Fault code
UPS Alarm Warning
(Err)
33 No Battery
Battery Under Voltage
34
(Low Battery protection)
Battery Volt Warning (Battery
35
Voltage Low)
36 Inner Communication Fault
DC Component Over Limit.
37
(Unbalance INV. DC)
38 Parallel Overload
39 Mains Volt. Abnormal
40 Mains Freq. Abnormal
41 Bypass not Available
42 Bypass Unable to Trace
43 Inverter on Invalid
4.4 Options
4.1 SNMP card:
Loosen the 2 torque screws (on each side of the card).
•
Carefully pull out the card. Reverse the procedure for re-installation.
•
USHA – acronym for UPS SNMP and HTTP Agent. It can get hold of the status from issue commands to the UPS.
User can use SNMP managers or Web browsers to manage the UPS through an Ethernet. USHA also provides
shutdown programs for different operating systems. It issues a shutdown command in the event such as mains
failure, UPS battery low condition, UPS overload and UPS over temperature. All shutdown events are configurable
by user. The shutdown software will proceed to the automatic orderly shutdown to prevent the abnormal shut-off
of the clients or servers.
SNMP Features
Real-time UPS health monitoring
•
Comprehensive UPS management and flexible configuration via Web Browser, NMS, Telnet, and SNMP
•
Automatic events notification via E-mail, and SNMP Trap
•
Graceful shutdown to protect servers/workstations from data loss due to power outage
•
Assigned IP automatically via DHCP or BOOTP
•
Regularly records UPS parameters for statistical analysis and event diagnostics
•
Standard UPS MIB and USHA-proprietary MIB supported
•
Auto-sense to works in the 10/100Mbps fast Ethernet network environment
•
Configuration utility simplifies the firmware upgrade process
•
IPv4 and IPv6 dual stake.
•
Buzzer
Once per second
Once per second
Once per second
Once per 2 seconds
Once per 2 seconds
Once per 2 seconds
Once per 2 seconds
Once per 2 seconds
LED
Battery LED blinking
Battery LED blinking
Battery LED blinking
Fault LED blinking
INV LED blinking
INV LED blinking
Battery LED lit
Battery LED lit
BPS LED blinking
BPS LED blinking
