- Page 1 POWEREDBY USER MANUAL MERACH MR-E17 CARDIO CLIMBER Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com...
- Page 2 WE ARE Our customers aren't just important; their health, fitness, and pure enjoyment for live is at the core of everything we do at MERACH. From innovative fitness research and cutting-edge product development, to our exceptional purchasing & after-sales service. We are our customers' life-long partner in crafting a better fitness future.
- Page 3 Contents Contents Please read the entire manual carefully before installing and using the machine, and save for further use.
-
Page 4: Safety Instructions
Safety Instructions Please keep this manual in a safe place for future reference. It is very important to read the entire manual thoroughly before installing and using the machine. Safe and effective training can only be achieved if the machine is properly assembled, properly maintained and used. - Page 5 Safety Instructions This machine is not for professional medical treatment. This product is only for consumer use only. The overall performance of the machine and all moving parts must be checked regularly to ensure the safety of the machine. If the moving parts are damaged, please do not use the machine until the parts are repaired.
-
Page 6: Specifications
Specifications Mode: MR-E17 Name: MERACH Magnetic Cardio Climber Recommend Max Weight: 300 lbs Net Weight: 85.2 lbs Product Dimensions: 37.6*26.5*62.4 inch... -
Page 7: Packing List
#34RRightHandrailx1 #86FrontHandleBarX1 #29RRightSwingLeverx2 #25ConnectionStrapx2 POWEREDBY USER MANUAL MERACH MR-E17 CARDIO CLIMBER Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com... - Page 8 Parts Tool List Check if all bolts and tools are in the package. Step4 Step1 #75 Cross Recessed Pan Head Tapping Screws ST4.2*20 x2 #35 Cup head Square Neck Bolt M8*42 x4 #73 Cross Recessed Pan Head Tapping Screws ST4.2*21 x4 #36 Spring Washer D8 x4 #4 Hexagon Socket Button Head Screws M8*55 x8 #37 Bolt Cap M8 x4...
- Page 9 Assembly Instructions Step1: Install the Foot Tubes, Decorative Covers and Adjustable Foot Pads A. As shown in Figure P1, remove the pre-assembled Front Welded Pipe(#a), Rear Welded Pipe(#b), Four Flat Round Head Hex Socket Screw(#c) and Flat Washer(#d) with Allen Key(#A) firstly.
- Page 10 Assembly Instructions Step2：Install the Left & Right Pedal A. Install the Pedal Backing Plate(#83) and Left/Right Pedal(#10L/R) onto the Left/Right Pedal Tube(#9L/R) with four Hexagon Bolts(#11), four Flat Washers(#6) and four Nylon Nuts(#12), and tighten it with the Cross Wrench(#B). Note: As shown in Figure, the Pedal Backing Plate(#83) should be assembled on the Left/Right Pedal(#10L/R) below respectively.
- Page 11 Assembly Instructions Step3: Install the Handlebar Axle, Swing Levers and the Connection Strap A. Insert the Handlebar Axle(#49) through the Main Frame(#1). B. Use two Wave Washer(#95), two Hexagon Socket Button Head Screws(#33), two Spring Washers(#32), two Flat Washers(#31) and two D Shape Washers(#30) to secure the Left/Right Swing Lever(#29L/R) onto the Main Frame(#1).
- Page 12 Assembly Instructions Step4: Install the Left / Right Handrail A. Align and attach the Left / Right Handrail(#34L/R) into the Left/Right Swing Lever(#29L/R) respectively with four Cup Head Square Neck Bolt(#35), four Spring Washer(#36) and four Bolt Cap(#37), tighten it with the Cross Wrench(#B).
- Page 13 Assembly Instructions Step5: Install the Monitor and Bottle Cage A. Remove the pre-assmebled Bolt(#84) of the Monitor(#4) and the pre-assembled Cross Recess Head Screw(#92) of Middle Handlebar Post(#39) firstly. B. Connect the Wires of Monitor(#41) with the Induction Wire(#80) and the Trunks lines(#96) , and install the Monitor(#4) onto the Middle Handlebar Post(#39) with four Bolts (#84).
- Page 14 Assembly Instructions Step6: Install the Front Handle Bar A. Raise up the Middle Handlebar Post(#39) in the direction of the arrow as shown in Figure. B. Tighten the Middle Handlebar Post(#39) with one Hexagon Socket Button Head Screws(#42), one Spring Washer(#32) and one Flat Washer(#6). C.
- Page 15 Product Usage Instructions Resistance Adjustment Instruction Rotate the Resistance Adjusting Knob(#76) with the arrow aligned with the gear digit as shown. Rotate clockwise to increase resistance and counter-clockwise to decrease resistance(1-16).
- Page 16 Product Usage Instructions Machine Movement Instructions Drag back and forth by grasping the Front Handle Bar(#86) with your hand and the Front Foot Tube(#2) touching the ground. Batteries Installation Instructions Remove the back cover by hand (Figure A), then prepare the batteries (Figure B), then install two batteries, install the back cover (Figure C), and the battery assembly is completed (Figure D).
- Page 17 Instructions for the Monitor FUNCTIONAL BUTTONS: MODE - Press to select function.Long press to reset time/distance/calorie. SET - To set the values of time/distance/calories and pulse when not in scan mode. RESET - Press to reset time/distance/calories and pulse. FUNCTION AND OPERATIONS: 1.
- Page 18 Instructions for the Monitor 7. PULSE RATE: (1) Press MODE button until “PULSE” appears. Before measuring your pulse rate, please place your palms of your hands on both of your contact pads and the monitor will show your current heart beat rate in beats per minute (BPM) on the LCD after 6~7 seconds.
- Page 19 Please include your order ID and MERACH app Username. 1. To download the MERACH app, scan the QR code or search "MERACH" in the Apple App Store® or Google Play Store.
- Page 20 Store or Google Play Store. ® 2. Open the Kinomap app. Log In or Sign Up. 3. Select the corresponding fitness equipment 4. Turn on Bluetooth, and choose Merach. 5. Select "Ellipticals", and find your "MRK-E17-XXXX". 6. Start training and explore different workout methods.
- Page 21 Warm-up Do stretches before exercising. Warm muscles are easier to stretch, so start with a 5-10 minute warm-up, then do some stretches shown below - 5 times, 10 seconds or more per leg. Do it again after the workout. 1. Stretch down Bend your knees slightly, slowly bend your body forward, relax your back and shoulders, and try to touch your toes with your hands.
-
Page 22: Warning Decal Placement
Warning Decal Placement PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE USE & REFERENCE. DO NOT DISCARD This drawing show the locations of the important Safety and Warning Decals. Please ensure any user of the unit familiarizes themselves with Safety and Warning guidelines before use. lmproper or excessive exercise may cause injuries. -
Page 23: Troubleshooting
Troubleshooting Questions Solutions Rotate the knob clockwise to increase resistance, and rotate the knob counterclockwise to reduce resistance. Cardio Climber resistance is adjustable, the mechanical knob is to How to adjust the knob help achieve multi-gear variable speed. and how to use it? The Cardio Climber is still malfunctioning. -
Page 24: Warranty Information
Unsupervised use by children under 18 years old. MERACH and its subsidiaries are only responsible for damages caused by the intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses, so the above disclaimer may not apply to you. - Page 25 You can enjoy an additional 12-month warranty. Just active your warranty by sending the product's model name via register@merach.com, or log onto merachfit.com/pages/warranty and enter your order number (i.e. Amazon) within the first 14 days of purchase to register your new product for the extended warranty. If you are unable to provide the order number for your product, please type a short note in the order number field along with the date you received your product.
- Page 26 @merachfit @Merachfit @Merachfit @Merachfit Customer Service: support@merach.com Official Website: merachfit.com...
