Merach MR-526D Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MR-526D
ELLIPTICAL TRAINER
INSTRUCTION MANUAL
Mail:service@merach.com
Web: www.merach.com
Manufacturer: Zhejiang Yulu E-commerce Co., Ltd.
Address: 298 Weiye Road, Binjiang District, Hang-
zhou, Zhejiang Province, China

Advertisement

loading
Need help?

Need help?

Do you have a question about the MR-526D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Merach MR-526D

Summary of Contents for Merach MR-526D

  • Page 1 MR-526D ELLIPTICAL TRAINER INSTRUCTION MANUAL Mail:service@merach.com Web: www.merach.com Manufacturer: Zhejiang Yulu E-commerce Co., Ltd. Address: 298 Weiye Road, Binjiang District, Hang- zhou, Zhejiang Province, China...

  • Page 3: Exploded Drawing

    Exploded Drawing...
  • Page 4 MR-526D Spare Parts List Product Name Specification Material meter handle pulse sensor Handle Bar Φ25 weldment Self-tapping screws M4.5*25 Half round end cap Φ25 Foam Φ25*3T*500mm End cap Φ50*32 Foam Φ32*3t*57OMM left arm Φ32 right arm Φ32 Coated Allen Bolt...
  • Page 5 M10*1.2 Hexagon nut M10*1.25 Fly Wheel Alex M10*1.25*115MM Chain adjustable set Plastic Cover Sensor wire 350MM length Washer Φ17*Φ22*2 C shape Clip Φ15 (axle Φ17) DC wire 400MM length Main frame welding weldment C shape Clip Φ10 Belt Wheel Φ37*20.5L axle Φ10*42mm Magnet...
  • Page 6 STEP 1 1. Fix the rear stabilizer caps(88) On the rear stabilizer (89 ) 2. Fasten front stabilizer (87) with 2 carriage bolts (90) from the underside of stabilizer. 3. Fasten rear stabilizer (89) with 2 carriage bolts (90) from the underside of stabilizer.
  • Page 7 STEP 2 1. Connect lower wire (32) and upper wire(31), make sure there is no looseness 2. Put upper support (30) into main frame (60) through plastic cover (96).
  • Page 8 STEP 3 1. Lock the left cardan joint(44) on the left pedal axle (77) with hexagon socket screws (10), spring washers (11) and washers (40) , tighten it with an Allen key (99). 2. The Installation method on the right is the same as that on the left.(Note : use the right cardan joint) R（Right）...
  • Page 9 STEP 4 1. Fasten lower swing bars (25R/25L) with axle (21) from upper support (30) and secure it with Washer(12), Spring washer (11), and Allen bolt (10) tightly. 2. The Installation method on the right is the same as that on the left.
  • Page 10 STEP 5 1. Fasten upper swing bars (9R/9L) with lower swing bars (25R/25L) and secure them with washer (14) and Allen bolt (15). 2. Lock the pedal bar(34L) in the left cardan joint(44) with bolt (42), washers (45) and nylon nut(46) , tighten it with an Allen key (99).
  • Page 11 STEP 6 1. Fasten right pedal (36R) with carriage bolts (35) from the right pedal bar (34R) and secure it with washer (37), spring washer (38) and knob (39) tightly. Do the same for the left pedal.
  • Page 12 STEP 7 1. Put upper support (30) into main frame (60) through plastic cover (96). And secure them with spring washer(11) & curved washers (14)&allen bolts (15) tightly.Fix plastic cover tightly with main frame (50).
  • Page 13 STEP 8 1. Fasten the Bottle Cage (28) to Upper Support （ 30） and secure it with 2 Screw(29). 2. Fasten handle bar (3) with Allen bolts (10) and washers (14) from upper Support （ 30） . 3. Remove the fixing screw (17) on the back of the meter(1) in advance, Connect hand pulse wire (20) and meter wire (31) with meter (1).
  • Page 14 STEP 9 1. Find the adapter (98), plug in power supply from the back of the elliptical machine and it can be used after power on.
  • Page 15 Electronic Displayer Instructions Fuction 1. Program: 21 in total Remarks: (1) The WATT window of the instrument without WATT function is not displayed. (2) The displayer without WATT function has only 20 programs and no watt control program. A: 1 manual program(Figure 1) Figure 1 B: 10 automatic programs P1~P10 (Figure 2~Figure 11) Figure 2...
  • Page 16 Figure 8 Figure 9 Figure 10 Figure 11 P1: ROLLING P2: VALLEY P3: FATBURN P4: RAMP P5: MOUNTAIN P6: INTERVAL P7: CARDIO P8: ENDURANCE P9: SLOPE P10: RALLY C: 1 WATT control program (Figure 12) (if this function is available) Figure 12 D: 4 heart rate control programs (Figure 13～Figure 16) 55%H.R, 75%H.R, 90%H.R and TARGET H...
  • Page 17 E: 4 user-defined programs CUSTOM1~CUSTOM4 (Figure 17~Figure 20) Figure 17 Figure 18 Figure 19 Figure 20 F:1 fat measurement program FAT (Figure 21) Figure 21 2. The user's gender, height, weight, and age can be memorized after power off. 3. Use dot matrix characters to display main information. 4.

  • Page 18: Operation

    A. When selecting the function program, press the ENTER key to confirm the program you want to exercise. B. When setting the function value, press the ENTER key to confirm the set value. 1. In the running (START display) state, press the ENTER key to select the speed window display speed or RPM or automatic switching.
  • Page 19 B. The age value flashes, press UP, DOWN (or rotate or slide) to set the age of the user, press ENTER to confirm, then press UP, DOWN to enter the MANUAL program (Figure 25) Note: When the age setting is wrong, the heart rate percentage indicated will be wrong either, so you need to set an accurate age.
  • Page 20 Watt control program WATT (if this function is available) A. Press the UP and DOWN keys (or rotate) to select the watt control program WATT B. Press the ENTER key to confirm the selection of the Watt control program and enter the time window setting state.
  • Page 21 Heart rate control program TGT H.R The user can arbitrarily set the heart rate target value to control the exercise. A. Press the UP and DOWN keys (or rotate) to select the heart rate control program TGT B. Press the ENTER key to confirm the selected heart rate control program and enter the time window setting state.
  • Page 22 Body fat measurement program(FAT) A. Press the UP and DOWN keys (or rotate) to select the body fat measurement program (FAT). (Figure 35) B. Press the ENTER key to confirm the selected body fat measurement program and enter the height setting state at the same time. C.
  • Page 23 Remarks: 1. When performing a body fat test, you should hold the heart rate test piece. The test results are: body fat percentage, basal metabolic rate BMR, body mass index BMI, body type and body type description. (Figure 41) Figure 41 FAT%: percentage of all body fat BMR (Basal Metabolic Rate): The calories needed to maintain the basic functions of the body.

  • Page 24: Alarm Prompt

    Figure 42 Figure 43 5. Heart rate test Grasp the metal plate of the heart rate sensor at the corresponding position with the left and right palms. During the test, make sure that each palm touches the two metal plates at the same time.
  • Page 25 MP3 playback (if this function is available) Insert the audio input plug into the earphone jack, turn the ON/OFF switch on the edge of the displayer, and the audio file in the external MP3 will be played immediately. LED light indicates the percentage of heart rate (if this function is available) LED displays the tested heart rate value as a percentage of the maximum heart rate of the age group A.
