GAS HEATERS
MODEL NOS: DEVIL 900
PART NO: 6920186
USER INSTRUCTIONS
ORIGINAL INSTRUCTIONS
DL0425 - ISS 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEVIL 900 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke DEVIL 900

  • Page 1 GAS HEATERS MODEL NOS: DEVIL 900 PART NO: 6920186 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0425 - ISS 7...
  • Page 2: Environmental Recycling Policy

    INTRODUCTION Thank you for purchasing this CLARKE Gas Powered Heater. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 Contact Details: Clarke International Ltd, Hemnall St, Epping, Essex, CM16 4LG Tel: 0208 988 7400 Model Number DEVIL 900 Indirect Heating Functionality Direct Heat Output 25kW Indirect Heat Output Minimum permissible total flue length (vertical + horizontal)
  • Page 4: Function And Operating Parameters

    Type of heat output/room temperature control (select one) Single stage heat output, no temperature control Two or more manual stages, no temperature control With mechanical thermostat temp control With electronic temperature control Electronic temperature control with day timer Electronic temperature control with week timer Other control options (multiple selections possible) Room temperature control with presence detection Room temperature control with open window detection...
  • Page 5: Safety Information

    SAFETY INFORMATION Read, and make sure you fully understand the following precautions and the hazards associated with this type of equipment. 1. ONLY use with the voltage specified and ensure the heater is properly earthed. 2. Use only the hose and factory preset regulator provided with the heater. 3.
  • Page 6: Safety Symbols

    23. To prevent injury wear gloves when handling the heater. 24. NEVER attach duct work to front or rear of the heater. 25. DO NOT alter the heater. Keep the heater in its original state. 26. Turn off the propane supply and unplug the heater when not in use. 27.
  • Page 7: General Precautions

    GENERAL PRECAUTIONS Even though this heater operates very close to 100 percent combustion efficiency, it still produces small amounts of carbon monoxide. • Carbon Monoxide (CO) is toxic. • Pregnant women, persons with a heart or lung condition, anemia or under the influence of alcohol, or those at high altitude, are more likely to be effected by Carbon Monoxide.
  • Page 8: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz.
  • Page 9: Propane Gas Supply

    UNPACKING When unpacking, check the heater for possible shipping damage. Should any damage be apparent, please notify your CLARKE dealer immediately. Your heater is fully assembled,- only the electrical and gas supplies need connecting. Retain any plastic cover caps (attached to the inlet connector and hose/regulator assembly) for future storage.
  • Page 10: Operating Space And Air Supply

    In order to reduce the risk of icing up when operating at long periods at maximum capacity, you should use a larger capacity gas bottle, or two/three bottles in parallel, as shown in Fig 2. • The ‘Tee’ piece and ‘pigtails’ are readily available from your builders merchants or gas supplier.
  • Page 11: Principle Of Operation

    PRINCIPLE OF OPERATION Understanding the basic operation of the heater will reinforce the need to maintain the unit in top condition at all times, whilst always observing the safety precautions. The heater comprises four basic systems: 1. The gas system. 2.
  • Page 12: Starting Procedure

    that after a few seconds, the gas valve button may be released and the flame is established. SAFETY CONTROL SYSTEM Should the flame extinguish for any reason, the thermocouple will quickly cool, causing the Flame Failure valve to close, shutting off the gas supply. Similarly, should there be a power failure, causing the fan motor to stop, the Safety Shut-Off valve solenoid will become de-energised, and therefore shut off the gas supply.
  • Page 13: Shutdown Procedure

    Should the flame extinguish when the ignition button is released, wait for 1 minute, before repeating the operation. • Turning the flame intensity control valve anti-clockwise will increase the gas supply and therefore the output, clockwise to decrease. If ignition is difficult or irregular, ensure the fan is operating and that the air inlet and outlet are completely clear.
  • Page 14 STORAGE CAUTION: DISCONNECT THE HEATER FROM THE PROPANE SUPPLY CYLINDER(S) 1. Store the propane gas cylinders in a safe manner outdoors and keep them below F (37 2. Place protective bags over fittings & connectors and store in a clean, dry place. 3.
  • Page 15: Maintenance

    Ensure that all connections are clean and secure. When necessary, clean the fan and the inside of the heater thoroughly. The use of parts other than genuine CLARKE replacement parts may result in safety hazards or decreased performance, and will invalidate your warranty.
  • Page 16: Troubleshooting

    Lock out of appliance due to Identify cause of over- overheating. Thermal cut-out heating. Wait for 5 mins and in operation. restart. If condition persists, contact your CLARKE dealer for advice. Spark plug does not Gap incorrect, faulty Clean and reset gap if spark.
  • Page 17 PROBLEM CAUSE REMEDY Burner starts but stops Thermocouple is not warm Repeat the starting as the gas valve button enough or is faulty. operation, keeping the gas is released. valve button depressed for longer. Weak gas supply. Increase flame intensity control valve setting.
  • Page 18: Specifications

    24.9/85,000 Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. ALWAYS consult the heater’s data plate.
  • Page 19: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 20: Parts List

    PARTS LIST Description No Description Outer Shell Spark Plug Washer Handle Mounting clips Spark Plug Handle Elbow Fitting Middle Cylinder Fuel Tube Assembly Front Guard Extension Fitting Orifice Assembly Securing Nut Flame Holder Assembly Gas Valve Orifice Nut Male Fitting Connector High Limit Switch Bracket Solenoid Valve Assembly High Limit Switch...
  • Page 21: Wiring Diagrams

    WIRING DIAGRAMS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 22 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 23: Declaration Of Conformity (Ce)

    DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 24 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
