Summary of Contents for The Splash Lab TSL.467
- Page 1 TSL.467 Wall Mounted Soap Dispenser...
- Page 2 Safety and warnings Box contents Technical data Before you Iistall Technical drawing How to install Commisioning Operation / maintenance / cleaning Troubleshooting Warranty Back cover Contact details 2 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL...
- Page 3 Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer (see back page for details). General information info.uk@thesplashlab.com +44 (0) 161 482 7000 Technical support info.uk@thesplashlab.com/uk For further contact information visit: www.thesplashlab.com/uk 3 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL...
-
Page 4: Box Contents
Anti rotation washer Base collar Power supply unit (PSU) Soap foaming chamber pipe set Soap supply pipe / 10 feet Soap reservoir Hex wrench Soap foamer pump unit Wall mounting bracket for pump 4 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL... -
Page 5: Technical Data
Overview The TSL.467 is a stainless steel wall mounted soap dispenser, available in a variety of coloured finishes, with a sleek minamalist design. Codes Power TSL.467.CS Mains Brushed Stainless Steel TSL.467.CP Mains Brushed Copper TSL.467.BK Mains Brushed Black TSL.467.BR... - Page 6 Max range 400mm Min range 600mm Sensor type Infrared Response time (max) < 300ms Security cut-off time 30 seconds Connection to sensor cable 1700mm Connection to fused supply 1780mm 6 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL...
-
Page 7: Before You Install
Installation Requirements Installation Requirements The TSL.467 is normally mounted in the wall panelling above a basin or counter-top. As a guide we would recommend that a minimum distance of 100mm between the dispenser and any adjacent tap, but this is ultimately only a guide measurement. -
Page 8: Technical Drawing
254mm Power supply 8 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL... -
Page 9: How To Install
Drill 18mm diameter hole through the surface for installation. mounting surface and into the wall cavity. Slide the collar over the spigot. Slot the spigot end of the dispenser through the pre-drilled hole. 9 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL... - Page 10 2 soap foamer pump, and the power supply pipe fittings on the top of the soap foamer unit. cables Then connect soap pick-up pipe on unit and the opposite in reservoir. 10 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL...
-
Page 11: Access Information
10cPs. It is not suitable for use with liquid or pearl soap, alcohol gels or hand sanitisers. access information Access Requirements It is critical all components which require fixing behind the wall are easily accessible at all times during installation and routine maintenance 11 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL... -
Page 12: Operation
If further information is required, contact The Splash Lab technical team for more detailed stainless steel care guidelines. -
Page 13: Troubleshooting
If this is not possible, the sensor range can be adjusted as described in ‘Resetting the sensor’ We are always looking to improve. If these steps did not solve your problem please contact us and we will endeavour to help. +44 (0)161 482 7000 info.uk@thesplashlab.com 13 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL... -
Page 14: Warranty
TSL.467 Wall-mounted Soap Dispenser 1 year limited warranty If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replace- ment part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. - Page 15 General information info.uk@thesplashlab.com +44 (0)161 482 7000 Unit 34, Meadow Industrial Estate, Water Street Stockport SK1 2BU United Kingdom Technical support info.uk@thesplashlab.com For further information visit: www.thesplashlab.com/uk 15 + TSL.467 WALL-MOUNTED SOAP DISPENSER INSTALL MANUAL...
