Summary of Contents for Merach MR-E07
- Page 1 POWEREDBY USER MANUAL MERACH MR-E07 ELLIPTICAL MACHINE Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com...
- Page 2 WE ARE Our customers aren’t just important; their health, fitness, and pure enjoyment for live is at the core of everything we do at MERACH. From innovative fitness research and cutting-edge product development, to our exceptional purchasing & after-sales service, we are our customers’...
-
Page 3: Table Of Contents
Specifications·······························································03 Packing List·································································04 Parts Tool List ······························································05 Assembly Instructions····················································06 Product Usage Instructions·············································13 Insturctions for the Monitor··············································15 MERACH APP Setup·····················································17 KINOMAP APP Setup····················································18 Warm-up·····································································19 Troubleshooting····························································20 Warranty Information······················································21 This device contains a radio transmitter module with type approval code FCC ID ENTIFIER: 2A6QWMR-BLE001. -
Page 4: Safety Instructions
Safety Instructions Please keep this manual in a safe place for future reference. It is very important to read the entire manual thoroughly before installing and using the machine. Safe and effective training can only be achieved if the machine is properly assembled, properly maintained and used. - Page 5 Safety Instructions This machine is not for professional medical treatment. This product is only for family use. The overall performance of the machine and all moving parts must be checked regularly to ensure the safety of the machine. If the moving parts are damaged, please do not use the machine until the parts are repaired.
-
Page 6: Specifications
Specifications Mode: MR-E07 Name: MERACH Magnetic Elliptical Machine Recommend Max Weight: 265 lbs Net Weight: 59.08 lbs Product Dimensions: 43.9*22.24*61.42 inch... -
Page 7: Packing List
#92PedalBackingPlatex4 #5 Middle Handrail X 1 POWEREDBY USER MANUAL MERACH MR-E07 ELLIPTICAL MACHINE Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com... -
Page 8: Parts Tool List
Parts Tool List Check if all bolts and tools are in the package. Step2 Step1 #7 Hexagon Socket Pan Head Bolt #36 Square Neck Bolt M8*62*60 X 4 M8*15*56 X 6 #6 Flat Washer d8*Φ20*1.5 X 4 #6 Flat Washer d8*Φ20*1.5 X 4 #23 Cap Nut M8*S13 X 4 #20 Spring Washer D8 X 6 #A Multi-function Cross Wrench... -
Page 9: Assembly Instructions
Assembly Instructions Step 1: Install the Foot Tubes A. Use the Square Neck Bolt(#36), Flat Washer(#6) and Cap Nut(#23) to fix the Front Foot Tube(#35A) and Rear Foot Tube(#35B) on the Main Frame(#33) by the Multi-function Cross Wrench(#A) as shown below. - Page 10 Assembly Instructions Step 2: Fix the Handlebar Post A. Connect the Trunk link(#10) of Monitor to the Induction Wire(#31), and then join the Resistance Knob(#11) and Wire(#32) as shown in figure. B. Install the Handlebar Post(#12) into the Main Frame(33), align the hole of bolts. C.
- Page 11 Assembly Instructions Step 3: Assemble the Pedals on the Foot Pedal Connecting Tube A. Assemble the Left Pedal(#38L) and the Pedal Backing Plate(#92) onto the Left Foot Pedal Connecting Tube(#41L) with the Small Hexagon Head Bolt(#37) and Nylon Nut(#43). B. Assemble the Right Pedal(#38R) and the Pedal Backing Plate(#92) onto the Right Foot Pedal Connecting Tube(#41R) with the Small Hexagon Head Bolt(#37) and Nylon Nut(#43).
- Page 12 Assembly Instructions Step 4: Install the Handrails A. Insert the Left Handrail(#16L) into the Left Rocker(#25L), align the hole of bolts. B. Use the Multi-function Cross Wrench(#A) to tighten the Left Handrail(#16L) with the Square Neck Bolt(#24),Flat Washer(#6) and Nylon Nut(#39). C.
- Page 13 Assembly Instructions Step 5: Connect the Foot Pedal Connecting Tube to the Main Frame A. Remove the pre-assembled Wave Washer(#14), Flat Washer(#19), Sparing Washer(#20) and Outer Hexagon Bolt(#21) from the Long Axis(#15). B. Insert the Long Axis(#15) into the Handlebar Post(#12) horizontally, and then assemble the Wave Washer(#14), Left Handrail(#16L) and Right Handrail(#16R) on the Long Axis(#15) separately.
- Page 14 Assembly Instructions Step 6: Install the Middle Handrail A. Remove the pre-assembled Stopper(#52) from the wire hole of Handlebar Post（#12). B. Put the Heart Rate Wires(#51) of the Middle Handrail(#5) through the wire hole of Handlebar Post(#12), and draw it from the plate of the monitor. C.
- Page 15 Assembly Instructions Step 7: Install the Monitor and Bottle Cage A. Screw the pre-assembled Cross Recess Head Screw(#2) off from the Monitor(#1) by the Multi-function Cross Wrench(#A). B. Screw the pre-assembled Cross Recessed Pan Head Tapping Screws(#91) off from the Handlebar Post(#12).
-
Page 16: Product Usage Instructions
Product Usage Instructions Resistance Adjustment Instruction Rotate the Resistance Adjusting Knob(#11) with the arrow aligned with the gear digit as shown. Rotate clockwise to increase resistance and counterclockwise to decrease resistance(1-16). Rear Foot Tube Adjustment Instruction Please adjust the Twelve Eccentric Foot Sleeve(#29) on the Rear Foot Tube(#35B) as needed to make the machine stable without shaking. - Page 17 Product Usage Instructions Machine Movement Instructions Drag back and forth by grasping the Left and Right Handlerail(#16L/R) with your hand and the Front Foot Tube(#34) touching the ground. Batteries Installation Instructions Remove the back cover by hand (Figure A), then prepare the batteries (Figure B), then install two batteries, install the back cover (Figure C), and the battery assembly is completed (Figure D).
-
Page 18: Insturctions For The Monitor
Instructions for the Monitor FUNCTIONAL BUTTONS: MODE - Press to select function.Long press to reset time/distance/calorie. SET - To set the values of time/distance/calories and pulse when not in scan mode. RESET - Press to reset time/distance/calories and pulse. FUNCTION AND OPERATIONS: 1. - Page 19 Instructions for the Monitor 7. PULSE RATE: (1) Press MODE button until “PULSE” appears. Before measuring your pulse rate, please place your palms of your hands on both of your contact pads and the monitor will show your current heart beat rate in beats per minute (BPM) on the LCD after 6~7 seconds.
-
Page 20: Merach App Setup
MERACH APP Setup Download and Use of MERACH Ourcustomercangeta180-dayMERACHmembership.Pleasecontactusthrough support@merach.comafterreceivingtheproducttogetanexclusiveredemption code.PleaseincludeyourorderIDandMERACHappUsername. 1.TodownloadtheMERACHapp,scantheQRcodeorsearch"MERACH"intheApple AppStore®orGooglePlayStore. MERACH APP Download APP Connection Guide 2.OpentheMERACHapp.LogInorSignUp. 3.Followthein-appinstructionstosetupyourdevice. USINGYOURELLIPTICALMACHINE Note: 1.UsingtheMERACHappallowsyoutogetfreeworkoutcoursesandaccessadditional functionsandfeatures. 2.CoachingcoursesareonlyavailableinEnglish. -
Page 21: Kinomap App Setup
KINOMAP APP Setup Download and Use of KINOMAP 1.TodownloadtheKinomapapp,scantheQRcodeorsearch"Kinomap"inthe AppleAppStore®orGooglePlayStore. 2.OpentheKinomapapp.LogInorSignUp. 3.Selectthecorrespondingfitnessequipment 4.TurnonBluetooth,andchooseMerach. 5.Select"Ellipticals",andfindyour"MRK-E07-XXXX". 6.Starttrainingandexploredifferentworkoutmethods. -
Page 22: Warm
Warm-up Do stretches before exercising. Warm muscles are easier to stretch, so start with a 5-10 minute warm-up, then do some stretches shown below - 5 times, 10 seconds or more per leg. Do it again after the workout. 1. Stretch down Bend your knees slightly, slowly bend your body forward, relax your back and shoulders, and try to touch your toes with your hands. -
Page 23: Troubleshooting
Troubleshooting QuestionsSolutions Rotate the knob clockwise to increase resistance, and rotate the knob counterclockwise to reduce resistance. Elliptical machine resistance is adjustable, the mechanical knob is to How to adjust the knob help achieve multi-gear variable speed. and how to use it? The elliptical machine is still malfunctioning. -
Page 24: Warranty Information
Unsupervised use by children under 18 years old. MERACH and its subsidiaries are only responsible for damages caused by the intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses, so the above disclaimer may not apply to you. - Page 25 You can enjoy an additional 12-month warranty. Just active your warranty by sending the product's model name via register@merach.com, or log onto merachfit.com/pages/warranty and enter your order number (i.e. Amazon) within the first 14 days of purchase to register your new product for the extended warranty. If you are unable to provide the order number for your product, please type a short note in the order number field along with the date you received your product.
- Page 26 @merachfit @Merachfit @Merachfit @Merachfit Customer Service: support@merach.com Official Website: merachfit.com...
