MODEL # M20
IMPORTANT
Always wear protective clothing, eye wear, and dust mask to prevent contact with chemicals and other
materials being applied with this machine.
Remove any material in the hopper before lifting or detaching this machine from the vehicle.
Care must be taken when lifting this machine so as not to cause personal injury or equipment damage. Never
attempt to install this machine to the vehicle alone. Recruit the help of someone to assist when attaching and
detaching this machine from the vehicle.
Refer to the material packaging or the Material Safety Data Sheet for precautionary measures required when
handling materials to be applied.
Before attaching this machine, consideration must be given to the load capacity of the vehicle. Refer to the owner's
manual of the vehicle for rated load capacity. Be sure to take into account the weight of this machine is 20lbs. and
the weight of the material to be placed in the hopper when calculating the total load.
M20 Manual Mar2024
Broadcast Spreader
ASSEMBLY INSTRUCTIONS
Thank you for selecting EarthWay for your
spreader needs. Our production team in
Northern Indiana takes pride in building this
spreader. Our customer support team is standing
ready to ensure your success. Please contact us
at www.EarthWay.com to see our full line of
commercial, lawn & garden tools.
12 Volt ATV
PAGE 1
Advertisement
Table of Contents
Related Manuals for EarthWay M20
Summary of Contents for EarthWay M20
- Page 1 Northern Indiana takes pride in building this spreader. Our customer support team is standing ready to ensure your success. Please contact us at www.EarthWay.com to see our full line of commercial, lawn & garden tools. IMPORTANT Always wear protective clothing, eye wear, and dust mask to prevent contact with chemicals and other ...
- Page 2 STEP 5: Next install four 1/4-20 x 1-1/2” Carriage bolts (#12) through the Hopper assembly and then through ONE of either side Frame and secure with 1/4-20 Hex Nut (#8). STEP 6: Now position the M20 to the Quad and install the remaining Frame member as outline above in STEP 4.
-
Page 3: How To Operate Safely
MOUNTING INSTRUCTIONS Position the M20 on the vehicle so that the impeller is positioned to be able to spin clear of any part of the vehicle, this will allow a full 180 degree spread pattern. Secure the frame to the mounting location with the enclosed J-Bolts at positions that will secure the spreader so that it will not move when operating the vehicle. - Page 4 Assembly and Operation Instructions SPREADER CALIBRATION INSTRUCTIONS Loosen stop on the gauge and set to #30 Open the lever to #30 and make sure that the shut-off is fully open. Loosen the cable clamp on the bottom of the hopper and slide the outer cable IN/Out until the shut-off is fully ...
-
Page 5: How To Order Parts
Assembly and Operation Instructions HOW TO ORDER PARTS Call or Email: TURF DEPOT 800-305-9255 or earthway@turfdepot.com *Installation of 77122 3-Sided Deflector Kit requires drilling of the hopper and motor support assembly for fitting. M20 Spreader Parts List Key # Part #... -
Page 6: Ec Declaration Of Conformity
EC Council Directives concerned with Machinery and Electromagnetic Compatibility. No alterations are to be made to the machine without prior consultation and approval of Earthway Products, Inc. otherwise the Declaration may become invalid. This equipment must be commissioned, used, and maintained strictly in accordance with the operating and maintenance instructions issued with the machine. -
Page 7: Customer Service
EarthWay. Due to the corrosive nature of most fertilizers and ice melt products, EarthWay Products, Inc. makes no warranty against and specifically excludes part(s) or product degradation or failure due to corrosion or its effects .
