Summary of Contents for The Splash Lab TSL.C041
- Page 1 TSL.C041 channel soap dispenser +"' +THE +"' SPLASH +"'...
- Page 2 Safety and Warnings Box Contents Technical Data Before You Install How to Install Operation Spare parts Maintenance & Cleaning Troubleshooting Diagram Warranty Back Cover Contact Details 2 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL...
- Page 3 Ensure wiring and cover is installed correctly before connecting to live power supply. If in doubt, consult an electrician. General information lnfo.uk@thesplashlab.com + 44 (0) 161 482 7000 Technical support lnfo.uk@thesplashlab.com For further contact information visit: www.thesplashlab.com TSL.C041 CHANNEL SOAP DISPENSER MANUAL+ 3...
-
Page 4: Box Contents
Dispenser head assembly Pad (already installed) Gasket Washer Fixing nut Soap foaming pipe - 1000mm Soap reservoir - 1500ml Hex wrench/ Soap outlet Soap foamer pump unit Power supply unit 4 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL... -
Page 5: Technical Data
Finishes TSL.C041.C Bright Polished TSL.C041.CS Brushed Stainless TSL.C041.CP Brushed Copper TSL.C041.BK Brushed Black TSL.C041.BR Brushed Brass TSL.C041.BZ Brushed Bronze Power supply - Mains Input: 100-240V ac; 50/60Hz Output: 6V DC; 1.5A, 9W max Power supply - Battery 6V Type AA x 4 pcs Alkaline (not included) (Optional) -
Page 6: Before You Install
If an alternative The Channel Dryer should be 250mm to the basin is used, please confirm with right of the Tap. The Splash Lab that there will be no reflection or splash issue. Backplate The Splash Lab offers an optional backplate... - Page 7 50mmMAX 10mm MIN 163mm (l)50mm �r c< ,� ,__l � 020mm� Sensor/ Range 70±15mm soap foaming pipe � Mains ,p'�A- 117.4mm 128.5mm installation depth 170mm MIN TSL.C041 CHANNEL SOAP DISPENSER MANUAL+ 7...
-
Page 8: How To Install
Drill hole 22mm diameter in wall dispenser body into the 22mm hole in wall. 200-250mm above the bottom of the basin. 8 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL... - Page 9 Place Mounting template on the wall pipe through the gasket, washer and below the basin or behind the UT wall fixing nut. Tighten the nut against to find the best position for installing. the installation wall. TSL.C041 CHANNEL SOAP DISPENSER MANUAL+ 9...
- Page 10 Then drill 3 holes (size: 8mm) assembly can hang properly. and put the 3 wall plugs, included in kit, in the holes. Contractor may use other size. 10 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL...
- Page 11 When the control box assembly has been Pull up the soap pump, fill in the foam soap hung on the wall, fasten the third screw and then push down the soap pump until into the bottom wall plug. you hear it snap into place. TSL.
- Page 12 AC power wire from the control box. The life cycle of the soap dispenser based on using batteries as the power source is about 15,000 cycles. 12 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL...
-
Page 13: Operation
Should a replacement mains power supply be required it is imperative that an identical type is used. Contact The Splash Lab for further information. TSL. C 041 CHANNEL SOAP DISPENSER MANUAL+ 13... -
Page 14: Maintenance And Cleaning
Do not use steel brush or abrasive that could scratch the spouts. Best care for PVD Finishes You can clean the PVD finished spouts with a damp cloth and water. Do not use cleaning solution or liquid alcohol. 14 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL... -
Page 15: Troubleshooting
troubleshooting If the dispenser will not run Ensure there is power to the dispenser and the wire from the fuse spur is connected correctly to the pump motor. Check that the sensor cables are fully connected to the corresponding cables from the foam pump unit. - Page 16 Dispenser head assembly Soap foaming pipe - 1000mm Soap reservoir - 1500ml Soap foamer pump unit Power supply unit • • 16 + TSL.C041 CHANNEL SOAP DISPENSER MANUAL...
-
Page 17: Warranty
One year limited warranty + If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 20 contact General information lnfo.uk@thesplashlab.com +44 (0) 161 482 7000 Technical support I nfo.uk@thesplashlab.com 1i2' For further contact information visit: ::::, www.thesplashlab.com LJ.J ::i'...
