LEGRAND NUMERIC HPi 33 EVO User Manual page 3

CONTENTS
Index
1. Safety
1.1.Safety Notes
1.2 Symbols used in this guide
2. Main Features
2.1 Summary
2.2 Functions and Features
3 Installation
3.1 Unpack checking
3.2 Cabinet Outlook
3.3 LCD control panel
3.4 Installation notes
3.5 External Protective Devices
3.6 Power Cables
3.7 Power cable connect
3.8 Battery connection
3.9 UPS parallel Installation
3.10 Computer access
4. Operation
4.1 Operation Modes
4.2 Turn on / off UPS
4.3 The LCD Display
4.4 Options
Appendix 1 Specifications
Appendix 2 Problems and Solution
Appendix 3 USB communication port definition
Appendix 4 RS232 communication port definition
Appendix 5 RS485 communication port definition
Appendix 6 BAT_T communication port definition
Appendix 7 Optional port definition
Appendix 8 REPO instruction
Pg
4
4
4
5
5
5
6
6
6
7
8
9
9
10
12
14
15
17
17
19
25
35
37
38
39
40
40
41
42
42
3
