F-M2SDI-Tx/Rx
F-M4SDI-Tx/Rx
Quick Setup Guide
Step 1: Connect Power
F-M4SD1
F-M2SD1
Connect the included
Power Supplies to the
TRANSMITTER and
the RECEIVER
The RUN LED will
blink indicating that
power is properly
connected
RUN LED
Using Fiber Cable (not included)
Step 2: Connect Fiber
Connect the FIBER OUT of the
TRANSMITTER to the FIBER IN of
the RECEIVER
NOP LED
The NOP LED indicates the status of the fiber connection. It will turn off
when the fiber is properly connected and light red when disconnected.
