REPLACING THE BATTERY
Read the Safety instructions document.
Risk of explosion if the battery is replaced by an incorrect type.
Insert 1 3V CR2032 battery, with the plus (+) side up. Be sure to respect the polarity. The power
supply terminals must not be short-circuited.
2
6
7
4
3
1
5
___
TECHNICAL DATA
Frequency range and maximum power used: 868.700 MHz - 869.200 MHz e.r.p. < 25 mW.
The environment in which the product is used might reduce the radio range. The use in the same
floor as the controlled products is recommended. Radio range in free field: 150 m.
Operating temperature: 0 °C (+32 °F) to +48 °C (+118.4 °F).
Power supply: 1 x CR2032 battery, 3 V
