- Page 1 K46100, K46195, K46196, K46300, K46395, K46396 Cloud and Pour Point Bath – Bench & Floor Models service | innovation | technology REV K-A...
- Page 2 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual - ii -...
- Page 3 Cloud and Pour Point Bath – Bench Model & Floor Model K46100, K46195, K46196, K46300, K46395, K46396 This certificate verifies that part numbers K46100, K46195, K46196, K46300, K46395, K46396, Cloud and Pour Point Bath, were manufactured in conformance with the applicable standards set forth in this certification.
- Page 4 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual - iv -...
- Page 5 Responsibility for Registration and Annual Reporting: Koehler will not sell directly to end users in the EU and so has no responsibility to register within each EU state and to make annual reports. Koehler declares that this responsibility is born by the importer who is the first level of the distribution chain and is subject to producer responsibility.
- Page 6 Recycling is free of charge. Shipping is the responsibility of the end users. Whether shipping to a distributor or to Koehler directly, safe, properly declared, and labeled packaging and shipping expenses are the sole responsibility of the end user.
-
Page 7: Table Of Contents
Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual Table of Contents 1. Introduction 1.1. Koehler’s Commitment to Our Customers 1.2. Recommended Resources and Publications 1.3. Instrument Specifications 2. Safety Information and Warnings 3. Getting Started 3.1. -
Page 8: Introduction
Providing quality testing instrumentation and technical support services for research and testing laboratories has been our specialty for almost 100 years. At Koehler, the primary focus of our business is providing you with the full support of your laboratory testing needs. Our products are backed by our staff of technically knowledgeable, trained specialists who are experienced in both petroleum products testing and instrument service to better understand your requirements and provide you with the best solutions. -
Page 9: Instrument Specifications
Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 1.3. Instrument Specifications Models: K46100 3-Position Benchtop Model 115V 60Hz 12.2A K46195 3-Position Benchtop Model 220-240V 50Hz 6.9A K46196 3-Position Benchtop Model 220-240V 60Hz 6.9A K46300... -
Page 10: Packing List
We will assist you with your claim, if requested. When submitting a claim for shipping damage, request that the carrier inspect the shipping container and equipment. Do not return goods to Koehler without written authorization. -
Page 11: Descriptions
Figure 1. Instrument Descriptions Part Number Description K46120 Cork Disk 332-004-001 Test Jar* AS568-131 Gasket for Test Jar K46100-03030 Copper Test Jacket * Sold separately 4.2. Additional Accessories Part Number Replacement Part Part Number Replacement Part 250-000-05F ASTM 5F Thermometer... -
Page 12: Temperature Controller
Menu/OK Call up main menu, switch to submenu/level, switch to editing mode, exit editing mode confirming changes. IMPORTANT NOTE: The digital temperature controller has been pre-programmed specifically for this instrument at the Koehler factory. Please do NOT attempt to re-program the controller as this may cause undesired operation and will void the product warranty. -
Page 13: Operation
Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual Press the Menu/OK key two times until PCt is displayed in the upper white display. Press the DOWN key. CAL will display on upper white display. If there is a value observed in the upper white display, add it to the calculated difference obtained in the previous step. -
Page 14: Maintenance
Disconnect power to the unit before servicing to avoid exposure to high voltages and/or temperatures which may result in personal injury or death. If you have any questions about maintaining your equipment, then please do not hesitate to contact the Koehler technical service department. •... -
Page 15: Wiring Diagrams
Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 8. Wiring Diagrams 8.1. Floor Model - 9 -... - Page 16 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 8.2. Bench Model (115V) - 10 -...
- Page 17 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 8.3. Bench Model (230V 50Hz) - 11 -...
- Page 18 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 8.4. Bench Model (230V 60Hz) - 12 -...
- Page 19 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual 8.5. Temperature Controller Configuration - 13 -...
-
Page 20: Service
We, at Koehler, would like to thank you for your equipment purchase, which is protected by the following warranty. If within one (1) year from the date of receipt, but no longer than fifteen (15) months from the date of shipment, Koehler equipment fails to perform properly because of defects in materials or workmanship, Koehler Instrument Company, Inc. - Page 21 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual Notes - 15 -...
- Page 22 Cloud and Pour Point Bath – Bench & Floor Models Operation and Instruction Manual Notes - 16 -...
