3 INSTALLATION
3.1 Unpack checking
1. Don't lean the UPS when moving it out from the packaging.
2. Check the appearance to see if the UPS is damaged or not during the transportation, do not Switch ON the
UPS if any damage found. Please contact the dealer right away.
3. Check the accessories according to the packing list and contact the dealer in case of missing parts.
3.2 Cabinet Outlook
(Terminal block without cover)
6
Front View
10kVA Rear View
Side View
15-20kVA Rear View
(Terminal block without cover)
