- Page 1 TSL-470 soap dispenser...
- Page 2 Box Contents Technical Data Before You Install How to Install Commissioning Operation Maintenance Cleaning Soap Refilling Warranty Contact Details TSL-470 SOAP DISPENSER MANUAL...
-
Page 3: Box Contents
Recommended soap system L-ST series, to be specified separately Feed pipe connection 8mm push-fit connector to L-ST series feed system Tested to 2,000,000 depressions Standard discharge 0.03 fl oz TSL-470 SOAP DISPENSER MANUAL... -
Page 4: Before You Install
NOTE: The L470 soap dispenser needs to be used with one of The Splash Lab’s Liquid soap feed systems listed below (to be specified separately) LMT1 Single feed soap system –... -
Page 5: How To Install
1" open-ended wrench how to install Mark the dispenser position and drill Assemble the wall flange to the 11/16" Ø hole to accept the brass dispenser ensuring the finished face will dispenser tail. not be against the wall. TSL-470 SOAP DISPENSER MANUAL... - Page 6 Insert the pipe-barb into firmly lock the nuts together. Ensure you the PVC hose, and this connector can maintain the correct orientation of the then be pressed into the previously fitted dispenser during this operation. elbow connector. TSL-470 SOAP DISPENSER MANUAL...
-
Page 7: Operation
The cap is depressed by the user, which draws a measured amount of soap 0.03 fl oz along the feed pipe from the reservoir, then through the pump, and the soap is dispensed from the spout onto the user’s hands. TSL-470 SOAP DISPENSER MANUAL... -
Page 8: Maintenance
A good quality liquid soap of viscosity 100 – 3800 cPs units should be used. Hand cleaners containing abrasive particles should not be used as this will cause damage to the pump mechanism. The dispenser mechanism is not compatible with alcohol gels or hand sanitisers. TSL-470 SOAP DISPENSER MANUAL... - Page 9 Priming of the system is achieved by depressing the pump until soap is dispensed consistently. THE SOAP DISPENSERS CONTAIN NO USER-SERVICABLE PARTS. TSL-470 SOAP DISPENSER MANUAL...
-
Page 10: Warranty
Soap & paper dispensers 1 year If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. - Page 11 General information info@thesplashlab.com +1 310 410 5008 Technical support technical@thesplashlab.com For further contact information visit: www.thesplashlab.com TSL-470 SOAP DISPENSER MANUAL...
