- Page 1 TSL.420 Sensor Deck Mounted Soap Dispenser...
- Page 2 Safety and warnings Box contents Technical data Before you install How to install Operation / maintenance / cleaning Commissioning Troubleshooting Warranty Back cover Contact details 2 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
- Page 3 Ensure wiring and cover is installed correctly before connecting to live power supply. If in doubt, consult an electrician. General information info.uk@thesplashlab.com +44 (0) 161 482 7000 Technical support info.uk@thesplashlab.com For further contact information visit: www.thesplashlab.com/uk 3 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
-
Page 4: Box Contents
Soap supply pipe / 10 feet Fixing nut Soap reservoir Anti rotation washer Hex wrench Base collar Soap foamer pump unit Power Supply Unit (PSU) Wall mounting bracket for pump Soap foaming chamber pipe set O-ring 4 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL... - Page 5 Overview The TSL.420 is a stainless steel deck mounted sensor soap dispenser, available in a variety of coloured finishes. Codes Finishes TSL.4.20CS Brushed Stainless Steel TSL.420CP Brushed Copper TSL.420.BK Brushed Black TSL.420.BR Brushed Brass TSL.420.BZ Brushed Bronze Input: 100-240V ac; 50/60Hz Power supply - Mains Output: 6V DC;...
- Page 6 The Splash Lab recommends a minimum distance of 100mm between the dispenser and a tap. The TSL.420 is supplied with a single-feed reservoir to be connected with a flexible feed- pipe to the dispenser. If a multifeed system is required, this needs to be specified separately.
- Page 7 95mm Ø30mm SIDE 254mm Power supply 7 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
- Page 8 Fix anti-rototation washer from below the basin countertop with the stainless steel bezel above the countertop. Ensure the rubber 0-ring is placed onto the spigot before inserting the unit through the countertop 8 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
- Page 9 2 soap foamer pump, and the power supply pipe fittings on the top of the soap foamer unit. cables Then connect soap pick-up pipe on unit and the opposite in reservoir. 9 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
- Page 10 2 pipe fittings on the top of the soap the power supply cables. foamer unit. 10 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
-
Page 11: Operation
Do not use steel brush or abrasive that could scratch the spouts Best care for PVD Finishes You can clean the PVD finished spouts with a damp cloth and water. Do not use cleaning solution or liquid alcohol 11 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL... - Page 12 The dispenser is only to be used with a compatible foam soap, with a viscosity of less than 10cPs. It is not suitable for use with liquid or pearl soap, alcohol gels or hand sanitisers. 12 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
-
Page 13: Troubleshooting
If this is not possible, the sensor range can be adjusted as described in ‘Resetting the sensor’ We are always looking to improve. If these steps did not solve your problem please contact us and we will endeavour to help. +44 (0)161 482 7000 info.uk@thesplashlab.com 13 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL... -
Page 14: Warranty
TSL.420 Deck-mounted Soap Dispenser 1 year limited warranty If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replace- ment part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. - Page 15 General information info.uk@thesplashlab.com +44 (0)161 482 7000 Unit 34, Meadow Industrial Estate, Water Street Stockport SK1 2BU United Kingdom Technical support info.uk@thesplashlab.com For further information visit: www.thesplashlab.com/uk 15 + TSL.420 DECK-MOUNTED SENSOR SOAP DISPENSER INSTALL MANUAL...
