LEGRAND NUMERIC HPi 33 EVO User Manual page 37

APPENDIX 1 SPECIFICATIONS
MODEL
Capacity (VA/Watts) @ 35 Degree Celsius
Capacity (VA/Watts) @ 40 Degree Celsius
INPUT
Rated AC Input Voltage
Input Voltage Range
Frequency
Power Factor
100%
75%
Harmonic distortion
(THDi)
50%
25%
Generator Input
OUTPUT
Power factor
Rated AC Voltage
Voltage Regulation
Transient Voltage Response
Phase Balance
Frequency
Crest factor
Harmonic distortion (THD)
AC Mode
Overload Capacity
Bat. Mode
Normal mode efficiency
ECO mode efficiency
BATTERY
Battery voltage
Float Voltage
Boost Charge Voltage
End of Discharge
Charge Current(A) (charge current can be
set according to battery capacity installed)
SYSTEM FEATURES
Synchronous transfer time
Asynchronous transfer time
Alarms
Protection
Communication Interface
ENVIRONMENT
Operating Temperature
Storage Temperature
Humidity
Acoustical Noise (from 1M distance)
Altitude
PHYSICAL
Dimension W×D×H (mm)
Net weight (Kg)
STANDARDS
Safety certifications
EMC
Performance & Testing
Other
10KVA
10kVA/10kW 20kVA/20kW
10kVA/9kW 20kVA/18kW
320~480VAC @ Full load; 260~480VAC @ < 50% Load
≤ 4
≤ 6
≤ 9
≤ 20
+/-1% Balanced Load, +/-2% Unbalanced Load
1. Line Mode: synchronize with input; when input frequency >±10% (±1%/±2%/±4%/±5% optional),
output (50/60±0.1%) Hz. 2. Battery Mode:(50/60±0.1%)Hz
< 2% (linear load), <4% (nonlinear load)
Load ≤110%: last 60min change to bypass, ≤125%: last 10min, change to bypass,
≤150%: last 1min change to bypass, >150% change to bypass immediately
Load ≤110%: last 10min ≤125%: last 1min ≤150%: last 5S, >150% shut down UPS immediately
Up to 93%
10-20kVA: ±96/108/120VDC; battery quantity 16~20 pcs, Standard unit and 20 pcs no power derating;
18 pcs output power factor 0.9; 16 pcs output power factor 0.8;)
30-40kVA ±192/204/216/228/240/252/264/276/288VDC
(32/34/36/38/40/42/44/46/48pcs optional) Below 40 nos Output Power factor 0.9
2.25V/cell (selectable from 2.20-2.29V/cell) Constant current and constant voltage charge mode.
2.30V/cell (selectable from 2.30-2.40V/cell) Constant current and constant voltage charge mode
1.75 V/cell (selectable from 1.60 or 1.90V/cell)
14A
Utility to Battery : 0ms; Utility to bypass: 0ms
Asynchronous transfer: 15ms (50 Hz), 13.3ms (60 Hz)
Overload, utility abnormal, UPS fault, battery low, etc.
Short circuit, overload, over temperature, battery low, fan fault alarm.
USB, RS232, RS485, Parallel port, Dry contact, Intelligent slot, SNMP card (optional),
Relay card (optional),Battery temperature sensor(optional)
Max 65dbA at 100% load/ <55dbA at load ≤50%
< 1500m. When>1500m, lower the rated power for use
35
IEC/EN62040-2, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4,
IEC61000-4-5, IEC61000-4-6, IEC61000-4-8
20KVA 30KVA
30kVA/30kW
30kVA/27kW
380/400/415VAC, (3Ph+N+PE)
50-60Hz +/-10% autosensing
0.99
≤ 3
≤ 4
≤ 8
≤ 16
Support
1.0
380/400/415VAC, (3Ph+N+PE)
±5% (linear load)
120° ±1° (100% unbalanced load)
3:1
Up to 95%
Up to 98%
16A 18A
0°C ~ 40°C
-25°C ~ 55°C (no battery)
0 ~ 95% non-condensing
250x580x655
40 43
IEC/EN62040-1,IEC/EN60950-1
IEC/EN62040-3
RoHS
40KVA
40kVA/40kW
40kVA/36kW
20A
46
37
