GAS HEATERS
MODEL NOS: DEVIL 900DV, 1600DV & 2100DV
PART NOS: 6920175, 6920191& 6920196
USER INSTRUCTIONS
ORIGINAL INSTRUCTIONS
DL1123 - Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEVIL 900DV and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke DEVIL 900DV

  • Page 1 GAS HEATERS MODEL NOS: DEVIL 900DV, 1600DV & 2100DV PART NOS: 6920175, 6920191& 6920196 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1123 - Rev 2...
  • Page 2: Function And Operating Parameters

    INTRODUCTION Thank you for purchasing this CLARKE Gas Powered Heater. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: Safety Information

    SAFETY INFORMATION Read, and make sure you fully understand the following precautions and the hazards associated with this type of equipment. 1. ONLY use with the voltage specified and ensure the heater is properly earthed. 2. Use only the hose and factory preset regulator provided with the heater. 3.
  • Page 4: Safety Symbols

    19. NEVER block the air inlet (rear) or air outlet (front) of the heater. 20. Keep the heater away from strong drafts, water spray, rain or dripping water. 21. DO NOT leave the heater unattended. 22. NEVER move, handle or service a hot, operating or plugged-in heater. 23.
  • Page 5: General Precautions

    GENERAL PRECAUTIONS Even though this heater operates very close to 100 percent combustion efficiency, it still produces small amounts of carbon monoxide. • Carbon Monoxide (CO) is toxic. • Pregnant women, persons with a heart or lung condition, anaemia or under the influence of alcohol, or those at high altitude, are more likely to be effected by Carbon Monoxide.
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug or a suitably fused isolator switch. The heater may also be connected to a 110V supply through a suitably approved plug.
  • Page 7: Gas Connection

    4. Replacement fuse covers can be obtained from your local dealer or most electrical stockists. 5. The fuse in the plug must be replaced with one of the same rating (13 amps) and this replacement must be ASTA approved to BS1362. We strongly recommend that this machine is connected to the mains supply through a Residual Current Device (RCD).
  • Page 8: Changing Gas Bottles

    In order to reduce the risk of icing up when operating at long periods at maximum capacity, you should use a larger capacity gas bottle, or two/ three bottles in parallel, as shown in Fig 2. • The ‘Tee’ piece & ‘pigtails’ are readily available from your builders merchants or gas supplier.
  • Page 9: Principle Of Operation

    UNPACKING When unpacking, check the heater for possible shipping damage. Should any damage be apparent, please notify your Clarke dealer immediately. 5. Your heater is fully assembled,- only the electrical and gas supplies need connecting. Retain any plastic cover caps (attached to the inlet connector and hose/regulator assembly) for future storage.
  • Page 10 Similarly, should there be a power failure, causing the fan motor to stop, the Safety Shut-Off valve solenoid will become de-energised, and therefore shut off the gas supply Additionally, the machine is equipped with thermal overload protection, which will intervene should the unit overheat, shutting off the electrical supply. Parts &...
  • Page 11: Starting Procedure

    STARTING PROCEDURE WARNING: BEFORE STARTING THE HEATER, YOU MUST ENSURE THAT THE MINIMUM VENTILATION REQUIREMENTS ARE OBSERVED TO AVOID THE RISK OF CARBON MONOXIDE POISONING. Ensure there is sufficient gas and that it is correctly connected. 1. Open the supply valve on the gas cylinder, and fully open the regulator valve adjacent to the gas inlet pipe.
  • Page 12: Shutdown Procedure

    Should the flame safety valve operate, the heater may be restarted once the cause of the problem has been found and rectified. SHUT-DOWN PROCEDURE 1. Turn off the gas at the propane cylinder valve(s). 2. Let the heater run while any gas left in the supply hoses is burnt off. 3.
  • Page 13: Maintenance

    Ensure that all connections are clean and secure. When necessary, clean the fan and the inside of the heater thoroughly. The use of parts other than genuine Clarke replacement parts may result in safety hazards or decreased performance, and will invalidate your warranty.
  • Page 14: Troubleshooting

    No spark at spark plug due Check spark plug wire. to loose HT lead or PCB Tighten or re-attach if fault. loose. If condition persists, contact your Clarke dealer for advice Heater stops during Excessive or insufficient gas Check pressure regulator operation.
  • Page 15: Specifications

    50/170,000 Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the heater’s data plate.
  • Page 16: Environmental Recycling Policy

    ENVIRONMENTAL RECYCLING POLICY Through purchase of this product, the customer is taking on the obligation to deal with the WEEE in accordance with the WEEE regulations in relation to the treatment, recycling & recovery and environmentally sound disposal of the WEEE. In effect, this means that this product must not be disposed of with general household waste.
  • Page 17 PARTS DIAGRAM - DEVIL 900DV/1600DV Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 18 PARTS LIST DEVIL - 900DV/1600DV Description Description Outer Shell Fuel Tube Assembly Handle Mounting clips Extension Fitting Handle Control Valve Assembly Nut Middle Cylinder Control Valve Assembly Front Guard Male Fitting Connector Orifice Assembly Solenoid Valve Assembly Flame Holder Assembly Solenoid Valve Assembly Nut High Limit Switch Bracket Flame Intensity Control Knob...
  • Page 19: Parts Diagram - Devil 2100Dv

    PARTS DIAGRAM - DEVIL 2100DV Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 20: Parts List - Devil 2100Dv

    PARTS LIST - DEVIL 2100DV Description Description Outer Shell Elbow Fitting Handle Mounting Clips Fuel Tube Assembly Handle Extension Fitting Middle Cylinder Control Valve Assembly Nut Front Guard Control Valve Assembly Orifice Assembly Male Connector Fitting Flame Holder Assembly Solenoid Valve Assembly High Limit Switch Bracket Solenoid Valve Assembly Nut High Limit Switch...
  • Page 21: Wiring Diagram

    WIRING DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 22 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 23: Declaration Of Conformity (Ce)

    DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 24 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
