- Page 1 PROPANE GAS HEATER MODEL NO: GRH35 PART NO: 6920016 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0718 - Issue 9...
-
Page 2: Function And Operating Parameters
INTRODUCTION Thank you for purchasing this CLARKE Gas Heater. designed for industrial use only, i.e. NOT for domestic use. This portable gas heater is designed to BS 4096 for industrial applications, to give safe, efficient and reliable operation, and is for use with Propane Gas only. - Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 Item Symbol Value Unit Fuel LPG butane Gaseous [mg/kWh ] (GCV) input Space Heating Emission(*) Indirect heating fuctionality: [yes/no] Heat Output At nominal heat output Pnom At minimum heat output (indicative) Pnom 1.55 Auxiliary electricity consumption...
-
Page 4: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Read, and make sure you fully understand the following precautions and the hazards associated with this type of equipment. 1. Check the heater thoroughly for damage. DO NOT operate a damaged heater. 2. DO NOT modify the heater or operate a heater which has been modified from its original condition. -
Page 5: Minimum Fresh Air Opening Requirements
MINIMUM FRESH AIR OPENING REQUIREMENTS • Do not use in unventilated areas. • The flow of combustion and ventilation air must not be obstructed. Warning: PROVIDE AT LEAST 3FT OPENING OF FRESH, OUTSIDE AIR WHILST RUNNING THIS HEATER. IF PROPER FRESH OUTSIDE AIR VENTILATION IS NOT PROVIDED, CARBON MONOXIDE POISONING CAN OCCUR. -
Page 6: If You Smell Gas
IF YOU SMELL GAS NO ODOUR DETECTED LP gas and natural gas have man-made odorants added specifically for detection 1. Some people cannot smell the odour of fuel gas leaks. added to propane (LP) or natural gas. If a gas leak occurs you should be able to You must determine if you can smell smell the fuel gas. -
Page 7: Gas System
FEATURES OF THE GRH35 Understanding the basic operation of the heater will reinforce the need to maintain the unit in top condition at all times whilst always observing the safety precautions. The heater comprises three basic systems: 1. The gas system. -
Page 8: Installation
2. Remove all protective material which may have been applied to the heater for shipment. 3. Check the heater for possible shipping damage. Should any damage be apparent, please notify your Clarke dealer immediately. LOCATING THE HEATER Although this heater incorporates a ‘tip-over’ switch, the heater and propane gas cylinder must be located on a hard, flat, level surface to minimize the risk of accidental tipping. -
Page 9: Gas Connection
When used, the heater should rest on suitable insulating material at least 1 inch thick and extending 3 ft. or more beyond the heater in all directions. GAS CONNECTION The hose for connecting the heater to the gas bottles is supplied loose and must be fitted by the user. - Page 10 OPERATING INSTRUCTIONS WARNING: BEFORE STARTING THE HEATER, YOU MUST ENSURE THAT THE MINIMUM VENTILATION REQUIREMENTS ARE OBSERVED TO AVOID THE RISK OF CARBON MONOXIDE POISONING. FIRST USE The heater reaches a very high temperature and during first use you may notice an odour coming from the heater - this is quite normal and will disperse quickly (It is recommended the heater is initially run outside to enable the odour to clear).
- Page 11 the burner ignites, keep button pressed for one (1) minute or until the burner stays lit after releasing button. WARNING: WHEN LIGHTING THE BURNER WITH A TAPER, LIGHT AT THE BOTTOM OF THE SCREEN, NOT AT THE ORIFICE. NOTE: In cases where long runs of gas supply lines have been installed ahead of the appliance, it may be necessary to bleed trapped air out of supply lines before lighting pilot.
-
Page 12: Cleaning And Maintenance
CLEANING & MAINTENANCE WARNING: NEVER ATTEMPT TO SERVICE THE HEATER WHILE IT IS CONNECTED TO THE PROPANE SUPPLY, IS OPERATING, OR IS HOT. (SEVERE BURNS CAN OCCUR). 1. Turn heater off and let it cool for at least 20 minutes before cleaning. 2. -
Page 13: Troubleshooting
TROUBLESHOOTING Fault Cause Remedy Burner fails to light 1. Gas supply valve 1. Open gas supply valve slowly closed. 2. Close propane supply valve 2. Excess-flow check closed propane tank and re- valve. open slowly. 3. Excess-flow check 3. Replace burner orifice. valve. -
Page 14: Specifications
3. The tip-over switch has 3. Investigate the cause, heater tripped. has fallen over. Right it and investigate the cause. Take steps to prevent re-occurrence. SPECIFICATIONS Model GRH35 Gas Type Propane Output 10.25 kW (35,000 BTU/Hr) Regulator Pressure 37 mbar Regulator flow rate 1.5kg/hr Fuel Consumption 0.7 kg/hr... -
Page 15: Parts Diagram
PARTS DIAGRAM PARTS LIST Burner 115286-01 Tip Switch 115285-01 Thermocouple 114121-01 Brass Elbow 111090-02 Bracket 117384-01 Hose/Regulator 115290-04 Igniter Electrode 115291-01 Wheel 115292-01 Igniter Bracket 117385-01 Wheel Bracket 114156-02 Piezo-Igniter Kit 102445-01 Wheel Lock 115294-01 Orifice 115287-01 Main Frame Assy 117297-01 Valve 115285-01... -
Page 16: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 17 ALSO AVAILABLE FROM THE CLARKE RANGE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 18 ALSO AVAILABLE FROM THE CLARKE RANGE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 19 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
