  • Page 1 Kit Instructions Imaging Assembly 7878-K150/K152 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 Revision Record Issue Date Remarks Nov 2017 First Issue...

  • Page 4: Kit Contents

    • Phillips Screw Driver #2 • USB Flash Drive Software Tools Needed • Firmware — 497-0472618 or later versions • NCR Scanner Flash Drive Prep Tool or NCR Scanner Flash Tool Note: These tools are available for download at the NCR scanner website http://www5.ncr.com/support/support_drivers_patches.asp?Class=retail_RealScan...

  • Page 5: Installation Procedures

    Imaging Assembly Installation Procedures Warning: Disconnect the AC power cord before disassembling the Scanner. Installing the Imaging Assembly involves the following procedures: 1. Remove the Top Plate. 2. Remove the Front Bezel. 3. Remove the Tower Cover. 4. Install the Imaging Assembly. 5.
  • Page 6 Imaging Assembly Remove the Top Plate 1. Hold the front edge of the Top Plate until your fingers are underneath it. 2. Lift the Top Plate to remove it from the Scanner. 3. If the Scanner is in a Checkstand, remove the Scanner by grasping the back of the Tower Cover with one hand and the Debris Guard with the other hand.

  • Page 7: Remove The Front Bezel

    Imaging Assembly Remove the Front Bezel 1. Place one hand and slightly apply pressure on the top corner of the Front Bezel and use the other hand to pull the snap features at the bottom. Note: The Front Bezel snaps onto the Tower Cabinet. 2.
  • Page 8 Imaging Assembly Remove the Tower Cover The Tower Cover covers the Vertical Optics Assembly. It is fastened to the 7878 Mounting Bracket without screws. 1. Depress the two tabs at the top of the Tower Cover to disengage the snap features. 2.
  • Page 9 Imaging Assembly Install the Imaging Assembly 1. Remove the Blank Plate that is found at the back of the Optics Assembly. a. Remove the two Phillip screws indicated in the above image. Note: Set aside the screws as they are needed upon installation of the Imager kit. b.
  • Page 10 Imaging Assembly 2. Holding the Imager, route the Scanner USB Cable along the cable retaining frame and through the top notch. 3. Insert the Imager Mount on the Optics Assembly, starting with the bottom part of the mount.
  • Page 11 Imaging Assembly 4. Align the holes of the Imager Mount with the mounting holes of the Optics Assembly. 5. Secure the Imager Mount to the back of the Optics Assembly. a. Insert the screw to the right mounting hole. Do not tighten yet. b.
  • Page 12 Imaging Assembly 6. Route the Imager USB cable through the cable guide on the Optics Assembly, and then connect the Imager USB cable to the lower rear–facing tower USB peripheral port on the Tower Board. Install Tower Cover 1. Place the Tower Cover down onto the Inner Tower. Note: Ensure that no wires or cables are pinched between the Tower Cover and the unit.
  • Page 13 Imaging Assembly Install the New Hybrid Front Bezel 1. Align the top edge of the Tower Cabinet with the top edge of the New Hybrid Front Bezel. 2. Apply pressure on the bottom-left and bottom-right corners of the New Hybrid Front Bezel to latch it in place.
  • Page 14 Imaging Assembly 3. Connect the external cables to the Scanner. 4. If applicable, install the Scanner to the Checkstand. Grasp the back of the Tower Cover with one hand and the Debris Guard with the other hand, and then lower down the Scanner into the Checkstand.
  • Page 15 Imaging Assembly Install the Top Plate 1. Lower the back edge of the Top Plate onto the two back Support Posts on the Scanner. 2. Holding the front edge, lower the front of the Top Plate onto the two front Support Posts.

  • Page 16: Programming Procedures

    Imaging Assembly Programming Procedures Programming the Imaging Assembly and the 7878 scanners involves the following procedures: 1. Identify the 7878 scanner firmware version. 2. If needed, re–flash the required firmware to the 7878. 3. Program the 7878 for the Imager Module. 4.
  • Page 17 Imaging Assembly Identify the Firmware Version of 7878 1. Scan the Diagnostic Mode, Hex 4, and Hex A programming tags. The 7878 then speaks the 497–xxxxxxx number of its firmware. Note: The Diagnostic Mode, Hex 4, and Hex A programming tags must be the first tags scanned after applying power to the unit.
  • Page 18 2. Connect the scanner to the host terminal using an RS-232 cable or USB cable appropriate for 7878 scanner. • RS232 cable — part number 497-0300422 (1416-C019-004) • USB cable — 497-0445079 (1432-C158-0040) 3. Run Flash Tool by double–clicking the NCR Flash Tool icon on the desktop.
  • Page 19 Imaging Assembly 4. Port settings must be configured first before flashing firmware to the scanner. Select Port Settings in the main window and select the Modify INI button.
  • Page 20 Imaging Assembly 5. Select one of the radio buttons under the Communications Protocol Group within the Port Settings tab. For RS-232 communication protocol, you can configure more settings under the RS-232 Settings group. Right-click one of the cells in the table to either change the parameter value or restore it to its default value.
  • Page 21 Imaging Assembly 8. After configuring the necessary port settings, choose the scanner where you want to flash the firmware. 9. Select Modify INI after a scanner model has been chosen. Select the Update Firmware checkbox and choose the firmware BIN file you want to flash to the scanner.
  • Page 22 When initialization is successful, a window that shows the progress of the flashing process is displayed. 12. After firmware flashing is finished, exit the NCR Flash Tool application and disconnect the scanner from the host terminal.
  • Page 23 Imaging Assembly Firmware Flashing using a USB Flash Drive In order to minimize the need for a PC at the scanner site, the Flash Drive Prep Tool preps a flash drive so that the scanner could understand its contents and performs the tasks defined inside the device prepared by the host terminal software.
  • Page 24 Imaging Assembly 4. Select OK. The following window is displayed. 5. On the Target Scanner tab, select 7878. 6. On the FIRMWARE groupbox, select the checkbox under Update scanner with:. 7. Select the Firmware from the dropdown menu. 8. Select the Prep Flash Drive button. The application then preps the flash drive. The following message box is displayed after a successful flash drive prep.
  • Page 25 Imaging Assembly 9. Right–click the Safely Remove Hardware icon on the system tray to safely remove the flash drive. A Safe to Remove Hardware balloon message is displayed near the system tray. 10. Plug the flash drive in the scanner's USB peripheral port. The following lists the different actions the scanner initiates: a.
  • Page 26 Imaging Assembly Program the 7878 for the Imager Module The 7878 scanner must be programmed so it can perform the following: • Beep whenever 7878 receives valid bar code data from the Imager module through the USB host port; by default, the scanner does not beep when the Imager receives bar codes.
  • Page 27 Imaging Assembly 2. Activate the beeps sounds during the HH input by scanning the Hex 4, Hex 0, and Hex 5 tags.
  • Page 28 Imaging Assembly 3. Enable 2D bar codes pass–through by scanning the Hex 7, Hex F, and Hex 9 tags.
  • Page 29 Imaging Assembly 4. Enable the Imager kit by scanning the Hex 8, Hex B, and Hex 1 tags.
  • Page 30 5. Enable 2D pass–through function of all 2D types by scanning the Save and Reset tag. Note: The passed–through PDF data is transmitted in ASCII format when RS232 Serial or NCR USB is used. This data format is required by NCR OPOS for 2D bar codes.
  • Page 31 • The Imager flickers when it successfully reads an Enable symbology bar code. • Check if the symbologies are successfully read by scanning the bar codes in Sample 2D Bar Codes on page 30. Note: For advanced configurations, see NCR 7878‐K150/F150 Imaging Module User Guide (B005‐0000‐2166) on https://info.ncr.com/POSGen.
  • Page 32 Imaging Assembly Enable other Bar Code Symbologies Note: The Enable QR Code bar code also enables MicroQR.
  • Page 33 Imaging Assembly Sample 2D Bar Codes...
