Cincoze CS-W115FHC/P1301 Series User Manual

Sunlight readable panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CS-100/P1301 Series
User Manual
Power Efficient Sunlight Readable Industrial Panel PC
8.4"~24" TFT-LCD Sunlight Readable Panel PC with Intel® Alder Lake-N
Series Processor
Version: V1.23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-W115FHC/P1301 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze CS-W115FHC/P1301 Series

Summary of Contents for Cincoze CS-W115FHC/P1301 Series

  • Page 1 CS-100/P1301 Series User Manual Power Efficient Sunlight Readable Industrial Panel PC 8.4”~24” TFT-LCD Sunlight Readable Panel PC with Intel® Alder Lake-N Series Processor Version: V1.23...

  • Page 2: Table Of Contents

    1.2.1 CS-108C/P1301 Series ....................... 16 1.2.2 CS-110HC/P1301 Series ......................21 1.2.3 CS-112HC/P1301 Series ......................26 1.2.4 CS-115C/P1301 Series ....................... 31 1.2.5 CS-W115FHC/P1301 Series ....................... 36 1.2.6 CS-117C/P1301 Series ....................... 41 1.2.7 CS-119C/P1301 Series ....................... 46 1.2.8 CS-W121C/P1301 Series ......................51 1.2.9 CS-W124C/P1301 Series ......................
  • Page 3 Chapter 3 System Setup ........................73 3.1 Removing Top Cover ......................74 3.2 Installing SO-DIMM Memory ....................75 3.3 Installing M.2 Key B Card ...................... 76 3.3.1 M.2 Key B type 3052 ......................... 76 3.3.2 M.2 Key B type 3042 ......................... 77 3.4 Installing M.2 Key E Card ......................
  • Page 4 4.6 Boot Setup .......................... 113 4.7 Save & Exit .......................... 114 Chapter 5 Product Application ......................115 5.1 Where to download drivers? ..................... 116 5.2 Where to find the technical documents? ................116 CS-100/P1301 Series | User Manual...

  • Page 5: Preface

    2025/03/20 Copyright Notice © 2024 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    Conventions Used in this Manual This indication alerts operators to an operation that, if not strictly observed, may result in severe injury. (Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement observée, peut entraîner des blessures graves.) This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment.

  • Page 9: Package Contents

    qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: ⚫ The power cord or plug is damaged. ⚫ Liquid has penetrated into the equipment. ⚫ The equipment has been exposed to moisture. ⚫...

  • Page 10: Ordering Information

    Ordering Information Available Models Model No. Product Description 8.4“ TFT-LCD 1600nits Sunlight Readable Touch Panel PC CS-108C /P1301-i3 with Intel® Core i3-N305 Octa Core Slim Embedded Computer and P-Cap. Touch 8.4“ TFT-LCD 1600nits Sunlight Readable Touch Panel PC CS-108C /P1301-N97 with Intel®...
  • Page 11 15.6" TFT-LCD 1200 nits Full HD Sunlight Readable Display CS-W115FHC/P1301-N97 Modular Panel PC with Intel® Processor N97 Quad Core Slim Embedded Computer and P-Cap. Touch 15.6" TFT-LCD 1200 nits Full HD Sunlight Readable Display CS-W115FHC/P1301-X7425E Modular Panel PC with Intel® Atom® x7425E Quad Core Slim Embedded Computer and P-Cap.
  • Page 12 24“ TFT-LCD 1500nits Sunlight Readable Touch Panel PC CS-W124C /P1301-N97 with Intel® Processor N97 Quad Core Slim Embedded Computer and P-Cap. Touch 24“ TFT-LCD 1500nits Sunlight Readable Touch Panel PC CS-W124C /P1301-X7425E with Intel® Atom® x7425E Quad Core Slim Embedded Computer and P-Cap.

  • Page 13: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CS-100/P1301 Series | User Manual...

  • Page 14: Overview

    • Front Panel IP65 Compliant • Designed with Rugged Aluminum Die-casting Front Bezel • Supports Panel / VESA / Rack Mount • Supports Cincoze Patent CDS Technology (Patent No. M482908) AI & Multitasking Performance The CS-100/P1301 is equipped with an Intel Alder Lake-N quad-core processor based on the Intel®...
  • Page 15 Complete Product Portfolio The CS-100/P1301 series offers a variety of display options, with screen sizes from 8.4 to 24 inches, support for up to full HD resolution, high brightness up to 1,800 nits, and multi-point P-Cap touchscreen, which can be selected according to application needs.

  • Page 16: Specifications

    1.2 Specifications 1.2.1 CS-108C/P1301 Series Model Name CS-108C Display • 8.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 1600 Brightness (cd/m2) • 600 : 1 Contrast Ratio • 16.2M LCD Color • 0.213 (H) x 0.213 (V) Pixel Pitch •...
  • Page 17 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom®...
  • Page 18 Other Function • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 19 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 20 Dimension CS-108C/P1301 Unit: mm CS-100/P1301 Series | User Manual...

  • Page 21: Cs-110Hc/P1301 Series

    1.2.2 CS-110HC/P1301 Series Model Name CS-110HC Display • 10.4" (4:3) LCD Size • 1024 x 768 Max. Resolution • 1500 Brightness (cd/m2) • 1000 : 1 Contrast Ratio • 16.2M LCD Color • 0.206 (H) x 0.206 (V) Pixel Pitch •...
  • Page 22 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 23 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 24 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 25 Dimension CS-110HC/P1301 Unit: mm CS-100/P1301 Series | User Manual...

  • Page 26: Cs-112Hc/P1301 Series

    1.2.3 CS-112HC/P1301 Series Model Name CS-112HC Display • 12.1" (4:3) LCD Size • 1024 x 768 Max. Resolution • 1500 Brightness (cd/m2) • 700 : 1 Contrast Ratio • 16.7M LCD Color • 0.24 (H) x 0.24 (V) Pixel Pitch •...
  • Page 27 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 28 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 29 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 30 Dimensions CV-112H/P1301 unit: mm CS-100/P1301 Series | User Manual...

  • Page 31: Cs-115C/P1301 Series

    1.2.4 CS-115C/P1301 Series Model Name CS-115C Display • 15" (4:3) LCD Size • 1024 x 768 Max. Resolution • 1800 Brightness (cd/m2) • 800 : 1 Contrast Ratio • 16.2M LCD Color • 0.297 (H) x 0.297(V) Pixel Pitch • 160 / 150 Viewing Angle •...
  • Page 32 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 33 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 34 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze’s website. CS-100/P1301 Series | User Manual...
  • Page 35 Dimensions CS-115C/P1301 unit : mm CS-100/P1301 Series | User Manual...

  • Page 36: Cs-W115Fhc/P1301 Series

    1.2.5 CS-W115FHC/P1301 Series Model Name CS-W115FHC Display • 15.6" (16:9) LCD Size • 1920 x 1080 (Full HD) Max. Resolution • 1,200 Brightness (cd/m2) • 800 : 1 Contrast Ratio • 16.7M LCD Color • 0.17925 (H) x 0.17925 (V) Pixel Pitch (mm) •...
  • Page 37 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 38 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 39 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze’s website. CS-100/P1301 Series | User Manual...
  • Page 40 Dimensions CS-W115FHC/P1301 unit : mm CS-100/P1301 Series | User Manual...

  • Page 41: Cs-117C/P1301 Series

    1.2.6 CS-117C/P1301 Series Model Name CS-117C Display • 17” (5:4) LCD Size • 1280 x 1024 Max. Resolution • 1500 Brightness (cd/m2) • 800 : 1 Contrast Ratio • 16.7M LCD Color • 0.264 (H) x 0.264 (V) Pixel Pitch •...
  • Page 42 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 43 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 44 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 45 Dimensions CS-117C/P1301 unit: mm CS-100/P1301 Series | User Manual...

  • Page 46: Cs-119C/P1301 Series

    1.2.7 CS-119C/P1301 Series Model Name CS-119C Display • 19" (5:4) LCD Size • 1280 x 1024 (SXGA) Max. Resolution • 1600 Brightness (cd/m2) • 1000 : 1 Contrast Ratio • 16.7M LCD Color • 0.294 (H) x 0.294 (V) Pixel Pitch •...
  • Page 47 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 48 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 49 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 50 Dimensions CS-119C/P1301 unit: mm CS-100/P1301 Series | User Manual...

  • Page 51: Cs-W121C/P1301 Series

    1.2.8 CS-W121C/P1301 Series Model Name CS-W121C Display • 21.5” (16:9) LCD Size • 1920x1080 (Full HD) Max. Resolution • 1000 Brightness (cd/m2) • 5000 : 1 Contrast Ratio • 16.7M LCD Color • 0.24825 (H) x 0.24825 (V) Pixel Pitch •...
  • Page 52 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 53 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 54 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 55 Dimensions CS-W121C/P1301 unit: mm CS-100/P1301 Series | User Manual...

  • Page 56: Cs-W124C/P1301 Series

    1.2.9 CS-W124C/P1301 Series Model Name CS-W124C Display • 24” (16:9) LCD Size • 1920x1080 Max. Resolution • 1500 Brightness (cd/m2) • 5000 : 1 Contrast Ratio • 16.7M LCD Color • 0.27675 (H) x 0.27675 (V) Pixel Pitch • 178/178 Viewing Angle •...
  • Page 57 Model Name P1301 System • Onboard Intel® Alder Lake-N Series Processor: - Intel® Core™ i3-N305 8 Cores Up to 3.80 GHz, TDP 15W Processor - Intel® Processor N97 4 Cores Up to 3.60 GHz, TDP 12W - Intel Atom® x7425E 4 Cores Up to 3.40 GHz, TDP 12W •...
  • Page 58 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 59 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CS-100/P1301 Series | User Manual...
  • Page 60 Dimensions CS-W124C/P1301 unit: mm CS-100/P1301 Series | User Manual...

  • Page 61: External Layout

    1.3 External Layout 1.3.1 Front 1.3.2 Rear CS-100/P1301 Series | User Manual...

  • Page 62: Left

    1.3.3 Left 1.3.4 Right CS-100/P1301 Series | User Manual...

  • Page 63: Chapter 2 Introduction To Switches & Connectors

    Chapter 2 Introduction to Switches & Connectors CS-100/P1301 Series | User Manual...

  • Page 64: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View CS-100/P1301 Series | User Manual...

  • Page 65: Switches And Connectors Definition

    2.2 Switches and Connectors Definition Location Definition AT_ATX1 AT / ATX Power Mode Switch BAT1 RTC Battery Holder BL_DN1 Backlight Decrease Button BL_PWR1 Backlight Power on/off Button BL_UP1 Backlight Increase Button CAP_PH1 CAP Board to Board Connector CLR_CMOS1 Clear CMOS Switch M.2 Key B Socket (Support PCIE/USB3.0/ SATA interface) COM1_1 / COM2_1 DB9 Connectors, support RS232 / RS422 / RS485...

  • Page 66: Definition Of Switches

    2.3 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Switch Definition Left AT Power Mode Right ATX Power Mode (Default) BL_DN1: Backlight Brightness Decrease Switch Definition Push Backlight Decrease BL_PWR1: Backlight Power on / off Switch Definition Push Backlight Power on / off switching BL_UP1: Backlight Brightness Increase Switch...
  • Page 67 PWR_SW1: System Power Button Switch Definition Push Power up the System RESET1: Reset Button Switch Definition Push Reset System SW1: Super CAP SW Location Function DIP1 DIP2 Super CAP Enabled ON (Default) ON (Default) Super CAP Disabled SW3: Power Select for COM1/COM2 Location Function DIP1...

  • Page 68: Definition Of Connectors

    2.4 Definition of Connectors CN1 : M.2 Key B Socket (Support PCIE/USB3.0/ SATA interface) Pin No. PIN Name Pin No. PIN Name Pin No. PIN Name CFG3 100M_CLKN +3.3V M.2_BT_PCMFRM WAKE# PCIE2_RXN/USB3 RXN 100M_CLKP +3.3V USIM_RESET PCIE2_RXP/USB3 RXP PULL-UP USIM_CLK USB2- PULL-UP USIM_DATA...
  • Page 69 M2E_1 : M.2 Key E Socket (Support PCIE / CNVi Module) Pin No. Pin No. PIN Name Pin name +3.3V USB_D+ +3.3V USB_D‐ PCM_CLK WGR_D1N PCM_SYNC/LPC_RSTN WGR_D1P PCM_IN PCM_OUT WGR_D0N WGR_D0P UART_WAKE# WGR_CLKN UART_RX/BRI_RSP WGR_CLKP UARTX/RGI_DT UART_CTS/RGI_RSP PETP0 UART_RTS/BRI_DT PETN0 PERP0 PERN0 REFCLKP0...
  • Page 70 REF_CLK WT_D0N WT_D0P SUSCLK +3.3V WTCLKN +3.3V WTCLK +3.3V COM1_1 / COM2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS232 RS422 / 485 Full RS485 Half Definition Duplex Definition Duplex Definition DATA - DATA + DC_IN1: DC 9-48V Power Input Connector, with Power Ignition Connector Connector Type: Terminal Block 1x3 3-pin, 5.0mm pitch Definition +9-48VIN...
  • Page 71 DIO1: Digital 4IN / 4OUT Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ (DC INPUT) XCOM- (GND) RMT_BNT1: Remote Power Button / Remote LED Connector Remote Power LED connector can connect an external LED indicator up to 10mA. Connector Type: Terminal Block 1X4 4-pin, 3.5mm pitch 1 2 3 4 Definition...

  • Page 72: Optional Module Pin Definition & Settings

    2.5 Optional Module Pin Definition & Settings 2.5.1 CFM-IGN101 Module SW2 (on the module)：IGN Module Timing Setting Switch Set shutdown delay timer when ACC is turned off Pin 1 Pin 2 Pin 3 Pin 4 Definition 0 second 1 minute ON (IGN 5 minutes Enabled)

  • Page 73: Chapter 3 System Setup

    Chapter 3 System Setup CS-100/P1301 Series | User Manual...

  • Page 74: Removing Top Cover

    3.1 Removing Top Cover In order to prevent electric shock or system damage, must turn off power and disconnect the unit from power source before removing the chassis cover. (Afin d'éviter tout risque d'électrocution ou d'endommagement du système, vous devez couper l'alimentation et débrancher l'appareil de la source d'alimentation avant de retirer le couvercle du châssis.) Step 1.

  • Page 75: Installing So-Dimm Memory

    3.2 Installing SO-DIMM Memory Step 1. Locate the SO-DIMM sockets. Step 2. Tilt the SO-DIMM module at a 45-degree angle and insert it to SO-DIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° Step 3. Press the modules down until it’s fixed firmly by the two locking latches on each side. CS-100/P1301 Series | User Manual...

  • Page 76: Installing M.2 Key B Card

    3.3 Installing M.2 Key B Card 3.3.1 M.2 Key B type 3052 Step 1. Locate the M.2 Key B slot. Step 2. Insert the M.2 Key B card at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 77: Key B Type 3042

    3.3.2 M.2 Key B type 3042 Step 1. Locate the M.2 Key B slot. Step 2: Align the M.2 Key B Type 3052 to 3042 Adapter Bracket with the corresponding screw hole. Secure the bracket in place and fasten the screw. Step 3.

  • Page 78: Installing M.2 Key E Card

    Step 4. Press down the module and fasten the screw to secure the module. 3.4 Installing M.2 Key E Card Step 1. Locate the M.2 Key E slot on the system board. Step 2. Tilt the M.2 Key E card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly.

  • Page 79: Installing Antenna(S)

    3.5 Installing Antenna(s) Please install a Wireless LAN card before the antenna installation. Step 1. Remove the antenna hole cover(s) on the front or the side panel. Step 2. Have the antenna jack penetrate through the hole. Step 3. Put on the washer and fasten the nut with the antenna jack. CS-100/P1301 Series | User Manual...
  • Page 80 Step 4. Assemble the antenna and antenna jack together. Step 5. Attach the RF connector at another end of cable onto the module. CS-100/P1301 Series | User Manual...

  • Page 81: Installing Cpu Thermal Pad

    3.6 Installing CPU Thermal Pad Step 1. Remove the protective films of the Thermal Pad’s both sides and then place the thermal pad on the CPU heatsink. Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed! (Avant d'assembler le couvercle du châssis du système, assurez-vous que le film protecteur sur le coussin thermique a été...

  • Page 82: Installing Top Cover

    3.7 Installing Top Cover Step 1. Put on the cover. Step2. Fasten the 8 screws to fix the cover. CS-100/P1301 Series | User Manual...

  • Page 83: Installing Sata Hard Drive

    3.8 Installing SATA Hard Drive Step 1. Loosen the 2 screws on the front panel to remove the cover plate. Step 2. Loosen the screw on the HDD bracket. Step 3. Pull out the HDD bracket. Step 4. Make the bottom side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together.
  • Page 84 Step 5. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. Step 6. Fasten the screw on the HDD bracket. Step 7. Fasten the 2 screws on the front panel. CS-100/P1301 Series | User Manual...

  • Page 85: Installing Sim Card

    3.9 Installing SIM Card Step 1. Loosen the 2 screws on front panel to remove cover plate. Step 2. SIM card slot is at the front panel of the system. Step 3. Insert the SIM card until you hear a click sound; that indicates the installation is complete. CS-100/P1301 Series | User Manual...

  • Page 86: Installing Cfm Modules

    3.10 Installing CFM Modules Please refer to chapter 3.1 to remove the top cover of the P1301 system first. 3.10.1 CFM-IGN101 Step 1. Locate the IGN connector on system motherboard as indicated. Step 2. Insert CFM-IGN module vertically to the female connector on the system’s mainboard, and fasten the 2 screws to fix it.

  • Page 87: Cfm-Poe02

    3.10.2 CFM-PoE02 Step 1. Locate the PoE connector on system motherboard as indicated. Step 2. Insert the female connector of CFM-PoE module to the male connector on system motherboard. Step 3. Turn over the heatsink and paste the thermal pad onto the marked by red squares. Before putting on the thermal block (in the next step), please make sure the protective film on the Thermal Pad has been removed! (Avant de mettre le bloc thermique (à...
  • Page 88 Step 4. Paste the heatsink onto the CFM-PoE module carefully and fasten 2 screws to fix it. Step 5. Paste the thermal pads onto the heatsink and coil carefully. Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed! (Avant d'assembler le couvercle du châssis du système, assurez-vous que le film protecteur sur le coussin thermique a été...

  • Page 89: Disassembling The Cs Display Module

    Step 1. Remove the 6 screws on the display module and then disconnect the module. 3.12 Installing Panel Mount Step 1. Accessories provided by Cincoze are as below. (Please note that the quantity of mounting kits varies with the size of the display module, please refer to the datasheet for the actual quantity)
  • Page 90 Step 2. All mounting kits displayed are to be inserted into holes. Step 3. Installation preparation and steps. CS-100/P1301 Series | User Manual...
  • Page 91 CS-100/P1301 Series | User Manual...

  • Page 92: Installing Vesa Mount

    Step 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. 3.13 Installing VESA Mount The following picture indicates VESA mounting hole pattern on the P1301, which is compliant with VESA mounting standard.

  • Page 93: Installing Rack Mount

    3.14 Installing Rack Mount Step 1. Locate and align the screw holes on the PC module with those on the rack mount base. Fasten 8 M4x6 screws securely for a stable connection. Rack Mount Base Step 2. Locate the mounting holes on the rack mount brackets, as illustrated in the pictures below, depicting three different sets of screw holes for mounting the 8.4”...
  • Page 94 Step 3. Assemble the brackets and the rack mount base by securing 4 M5x6 screws on each side. For 8.4” ~ 17” Panel PC Side View Side View Bottom View For 19” ~ 24” Panel PC Side View Side View Bottom View Step 4.
  • Page 95 Step 5. And then assemble two rack mount brackets and the rack by fastening 4 M5x12 screws, flat washers and hex nuts at each side. Rack For 8.4” ~ 17” Panel PC For 19” ~ 24” Panel PC CS-100/P1301 Series | User Manual...

  • Page 96: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup CS-100/P1301 Series | User Manual...

  • Page 97: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 98: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ◼ System Date Set the date.

  • Page 99: Advanced Setup

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 CPU Configuration ◼ Intel (VMX) Virtualization Technology [Enabled] Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions.

  • Page 100: Sata Configuration

    4.3.2 SATA Configuration ◼ SATA Controller(s) [Enabled] Enables or disables SATA device. ◼ SATA Mode Selection [AHCI] Allows you to select which mode SATA controller will operates. Configuration options: [AHCI] ❑ Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. ❑...

  • Page 101: Trusted Computing Settings

    ◼ Firmware Update Configuration Configure Management Engine Parameters ❑ Me FW Image Re-Flash [Disabled] Enables or disables ME firmware Image Re-Flash function. 4.3.4 Trusted Computing Settings ◼ Security Device Support [Enabled] Enables or disables Security Device Support function. ◼ SHA256 PCR Bank [Enabled] Enables or disables SHA256 PCR Bank function.
  • Page 102 Enables or disables SM3_256 PCR Bank function. ◼ Pending Operation [None] Allows you to select which mode Pending Operation will operate. Configuration options: [None], [TPM Clear] ◼ Platform Hierarchy [Enabled] Enables or disables Platform Hierarchy function. ◼ Storage Hierarchy [Enabled] Enables or disables Storage Hierarchy function.

  • Page 103: Acpi Settings

    4.3.5 ACPI Settings ◼ Enable Hibernation [Enabled] Enables or disables system ability to hibernate state (OS/S4 state). This option may not be effective with some OS. ◼ ACPI Sleep State [S3 (Suspend to RAM)] Allows users to select the highest Advanced Configuration Power Interface® (ACPI) sleep state that system will enter when suspend button is pressed.
  • Page 104 ◼ Serial Port 1~2 Configuration. ❑ Serial Port [Enabled] Enables or disables serial port. ❑ Change Settings [Auto] Allows you to change the IO Address & IRQ settings of the specified serial port. ❑ Serial Port Mode [RS232] Allows you to select Serial Port Mode. Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] ◼...

  • Page 105: Hardware Monitor

    4.3.7 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures. 4.3.8 S5 RTC Wake Settings ◼ Wake system from S5 [Disabled] Enables or disables wake system from S5 (soft-off state). [Disabled]: Disables wake system from S5. [Fixed Time]: Sets a fixed time (HH:MM:SS) to wake system from S5.

  • Page 106: Serial Port Console Redirection

    4.3.9 Serial Port Console Redirection ◼ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2, COM3 console redirection function. 4.3.10 USB Configuration ◼ XHCI Hand-off [Enabled] Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support.

  • Page 107: Network Stack Configuration

    4.3.11 Network Stack Configuration ◼ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.13 CSM Configuration ■ CSM Support [Disabled] Enables or disables compatibility support module. CS-100/P1301 Series | User Manual...

  • Page 108: Nvme Configuration

    4.3.14 NVMe Configuration The screen allows users to select options for the NVMe configuration, and change the value of the selected option. If there is NVMe Device detected, the options will show as the NVMe Device is found. CS-100/P1301 Series | User Manual...

  • Page 109: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ◼ Memory Configuration This item displays detailed memory configuration in the system. ◼ VT-d [Enabled] Enables or disables Intel® Virtualization Technology for Directed I/O (VT-d) capability. CS-100/P1301 Series | User Manual...

  • Page 110: Pch-Io Configuration

    4.4.2 PCH-IO Configuration ◼ PCI Express Configuration ❑ PCI Express Root Port (M2E_1) ◼ PCI Express Root Port [Enabled] Enables or disables PCI Express Root Port. ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ❑...
  • Page 111 ◼ HD Audio Configuration ◼ HD Audio [Enabled] Enables or disables HD Audio function. ◼ LAN 1 i225 [Enabled] Enables or disables I210 LAN Controller. ◼ LAN 2 i225 [Enabled] Enables or disables I210 LAN Controller. ◼ Wake# event (PCIe) [Enabled] Enables or disables Wake# event (PCIe).

  • Page 112: Security Setup

    4.5 Security Setup This section allows users to configure BIOS security settings. ◼ Administrator Password Administrator Password controls access to the BIOS Setup utility. ◼ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ◼...

  • Page 113: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. ◼ Setup Prompt Timeout [1] Use this item to set number of seconds (1..65535) to wait for setup activation key. ◼ Bootup NumLock State Allows you to set NumLock key to [On] or [Off] state when system boots up. ◼...

  • Page 114: Save & Exit

    4.7 Save & Exit ◼ Save Changes and Exit This item allows you to exit the system after saving changes. ◼ Discard Changes and Exit This item allows you to exit system setup without saving any changes. ◼ Save Changes and Reset This item allows you to reset the system after saving changes.

  • Page 115: Chapter 5 Product Application

    Chapter 5 Product Application CS-100/P1301 Series | User Manual...

  • Page 116: Where To Download Drivers

    5.1 Where to download drivers? Drivers for the CS-100/P1301 Series can be downloaded from the CINCOZE website. 5.2 Where to find the technical documents? The following documents are the most relevant technical references for the CS-100/P1301 Series. All documents can be accessed via the CINCOZE Partner Zone: •...
  • Page 117 Wake On LAN Function Manual WDT Function Manual CS-100/P1301 Series | User Manual...
  • Page 118 © 2024 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
