Page 2
Safety and Warnings Box Contents Technical Data Before You Install How to Install Operation Maintenance Cleaning Troubleshooting Diagram Warranty Back Cover Contact Details 2 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
Page 3
General information 310 410 5008 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 3...
6V Type AA x 4 pcs Alkaline (not included) Standby power Weight 2lb16oz (1.4kg) Material 304stainlesssteel Sensor range 5-29/32"±19/32" (150±20mm) Foam soap: - <10cPs Recommended soap viscosity Approvals CE, RoHS, ADA Warranty 1 year parts and labor TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 5...
6" (152mm) to the left of the Faucet, which is at the center. The dryer shoudl be Basins 8" (200mm)to the right of the Faucet. Use of a The Splash Lab Monolith basin isrecommendedforusewiththeRibbon rangeofproducts Ifanalternativebasin isused, then appropriatemountingpoints...
Page 7
FRONT SIDE 6-27/64" (163mm) 4-11/64" (106mm) Sensor Range Ø 1 3/8" (35mm) 5-29/32" " (9.5mm) THROUGH HOLE 1-3/8 (150mm) " (35mm) Ø 1-1/4" (32mm) 2 -23/32" (69mm) TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 7...
Drill hole 1 3/8" (35mm) diameter in Fit anti-rotation washer from below basin. vanity top, if not already cut. 8 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
Page 9
Position the mounting template at a place where the soap tube can reach the gray circle on the mounting template to find the best place to install the control box and the supporting bracket. TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 9...
Page 10
Then drill 3 holes [size:1/4" (6mm)] box assembly can hang properly. and put the 3 wall plugs in the holes. 10 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
Page 11
Pull up the soap pump, fill in the liquid soap hung on the wall, fasten the third screw and then push down the soap pump until into the bottom wall plug. you hear it snap into place. TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 11...
Page 12
Plug-in an AC adapter or battery box to supply power. Installation finished. *To use power mains as the power source, do not place batteries in the battery compartment. 12 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
The soap dispenser should be serviced on a regular basis to ensure long service lifeoftheunit. Isolate the unit from the power supply before any servicing or maintenance work is carriedout. The dispenser should be activated at least once a day to ensure that soap does notcongealinthepipework. TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 13...
Page 14
If further information is required, contact The Splash Lab Team for more detailed stainless-steel care guidelines. 14 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
Remove the obstruction or cause of reflection. We are always looking to improve. If these steps did not solve your problem please contact us and we will endeavor to help. Tel: 310 410 5008 Email: info@thesplashlabusa.com TSL.R.010 RIBBON SOAP DISPENSER MANUAL + 15...
Page 16
Dispenser head assembly Soap foaming pipe Soap reservoir - 0.4 gallons (1500ml) Soap foamer pump unit Power supply unit 16 + TSL.R.010 RIBBON SOAP DISPENSER MANUAL...
The Splash Lab will warrant that its products will be free of manufacturing and material defectsduringnormaluseandenvironmentalconditionsasdetailedbelow: Ribbon Collection 1 year parts & labor If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide areplacementpartorproduct, ormakeappropriateadjustments.Damagecausedby accident,misuse,orabuseisnotcoveredbythiswarranty.Impropercareandcleaning willvoidthewarranty.
Page 20
contact General information 310 410 5008 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com...
