F-2SDI-B-3G-TxRx
2 Channel Bidirectional SD/HD 3G-SDI Over Single Fiber CWDM Uncompressed Rack-Mountable
Step 1: Connect Power
1). Connect Included Power Cables to both Transmitter (TX) and Receiver (RX)
Step 2: Connect Fiber
1). Connect Transmitter to Receiver using Single Mode Fiber
2). The 'NOP' LED will light RED only if the fiber is disconnected.
When the fiber is properly connected, the 'NOP' LED will turn off.
https://thorbroadcast.com
2). "PWR" LED on both TX and RX indicates the unit is receiving power
with ST/PC connector (Not Included) Distance up to 20km
800-521-8467
sales@thorfiber.com
Quick Setup Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Thor Broadcast F-2SDI-B-3G-TxRx
Summary of Contents for Thor Broadcast F-2SDI-B-3G-TxRx
- Page 1 800-521-8467 sales@thorfiber.com F-2SDI-B-3G-TxRx Quick Setup Guide 2 Channel Bidirectional SD/HD 3G-SDI Over Single Fiber CWDM Uncompressed Rack-Mountable Step 1: Connect Power 1). Connect Included Power Cables to both Transmitter (TX) and Receiver (RX) 2). “PWR” LED on both TX and RX indicates the unit is receiving power Step 2: Connect Fiber 1).
- Page 2 Once a valid signal is connected, the LED will turn green on both the TX and RX sides at the corresponding connectors Step 4: Signal Flow (Example) Signal IN Scan for More: Signal OUT F-2SDI-B-3G-TxRx Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
