- Page 1 TSL.420 deck mounted soap dispenser...
- Page 2 Safety and Warnings Box Contents Diagram Technical Data Before You Install Dimensions How To Install Commissioning & Operation Cleaning & Soap Maintenance & Refilling Troubleshooting Warranty Contact Details TSL.420 MANUAL...
- Page 3 Read and save these instructions WARNING Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer (see back page for more details) For more information contact: Tel: +44 (0)161 482 7000 Email: technical@thesplashlab.com TSL.420 MANUAL...
-
Page 4: Box Contents
Dispenser head assembly Fixing nut Anti rotation washer O ring Base collar Soap reservoir Soap supply pipe - 3 metres Power Supply Unit (PSU) Soap foamer pump unit Pump unit mounting bracket Soap foaming chamber pipeset TSL.420 MANUAL... - Page 5 Dispenser head assembly Power Supply Unit (PSU) Base collar Pump unit mounting bracket O ring Soap reservoir Anti rotation washer Fixing nut Soap foaming chamber pipeset Soap foamer pump unit TSL.420 MANUAL...
-
Page 6: Technical Data
Overview The TSL.420 is a stainless steel deck mounted soap dispenser, available in a variety of coloured finishes.. Codes Power Finishes TSL.420.CS Mains Brushed Stainless Steel TSL.420.CP Mains Brushed Copper TSL.420.BK Mains Brushed Black TSL.420.BR Mains Brushed Brass TSL.420.BZ... - Page 7 Sensor range Preset 70mm (adjustable using seperate controller if required) Max range 400mm Min range 60mm Sensor type Infrared Response time (max) < 300ms Security cut-off time 30 seconds Connection to sensor cable 1700mm Connection to fused supply 1780mm TSL.420 MANUAL...
-
Page 8: Before You Install
Installation Requirements The soap dispenser is intended to be mounted in a countertop or basin adjacent to a tap. As a guide, The Splash Lab recommends a minimum distance of 100mm between the dispenser and a tap. The TSL.420 is supplied with a single-feed reservoir to be connected with a flexible feed-pipe to the dispenser. -
Page 9: Technical Drawing
technical drawing Ø30 Sensor Lead Connectors Foaming Tube Set Sensor Lead Run Time and Prime Adjustment PRIME 1Ltr Soap Pump Bottle Housing PSU Lead to Spur Soap "Pick-up" Pipe - 3m TSL420 MANUAL... -
Page 10: How To Install
how to install Soap Installation Mark soap hole centres onto the surface Drill 25mm diameter hole in countertop. for installation. Insert dispenser through hole in basin or Fix anti-rotation washer from below the countertop with the stainless steel bezel basin. above the counter. - Page 11 Fit the fixing nut, and ensure that this is Mark wall in desired location for pump secure using a spanner. mounting bracket . Fit the pump bracket using appropriate Fit the soap foamer pump unit to the fixings. bracket TSL.420 MANUAL...
- Page 12 WARNING: Ensure all connections are fully tightened to ensure full seal of the soap. TSL.420 MANUAL...
-
Page 13: Operation
+ The user places their hands within detection range of the sensor to activate the soap dispenser. + The motor will start and soap is dispensed onto the user’s hands. + The motor will stop when the user’s hands are removed from the detection range. TSL.420 MANUAL... - Page 14 Use a soft cloth or sponge with a mild solution of soapy water as part of the regular washroom janitorial routine. Do not use abrasive or cream cleaners as these will damage the surface finish. If further information is required, contact The Splash Lab technical team for more detailed stainless steel care guidelines. soap A good quality foam soap of viscosity <10 cPs units should be used.
-
Page 15: Maintenance
If it does happen that the soap level is allowed to fall below the minimum required, there will be an airlock introduced into the pipe, which will then need to be re-primed. Priming of the system is achieved by pressing the prime button on the pump unit. TSL.420 MANUAL... -
Page 16: Troubleshooting
(remove the pupm unit from the wall bracket to make the change) Dispenser runs constantly Sensor is detecting an object or reflection Remove the obstruction or cause of refelction TSL.420 MANUAL... -
Page 17: Warranty
TSL.420: 2 years parts & labour If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 18 General information info@thesplashlab.com +44 (0) 161 482 7000 Technical support technical@thesplashlab.com For further contact information visit: www.thesplashlab.com TSL.420 MANUAL...
- Page 19 TSL.420 MANUAL...
