GAS HEATERS
MODEL NOS: 900DV,1600DV & 2100DV
PART NOS: 6920175, 6920191 & 6920196

USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS
LS0618 - ISS 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 900DV and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke 900DV

  • Page 1: User Instructions

    GAS HEATERS MODEL NOS: 900DV,1600DV & 2100DV PART NOS: 6920175, 6920191 & 6920196 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS LS0618 - ISS 1...
  • Page 2: Function And Operating Parameters

    INTRODUCTION Thank you for purchasing this CLARKE Gas Powered Heater. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase.
  • Page 3: Carbon Monoxide

    WARNING: LACK OF AIRFLOW CAN CAUSE CARBON MONOXIDE POISONING. WARNING: CARBON MONOXIDE POISONING CAN KILL. WE RECOMMEND THAT YOU USE A CARBON MONOXIDE DETECTOR, AVAILABLE FROM YOUR CLARKE DEALER WHAT ARE THE SIGNS The 6 symptoms to look out for: • Headaches •...
  • Page 4: Safety Information

    SAFETY INFORMATION Read, and make sure you fully understand the following precautions and the hazards associated with this type of heater. • Use only liquid propane gas with this heater. • Make sure that the Propane gas bottle, gas hose and electric cable, are positioned behind the unit, away from the heat.
  • Page 5: Safety Symbols

    • Do not use in wet areas, basements or below ground level. Propane gas is heavier than air and will sink to the lowest possible level. • Make sure that the heater is correctly maintained in accordance with this manual. •...
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug or a suitably fused isolator switch. The heater may also be connected to a 110V supply through a suitably approved plug.
  • Page 7: Propane Gas Supply

    UNPACKING When unpacking, examine the heater for possible shipping damage. Should any damage be apparent, please notify your Clarke dealer immediately. Your heater is fully assembled,only the electrical and gas supplies need connecting. Retain any plastic cover caps (attached to the inlet connector and hose/regulator assembly) for future storage.
  • Page 8: Gas Connection

    GAS CONNECTION Connect the free end of the gas hose to the gas inlet connection on the heater and tighten to ensure there are no gas leaks. Before attaching the regulator to the gas cylinder, ensure the mating parts are free from grease and dirt and are undamaged.
  • Page 9: Operating Space And Air Supply

    OPERATING SPACE AND AIR SUPPLY MINIMUM FRESH AIR OPENING REQUIREMENTS As a general rule of thumb, an opening of 1in per 1000 Btu/hr is a minimum requirement. These heaters are specified as requiring a minimum ventilation of 3 sq/ft per 100,000BTU/hr.
  • Page 10: Principle Of Operation

    PRINCIPLE OF OPERATION Understanding the basic operation of the heater will reinforce the need to maintain the unit in top condition at all times, whilst always observing the safety precautions. The heater comprises four basic systems: 1. The gas system. 2.
  • Page 11: Ignition System

    IGNITION SYSTEM Ignition is automatic with this heater as soon as the gas valve button is depressed, with a continuous spark from the spark plug igniting the gas. As the thermocouple heats up, a low voltage is fed to the Flame Failure Valve, causing the valve to open, so that after a few seconds, the Gas ValveButton may be released and the flame is established.
  • Page 12: Shutdown Procedure

    8. When the burner remains lit, set the heater at the required level by turning the flame intensity control valve counter-clockwise. If the burner goes out, turn off the gas. Turn the gas valve fully clockwise to its lowest position. Check the fuel supply.
  • Page 13: Maintenance

    Ensure that all connections are clean and secure. When necessary, clean the fan and the inside of the heater thoroughly. The use of parts other than genuine Clarke replacement parts may result in safety hazards or decreased performance, and will invalidate your warranty.
  • Page 14: Troubleshooting

    Identify cause of over- to overheating. Thermal cut- heating. Wait for 5 mins out in operation. and restart. If condition persists, contact your Clarke dealer for advice. Spark plug does not Gap incorrect, faulty Clean and reset gap if spark. connection necessary or replace.
  • Page 15: Specifications

    50/170,000 Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the heater’s data plate.
  • Page 16 PARTS DIAGRAM - DEVIL 900DV / 1600DV Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 17 PARTS LIST - DEVIL 900DV / 1600DV Description No Description Outer Shell Fuel Tube Assembly Handle Mounting clips Extension Fitting Handle Control Valve Assembly Nut Middle Cylinder Control Valve Assembly Front Guard Male Fitting Connector Orifice Assembly Solenoid Valve Assembly...
  • Page 18: Parts Diagram - Devil 2100Dv

    PARTS DIAGRAM - DEVIL 2100DV Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 19: Parts List - Devil 2100Dv

    PARTS LIST - DEVIL 2100DV Description No Description Outer Shell Elbow Fitting Handle Mounting clips Fuel Tube Assembly Handle Extension Fitting Middle Cylinder Control Valve Assembly Nut Front Guard Control Valve Assembly Orifice Assembly Male Fitting Connector Flame Holder Assembly Solenoid Valve Assembly High Limit Switch Bracket Solenoid Valve Assembly Nut...
  • Page 20: Wiring Diagrams

    WIRING DIAGRAMS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 21: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 22 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 23 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
