Team Corally RADIX 6 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LANGUAGES
INSTRUCTION
MANUAL
Download the latest version of the manual from www.corally.com
Téléchargez le guide de démarrage rapide en Français sur www.corally.com
Laden Sie die deutsche Schnellstartanleitung unter www.corally.com herunter.
Download de Nederlandse snelstartgids op www.corally.com
C-00185 • Instruction Manual - Revised : 2022-12-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RADIX 6 and is the answer not in the manual?

Questions and answers

Related Manuals for Team Corally RADIX 6

Summary of Contents for Team Corally RADIX 6

  • Page 1 LANGUAGES INSTRUCTION MANUAL Download the latest version of the manual from www.corally.com Téléchargez le guide de démarrage rapide en Français sur www.corally.com Laden Sie die deutsche Schnellstartanleitung unter www.corally.com herunter. Download de Nederlandse snelstartgids op www.corally.com C-00185 • Instruction Manual - Revised : 2022-12-20...

  • Page 2: Read First

    All Team Corally models guarantee a high quality of manufacture and performance that guarantees you a high satisfaction of use and services provided by the Team Corally. Always take the time to read the instructions carefully in order to follow all the procedures to use your RC model safely for you and for other people and property in the area.

  • Page 3: Use Precautions

    Take all necessary precautions before, during and after using your model. You are responsible for the safe assembly, mainte- nance and use of your model. In case of any questions, contact your local reseller or contact Team Corally support for assistance. LIPO BATTERY SAFETY PRECAUTIONS •...

  • Page 4: Warranty

    He must send the defective goods to our local rep- resentatives or directly to Team Corally / JSP Group Intl bvba, Geelseweg 80, 2250 Olen, Belgium at his own risk and cost.
  • Page 5 Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com DOWNLOAD • QUICK START GUIDE Download the latest version of this manual and other languages. Download updated PDF pages of : Spare parts - Option Parts - Exploded Views - Screws Chart ...

  • Page 6: Car Components

    Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com CAR COMPONENTS • QUICK START GUIDE Front Differential Front Shock Absorber Suspension Arm Anti-Roll Bar Steering Block...
  • Page 7 Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com QUICK START GUIDE • QUICK START GUIDE READ THE INSTRUCTIONS CHARGE THE BATTERY INSTALL 4x AA BATTERY CHARGER BATTERY...

  • Page 8: Gear Ratio

    GEAR RATIO MOTOR PINION MOD1.0 - PIGNON MOTEUR MOD1.0 - MOTORRITZEL MOD1.0 - MOTOR PINION MOD1.0 High-performance 13T tooth pinion gear, manufactured from special steel for toughness and durability with precise tolerances and assures unparalleled concentricity. Created on a special gear machine, all pinions feature ultra-precise tooth shaping and ultra-true running for vibration-free operation.
  • Page 9 GEAR MESH ADJUSTMENT - AJUSTEMENT DE L’ENGRENAGE - GETRIEBEVERSTELLUNG - TANDWIELAFSTELLING If the gear mesh is not correct, you wear out the spur gear prematurely, the transmission will make noise, give unnecessary load on the motor (higher consumption, heating of the transmission). Si l’espace entre le pignon et la couronne n’est pas correct, la couronne dentée s’use prématurément, la transmission fait du bruit et le moteur est inutilement sollicité...
  • Page 10 SHOCK ABSORBER MAINTENANCE - ENTRETIEN DES AMORTISSEURS - STOSSDÄMPFERWARTUNG - ONDERHOUD SCHOKDEMPERS It may be necessary to replace the silicone oil in the shock absorbers every 40 runs (depends on how you drive and the type of terrain you drive on). Il peut être nécessaire de remplacer l’huile silicone des amortisseurs toutes les 40 courses (cela dépend de votre conduite et du type de terrain sur lequel vous roulez).

  • Page 11: Shock Absorber

    SHOCK ABSORBER - AMORTISSEUR - STOSSDÄMPFER - SCHOKDEMPER • Do not overtighten the Shock Cap to prevent deformation of the silicone Shock Bladder. • Ne serrez pas trop le capuchon de l’amortisseur pour éviter la déformation de la membrane en silicone. •...

  • Page 12: Differential Maintenance

    DIFFERENTIAL MAINTENANCE - ENTRETIEN DU DIFFÉRENTIEL - DIFFERENZIALWARTUNG - DIFFERENTIEEL ONDERHOUD It may be necessary to replace the silicone oil every 50 runs (depends on how you drive and the type of terrain you drive on). Il peut être nécessaire de remplacer l’huile silicone toutes les 50 courses (cela dépend de votre conduite et du type de terrain sur lequel vous roulez). Es kann notwendig sein, das Silikonöl alle 50 Fahrten zu wechseln (abhängig von Ihrer Fahrweise und dem Gelände, auf dem Sie fahren).

  • Page 13: Front & Rear Differential

    FRONT & REAR DIFFERENTIAL - DIFFÉRENTIEL AVANT ET ARRIÈRE - DIFFERENTIAL VORNE UND HINTEN - VOOR & ACHTER DIFFERENTIEEL C-3002-30-12 (4pcs) C-00180-153-3 C-00180-205 C-3611-3-08-16-05 C-00180-179 (set) C-00180-182 C-00180-184 C-00180-178 C-00180-205 C-00180-183 C-00180-182 C-3611-3-08-16-05 C-00180-153-3 C-00180-098 CENTRE DIFFERENTIAL - DIFFÉRENTIEL CENTRAL - ZENTRALDIFFERENTIAL - CENTERDIFFERENTIEEL C-3002-30-10 (x4) C-00180-154-3 C-00180-205...
  • Page 14 FRONT DRIVE TRAIN - TRAIN AVANT - FRONTANTRIEB - VOORSTE AANDRIJFLIJN C-00180-117 C-00180-009 DIN913 C-00180-123 M4x4 C-00180-122 C-00180-009 C-00180-329 C-00180-123 C-3003-30-12 (2x) C-3003-30-10 C-00180-207 C-00180-009 C-3611-3-08-16-05 (x2) C-00180-150 C-00180-555 C-3201-60 C-00180-150 C-00180-011 C-00180-360 C-00180-193 C-3003-30-16 C-00180-149 C-00180-089 C-00180-012 (x2) C-3003-30-20 C-00180-051 C-00180-240 M4x10...
  • Page 15 REAR DRIVE TRAIN - TRAIN ARRIÈRE - HINTERACHSANTRIEB - ACHTERSTE AANDRIJFLIJN M3x14 C-00180-226-B C-00180-005 C-3002-30-12 (x2) Nylstop Nut•M3 C-00180-535 C-3003-30-20 C-00180-005-2 C-00180-005-2 C-31205 (x5) C-3003-30-12 (x2) C-3101-40 (4) C-3101-30 C-3101-30 C-00180-005 C-00180-030 C-3003-30-14 C-3101-30 C-00180-148 C-3003-30-25 C-00180-030 DIN913•M4x4 C-00180-122 C-00180-055 C-00180-132 C-00180-329 C-00180-293...
  • Page 16 CHASSIS - CHASSIS - CHASSIS - CHASSIS C-54055 C-3001-40-12 C-3003-30-10 C-00180-177 C-00180-023 C-3003-30-30 C-3004-40-04 M3x8 C-3003-30-12 C-3001-40-10 C-00180-372 C-3003-30-10 C-00180-171 C-3001-40-08 (x2) C-72713 C-52022 C-3003-30-18 C-3002-30-06 C-00180-129 C-00180-176 C-00180-015 C-00180-044 (x2) C-54011 C-3003-30-12 (x4) C-00180-149 C-00180-018 C-00180-024 C-00180-013 C-3104-40 C-3101-40 C-3003-30-10 C-3003-30-08 (x2) C-3003-30-12...

  • Page 17: Spare Parts

    SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-004 C-00180-004-1 C-00180-005-2 C-00180-008 C-00180-009 Battery - ESC Tray - Composite Battery Strap - Hook & Loop Wing Mount - Adjustable - Hub - Rear - Composite - 1 pc Steering Block - Pillow Ball Cup - 1 pc - 2 pcs...
  • Page 18 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-117 C-00180-122 C-00180-123 C-00180-127 C-00180-129 Pivot Ball Adjusting Nut - Alu- Pin 2.5x17mm - Steel - 10 pcs Pivot Ball - Steel - 4 pcs Hinge Pin - Outer - Steel - 2 pcs Turnbuckle - M3 - 35mm - minium - 4 pcs Steel - 2 pcs...
  • Page 19 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-193 C-00180-189 C-00180-190 C-00180-191 C-00180-192 Drive Shaft - Center - Front - Shock Bladders - Silicone - Shock Washer - 2.5x6x0.5mm - O-Ring - Silicone - 9x12mm O-Ring - Silicone - Steel - 1 pc 4 pcs Steel - 10 pcs...
  • Page 20 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN 100K Oil Filled C-00180-684 C-00180-685 C-00180-686 C-00180-555 C-00180-556 Steering Links - Buggy - Com- Camber Links Rear - Buggy - Gear Diff Pin - 3.5x29.8mm - Center Diff Assembly - Alumini- Diff Case - Centre - Aluminium.

  • Page 21: Option Parts

    OPTION PARTS - PIÈCES D’OPTION - OPTIONSTEILE - OPTIES Fit with C-00180-128-2 Fit with C-00180-130-2 Fit with C-00180-039 Fit with C-00180-041 C-00180-039 C-00180-041 C-00180-128-2 C-00180-130-2 C-00180-224 Steering Ball Cups - Composite Rear Camber Ball Cups - Outer Turnbuckle - M4 - 50mm - Turnbuckle - M5 - 50mm - Fan Holder - Composite - 1 set - 1 set...
  • Page 22 OPTION PARTS - PIÈCES D’OPTION - OPTIONSTEILE - OPTIES Swiss Made 7075 T6 Swiss Made 7075 T6 IP-67 Made in Italy Made in Italy C-00180-682 C-00180-683 C-52001 C-52022 C-49145-X OC-27 HV Digital Servo - 5-8.4V Suspension Arm Mount - FR - Suspension Arm Mount - FF - High Speed Servo - High Voltage Sport Racing 50C - 5400Mah - 4S...
  • Page 23 STEEL SCREWS - VISSERIE ACIER • STAHLSCHRAUBEN • STAAL SCHROEVEN LENGTH LENGTH LENGTH LENGTH HEX FLAT HEAD SCREWS HEX BUTTON HEAD SCREWS HEX SOCKET HEAD SCREWS HEX SET SCREWS DIN 7991 - STEEL - 10 PCS DIN 7380 - STEEL - 10 PCS DIN 912 - STEEL - 10 PCS DIN 916 - STEEL - 10 PCS NOMINAL...

  • Page 24: Ball Bearings

    NUTS - ECROUS • MUTTERN • MOEREN NYLSTOP NUT NYLSTOP NUT - FLANGED NYLSTOP NUT LOW PROFILE NUT ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS STEEL - 10 PCS DIN 936 - STEEL - 10 PCS NOMINAL NOMINAL NOMINAL NOMINAL COLOR COLOR...
  • Page 25 ALUMINIUM WASHERS - RONDELLES EN ALUMINIUM • ALUMINIUM-UNTERLEGSCHEIBEN • ALUMINIUM RINGEN WASHER FOR SOCKET HEAD SCREW WASHER FOR BUTTON HEAD SCREW WASHER FOR FLAT HEAD SCREW ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS FOR S/H FOR B/H FOR F/H COLOR...

  • Page 26: Declaration Of Conformity

    DECLARATION OF CONFORMITY - DÉCLARATION DE CONFORMITÉ • KONFORMITÄTSERKLÄRUNG • VERKLARING VAN OVEREENSTEMMING DECLARATION OF CONFORMITY EU-Konformitätserklärung/ Déclaration de Conformité UE (in accordance with ISO/IEC 17050-1) / (in Übereinstimmung mit ISO/IEC 17050-1) / (Conformément à la norme ISO/IEC 17050-1) Description : RADIX XP 6S - BUGGY 4WD - 1/8 -RTR Item Number: C-00185 This declaration is issued under the sole responsibility of the manufacturer.
  • Page 27 SPORT RACING - LIPO ELECTRONIC Discover our range of Precision CNC-Cut MOD-1.0 Team Corally - Sport Racing 50C - 4S or 6S - XT-90 - A range of high quality electronic equipment Pinions for motors with a ø 5.0mm motor shaft Hard Case for the best performance.
