviced before using again. Pregnant women, persons with a heart or lung condition, anaemia or under the influence of alcohol, or those at high altitude, are more likely to be effected by Carbon Monoxide. -
Page 4: Safety Symbols
• Never move, handle, replenish the gas supply or service the heater when it is hot, operating or plugged in. • Never attach the heater to any duct work, or impede air flow into or out of the heater. • Disconnect the heater from the power supply when not in use. •... -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 6: Propane Gas Supply
UNPACKING When unpacking, check the heater for possible shipping damage. Should any damage be apparent, please notify your Clarke dealer immediately. Your heater is fully assembled,- only the electrical and gas supplies need connecting. Retain any plastic cover caps (attached to the inlet connector and hose/regulator assembly) for future storage. -
Page 7: Changing Gas Bottles
In order to reduce the risk of icing up when operating at long periods at maximum capacity, you should use a larger capacity gas bottle, or two/ three bottles in parallel, as shown in Fig 2. • The ‘Tee’ piece and ‘pigtails’ are readily available from your builders merchants or gas supplier. -
Page 8: Principle Of Operation
PRINCIPLE OF OPERATION Understanding the basic operation of the heater will reinforce the need to maintain the unit in top condition at all times, whilst always observing the safety precautions. The heater comprises four basic systems: 1. The gas system. 2. -
Page 9: Ignition System
IGNITION SYSTEM Ignition is automatic with this heater as soon as the gas valve button is depressed, with a continuous spark from the spark plug igniting the gas. As the thermocouple heats up, a low voltage is fed to the Flame Failure valve, causing the valve to open, so that after a few seconds, the gas valve button may be released and the flame is established. -
Page 10: Shutdown Procedure
8. When the burner remains lit, set the heater at the required level by turning the flame intensity control valve counter-clockwise. If the burner goes out, turn off the gas. Turn the gas valve fully clockwise to its lowest position. Check the fuel supply. -
Page 11: Maintenance
Ensure that all connections are clean and secure. When necessary, clean the fan and the inside of the heater thoroughly. The use of parts other than genuine Clarke replacement parts may result in safety hazards or decreased performance, and will invalidate your warranty. -
Page 12: Troubleshooting
Identify cause of over- to overheating. Thermal cut- heating. Wait for 5 mins out in operation. and restart. If condition persists, contact your Clarke dealer for advice. Spark plug does not Gap incorrect, faulty Clean and reset gap if spark. connection necessary or replace. -
Page 13: Specifications
(kW/btu Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the heater’s data plate. - Page 14 PARTS DIAGRAM - DEVIL 700/900/910SS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 15 PARTS LIST DEVIL - 700/900/910SS Description No Description Outer Shell Spark Plug Washer Handle Mounting clips Spark Plug Handle Elbow Fitting Middle Cylinder Fuel Tube Assembly Front Guard Extension Fitting Orifice Assembly Securing Nut Flame Holder Assembly Gas Valve Orifice Nut Male Fitting Connector High Limit Switch Bracket Solenoid Valve Assembly...
-
Page 16: Parts Diagram - Devil 1600
PARTS DIAGRAM - DEVIL 1600 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 17: Parts List - Devil 1600
PARTS LIST - DEVIL 1600 Description No Description Outer Shell Thermocouple Bracket Handle Mounting Clips Thermocouple Handle Elbow Fitting Middle Cylinder Fuel Tube Assembly Front Guard Extension Fitting Orifice Assembly Securing Nut Flame Holder Assembly Gas Valve High Limit Switch Bracket Male Connector Fitting Orifice Nut Solenoid Valve Assembly... -
Page 18: Parts Diagram - Devil 1610Ss
PARTS DIAGRAM - DEVIL 1610SS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 19: Parts List - Devil 1610Ss
PARTS LIST - DEVIL 1610SS Description No Description Outer Shell Thermocouple Bracket Handle Mounting Clips Thermocouple Handle Elbow Fitting Middle Cylinder Fuel Tube Assembly Front Guard Extension Fitting Orifice Assembly Securing Nut Flame Holder Assembly Gas Valve High Limit Switch Bracket Male Fitting Connector Orifice Nut Solenoid Valve Assembly... -
Page 20: Parts Diagram - Devil 2100
PARTS DIAGRAM - DEVIL 2100 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 21: Parts List - Devil 2100
PARTS LIST - DEVIL 2100 Description No Description Outer Shell Thermocouple Bracket Flame Control PCB Thermocouple Flame Control PCB Bracket Orifice Nut Handle Mounting Clips Elbow Fitting Handle Fuel Tube Assembly Middle Cylinder Extension Fitting Front Guard Securing Nut Orifice Assembly Gas Valve Button Spark Plug Nut Male Fitting Connector... -
Page 22: Wiring Diagrams
WIRING DIAGRAMS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 23: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
