After changing the parallel system ID, the connection between Muser4000 and equipment
might be interrupted. If it occurs, please re-connect in accordance with the instruction
described before.
• After setting the UPS, if it has to be paralleled, power off all the UPS. Connect all the UPS according to "parallel
cable installation", and then power on the UPS.
4.3 The LCD Display
1
1. LED (from top to bottom: "alarm", "bypass", "battery", "inverter"), 2. LCD display
Introduction
CAUTION!
CAUTION!
Parallel cable cannot be connected
when setting the parallel parameters.
Overview of the operating panel of the UPS
CAUTION!
The display provides more functions
than those described in this manual.
2
