User ' s Guide
用户说明书
MR-535 椭圆机
全 国 热 线 ： 400-189-1969
官 方 网 站 ： w w w . merach.com
公 司 名 称 ： 麦瑞克(杭州)健康科技有限公司

Advertisement

loading
Need help?

Need help?

Do you have a question about the MR-535 and is the answer not in the manual?

Questions and answers

Related Manuals for Merach MR-535

Summary of Contents for Merach MR-535

  • Page 1 User ’ s Guide 用户说明书 MR-535 椭圆机 全 国 热 线 ： 400-189-1969 官 方 网 站 ： w w w . merach.com 公 司 名 称 ： 麦瑞克(杭州)健康科技有限公司...
  • Page 2 椭圆机 MR-535...
  • Page 4 爆炸图（A） 第2页...
  • Page 6 主架 M3 x 7mm 自攻螺丝 立柱管 M4 x 20mm 钻尾螺丝 前脚管 M4 x 20mm 自攻螺丝 后脚管 M6 x 100mm 外六角螺丝 控制台 M8 x 60mm 内六角螺丝 把手 M8 x 16mm 外六角螺丝 感应下段线 M6 六角螺母 感应棒固定座 大波垫（Φ19） 弹簧螺母 小波垫（Φ16） 左下摇摆管 M6 x 45mm 螺丝 右下摇摆管...
  • Page 7 M8 弹性垫片 中轴垫片 M8 防松螺母 M8 盖形螺母 M10 防松螺母 (90)–12 (84)–2 (82)–4 (67)–2 (83)–4 M8 弧形垫片 Φ13 波形垫片 M13 平垫 M10 平垫 (65)–18 (69)–2 (58)–2 (72)–4 M5 x 12mm M4 x 16mm M8 x 16mm M10 x 45mm 外六角螺丝 螺丝(80)–2 法兰面螺丝...
  • Page 8 M12 x 110mm 脚踏芯轴（左牙） (78)–1 M12防松螺母（左牙） (86)–1 M12 x 110mm 脚踏芯轴（右牙） (70)–1 M12 防松螺母（右牙） (85)–1 内六角扳手（L6） Φ19 波形垫片 (57)–2 内六角扳手（L8）...
  • Page 11 90 65...
  • Page 12 润滑油 Grease...
  • Page 13 安装右踏管芯轴连接U组（88）到右边曲柄上： 先将M12x110mm脚踏芯轴（右牙）光杆表面抹上润滑油,然后将小波垫（58） 套进脚踏芯轴。 将它们一起插进套管（88），用内六角扳手（L8）将芯轴按顺时针拧紧曲柄。 拧进后，另一头用一个平垫（69）、一个防松螺母（85）将其并紧。 安装左右上摇摆管： 将右上摇摆管（13）插到右下摇摆管（11）上，用2个弧形垫片 （65）、2个弹性垫片（90）、2个M8x16mm内六角螺丝固定。...
  • Page 15 Calories Total Distance Pulse DIST SCAN TIME SCAN MODE MODE TIME Time SCAN Speed Distance...
  • Page 16 ELLIPTICAL MACHINE MR-535...
  • Page 17 Safety Information Before you undertake any programme of exercise that will increase cardiovascular activity please be sure to consult with your doctor. Frequent strenuous exercise should be approved by your doctor and proper use of your product is essential. Please read this manual carefully before commencing assembly of your product or starting to exercise.
  • Page 18 EXPLODED VIEW (A) Page2...
  • Page 19 EXPLODED VIEW (B) Page3...

  • Page 20: Part List

    PART LIST Key No. Qty. Description Key No. Qty. Description Frame M3 x 7mm Screw Upright M4 x 20mm Self-tapping Screw Front Stabilizer M4 x 20mm Screw Rear Stabilizer M6 x 100mm Bolt Console M8 x 60mm Bolt Handlebar M8 x 16mm Hex Bolt Reed Switch/Wire M6 Nut Clamp...
  • Page 21 PART IDENTIFICATION CHART(A) Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
  • Page 22 PART IDENTIFICATION CHART(B) Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 23: Assembly Instruction

    ASSEMBLY INSTRUCTION Identify the Rear Stabilizer (4), which has Leveling Caps (23). Attach the Rear Stabilizer (4) to the Frame (1) with two M8 x 65mm Carriage Bolts (73), two M8 Curved Washers (65), and two M8 Acorn Nuts (82); start both Carriage Bolts, and then tighten the Acorn Nuts.
  • Page 24 ASSEMBLY INSTRUCTION While a second person holds the Upright (2) near the Frame (1), connect the Upright Wire (49) to the Reed Switch Wire (7). Next, connect the Resistance Cable (20) to the Lower Resistance Cable (21) in the following way: See drawing A.
  • Page 25 ASSEMBLY INSTRUCTION Insert the excess wire and cable into the Frame (1). Tip: Avoid pinching the wires and the cables. Slide the Upright (2) onto the Frame (1). Attach the Upright (2) with two M8 x 65mm Screws (75), two M8 Split Washers (90), four M8 Curved Washers (65), and two locknuts(84).
  • Page 26 ASSEMBLY INSTRUCTION Attach the Water Bottle Holder (41) to the Upright (2) with two M4 x 16mm Flange Screws (95); start both Flange Screws, and then tighten them. NOTE: Lower Arm(10/11), Pedal Arm(14/15) and Arm Bracket(88/89) have pre-assembled together already. Grease Grease Using a plastic bag to keep your fingers clean,...
  • Page 27 ASSEMBLY INSTRUCTION Identify the Right M12x110mm Bolt(70), and the Right M12 Nut(85). Apply grease to the Right M12x110mm Bolt. Attach the Right Arm Bracket(88) to the right side of the crank with the Right M12x110mm Bolt(70), an M13 Wave Washer(58), an M13 Washer(69), and the Right M12 Nut(85).
  • Page 28 ASSEMBLY INSTRUCTION Orient the Right Pedal (33) as shown, and attach it to the Right Pedal Arm (15) with two M10 x 45mm Bolts (76), two M10 Washers (72), and two M10 Locknuts (83); start both Bolts, and then tighten the Locknuts. Attach the Left Pedal (32) to the Left Pedal Arm (14) in the same way.

  • Page 29: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE The easy-to-use console features seven modes that provide instant exercise feedback during your workouts. Time (TIME) —This mode displays the elapsed time. Note: If you set a time goal , this display will show the time remaining in your workout.
