EN WARNING!
Children must not use the equipment until properly installed.
Maximum fall height: 195cm
Surface selection instructions
Loose-Fill Materials should be placed under the product and 6' out in
all directions • Use a minimum of 6 inches of protective surfacing for
play equipment less than 4 feet in height. If maintained properly, this
should be adequate • Use containment, such as digging out around
the perimeter and/or lining the perimeter with landscape edging. Don't
forget to account for water drainage • Check and maintain the depth of
the loose-fill surfacing material. To maintain the right amount of loose-
fill materials, mark the correct level on play equipment support posts.
That way you can easily see when to replenish and/or redistribute the
surfacing • Do not install loose fill surfacing over hard surfaces such as
concrete or asphalt.
Installation Instructions
Place the equipment on level ground, not less than 6 ft (1.8 m) from any
structure or obstruction such as a fence, garage, house, overhanging
branches, laundry lines, or electrical wires • Do not install home
playground equipment over concrete, asphalt, packed earth, grass,
carpet, or any other hard surface. A fall onto a hard surface can result
in serious injury or death to the equipment user • Make sure that all the
bolts are tightened securely, tighten the nuts on bolts flush to the tube
(or member) and the caps which go over the exposed bolts shall be put
on snug to the nut • To prevent serious injury, cautionary statements
shall be included which warn that children must not use the equipment
until properly installed.
Operating Instructions
Observing the following statements and warnings reduces the likelihood
of serious or fatal injury • We recommend that only three children,
50kg weight max each, to play on the product at the same time •
Recommending on-site adult supervision for children of all ages • The
owner shall instruct children not to walk close to, in front of, behind, or
between moving items • The owners shall not instruct children to use
the equipment in a manner other than intended • The owners shall
not allow children to wear inappropriate items, such as but not limited
to, loose fitting clothing, hood and neck drawstrings, scarves, cord-
connected items, capes and ponchos. These items can cause death by
strangulation • The owners shall not instruct children to climb when the
equipment is wet • Warning the owner to check the openings between
rollers and sliding surfaces of roller slides for foreign materials that could
be potentially hazardous to users • Warning the owner to verify that
suspended climbing ropes, chain, or cable are secured at both ends •
Warning the owner to verify that suspended climbing ropes, chain, or
cable cannot be looped back on itself • The owners shall instruct children
not to attach items to the playground equipment that are not specifically
designed for use with the equipment, such as, but not limited to, jump
ropes, clothesline, pet leashes, cables and chain as they may cause a
strangulation hazard • The owners shall instruct children to remove their
bike or other sports helmet before playing on the playground equipment
• The owners shall dress children with well fitting and full foot enclosing
footwear. Examples of the inappropriate footwear are clogs, flip flops
and sandals • Never add extra length to chain or rope. The chains or
ropes provided are the maximum length designed for the swinging
element(s) • The owner shall instruct children to avoid swinging empty
seats • The owner shall instruct children not to twist swing chains or
ropes or loop them over the top support bar since this may reduce the
strength of chain or rope • The owner shall teach children to sit/lie in the
centre of the swings with their full weight on the seat • The owner shall
instruct children not to get off equipment while it is in motion.
WARNING: Lawn swings are designed for use by children two years of
age and older. The use by children under the age of two can result in
entrapment between the seat and back rest because the child's body
may pass through the opening, causing entrapment of the child's head.
Such entrapment may result in strangulation. NEVER place children in a
rearward facing position or with legs between the seat and backrest
Maintenance Instructions
At the beginning of each play season:
- Tighten all hardware.
- Lubricate all metallic moving parts per manufacturer's instructions.
- Check all protective coverings on bolts, pipes, edges, and corners.
Replace if they are loose, cracked, or missing.
- Check all moving parts including swing seats, ropes, cables, and chains
for wear, rust, or other deterioration. Replace as needed.
- Check metal parts for rust. If found, sand and repaint using a nonlead-
based paint meeting the requirements of 16 CFR 1303.
- Check all wood members for deterioration and splinters. Sand down
splinters and replace deteriorating wood members.
- Reinstall any plastic parts, such as swing seats or any other items that
were removed for the cold season.
4
- Rake and check depth of loose fill protective surfacing materials to
prevent compaction and to maintain appropriate depth. Replace as
necessary.
Once a month during play season:
- Lubricate all metallic moving parts per manufacturer's instructions.
- Check all moving parts including swing seats, ropes, cables, and chains
for wear, rust, or other deterioration. Replace as needed.
Twice a month during play season:
- Tighten all hardware.
- Check all protective coverings on bolts, pipes, edges, and corners.
Replace if they are loose, cracked, or missing.
- Rake and check depth of loose fill protective surfacing materials to
prevent compaction and to maintain appropriate depth. Replace as
necessary.
At the end of each play season
- Remove plastic swing seats and other items as specified by the
manufacturer and take indoors or do not use.
- Rake and check depth of loose fill protective surfacing materials to
prevent compaction and to maintain appropriate depth. Replace as
necessary.
- Owners shall be responsible for maintaining the legibility of the warning
labels.
Disposal Instructions
To dispose of the item, first disassemble it. Dispose of it in such a way
that no unreasonable hazards will exist at the time that the item is
discarded.
FR ATTENTION!
Les enfants ne doivent pas utiliser l'équipement tant qu'il n'est pas
correctement installé.
Hauteur de chute maximum: 195cm
Instructions sur le choix de la surface
Des matériaux d'amortissement doivent être placés sous la balançoire,
sur une surface de 1,80 m dans toutes les directions • Appliquez une
surface protectrice de 15 cm minimum pour les équipements de jeux
de moins de 1,20 m de hauteur. Si l'entretien est adéquat, cela devrait
être suffisant • Utilisez un confinement : creuser autour du périmètre et/
ou border le périmètre avec une bordure pour aménagement. N'oubliez
pas de tenir compte du drainage de l'eau • Vérifiez et maintenez
la profondeur des matériaux d'amortissement de surfaçage. Pour
maintenir la bonne quantité de matériaux d'amortissement, indiquez
le niveau approprié en le marquant sur les poteaux de soutien de
l'équipement de jeux. De cette manière, vous pouvez facilement voir
lorsqu'il est nécessaire de reconstituer la surface ou de remettre des
matériaux • Ne pas mettre de matériaux d'amortissement de surfaçage
sur des surfaces dures, comme du béton ou de l'asphalte.
Instructions d'installation
Placer l'équipement sur un terrain plat, à au moins 1,8 m de toute
structure ou de tout obstacle comme une clôture, un garage, une
maison, des branches pendantes, des cordes à linge ou des câbles
électriques • Ne pas installer d'équipement d'aire de jeux sur du béton,
de l'enrobé, de la terre battue, de l'herbe, un tapis ou toute autre surface
dure. Une chute sur une surface dure peut entraîner des blessures
graves, voire mortelles, pour l'utilisateur de l'équipement • Assurez-vous
que tous les boulons sont bien serrés, serrez les écrous sur les boulons
au niveau du tube (ou du composant). Les capuchons qui recouvrent
les boulons exposés doivent être bien ajustés à l'écrou • Pour éviter
des blessures graves, des avertissements doivent être affichés afin
que les enfants n' utilisent pas l'équipement avant que celui-ci ne soit
correctement installé.
Mode d'emploi
Le respect de la déclaration et des mises en garde suivantes réduit
le risque de blessures graves ou mortelles • Nous recommandons
que seulement trois enfants, 50 kg maximum chacun, puissent jouer
sur le produit en même temps • Recommandation d'une surveillance
adulte sur site pour les enfants de tous les âges • Le propriétaire
doit expliquer aux enfants de ne pas marcher près, devant, derrière
ou entre les éléments en mouvement • Le propriétaire ne doit pas
expliquer aux enfants une utilisation de l'équipement autre que celle
qui a été prévue • Le propriétaire ne doit pas permettre aux enfants de
porter des choses non appropriées, comme par exemple, mais sans
s'y limiter, des vêtements amples, des cordons de capuche et de cou,
des écharpes, des éléments reliés par un cordon, des capes et des
ponchos. Ces éléments peuvent provoquer la mort par strangulation
• Le propriétaire doit expliquer aux enfants de ne pas grimper lorsque
l'équipement est mouillé • Conseiller au propriétaire de vérifier les
ouvertures entre les rouleaux et les surfaces de glisse des toboggans à
rouleaux à la recherche de corps étrangers potentiellement dangereux
pour les utilisateurs • Conseiller au propriétaire de vérifier que les
