TEXIO LSG-A Series Instruction Manual

Electronic load
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LSG SERIES
INSTRUCTION MANUAL
ELECTRONIC LOAD
LSG-A SERIES
LSG-175A
LSG-350A
LSG-1050A
LSG-2100AS LSG-2100ASH
B71-0517-01
LSG-175AH
LSG-350AH
LSG-1050AH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSG-A Series and is the answer not in the manual?

Questions and answers

Related Manuals for TEXIO LSG-A Series

Summary of Contents for TEXIO LSG-A Series

  • Page 1 LSG SERIES INSTRUCTION MANUAL ELECTRONIC LOAD LSG-A SERIES LSG-175A LSG-175AH LSG-350A LSG-350AH LSG-1050A LSG-1050AH LSG-2100AS LSG-2100ASH B71-0517-01...

  • Page 2: Table Of Contents

    CONTENTS USING THE PRODUCT SAFELY ························································ Ⅰ-Ⅳ 1. GETTING STARTED ............... 1 1-1. LSG-A Series Introduction ........... 1 1-1-1. Model Line Up ................... 1 1-1-2. Main Features ................... 2 1-2. Accessories ................ 3 1-2-1. Accessories ....................3 1-2-2. Package Contents ..................4 1-3.
  • Page 3 2-2. Basic Configuration ............44 2-2-1. Select the Switching Function ..............44 2-2-2. Select the Display Units for Dynamic Mode Levels ......... 47 2-2-3. Select the Switching Time Configuration for Dynamic Mode ....48 2-2-4. Slew Rate ....................49 2-2-5. CV, +CV Mode Response Speed ............50 2-2-6.
  • Page 4 2-8. Save / Recall ..............73 2-8-1. File Structure ..................73 2-8-2. File Types ....................74 2-8-3. Saving Files to Internal Memory ............. 75 2-8-4. Saving Files to USB Memory ..............76 2-8-5. Recalling Files from Internal Memory............77 2-8-6. Recalling Files from USB Memory ............78 2-8-7.
  • Page 5 3-6-1. BATT Test function setting parameters..........124 3-6-2. BATT Test function setting ..............125 3-6-3. Running a BATT Test function .............. 126 3-6-4. Results of BATT Test function .............. 126 3-6-5. Save the Data for BATT Test function ..........128 3-7.
  • Page 6 5-1-6. Using RealTerm to Establish a Remote Connection ......165 5-1-7. GP-IB Function Check ................168 5-1-8. LAN Function Check (HTTP) ..............169 5-1-9. LAN Function Check(Socket) ..............170 6. FAQ ..................174 7. APPENDIX ................175 7-1. Replacing the Dust Filter ..........175 7-2.
  • Page 7 7-9-7. Slew Rate ..................... 207 7-9-8. Meter..................... 208 7-9-9. Dynamic Mode ..................208 7-9-10. Soft Start ..................... 211 7-9-11. Remote Sensing ................. 211 7-9-12. Protection Function ................211 7-10. LSG-A/LSG-AH Specifications ........212 7-10-1. Sequence .................... 212 7-10-2. Other ....................212 7-10-3.
  • Page 8 The latest version of the instruction manual is posted on our website (https://www.texio.co.jp/download/). ■ The corresponding firmware versions in this manual are as follows. ：Ver2.33 or higher LSG-A Series ：Ver2.09 or higher LSG-AH Series This version does not support communication control via RS-485.

  • Page 9: Using The Product Safely

    USING THE PRODUCT SAFELY ■ Preface To use the product safely, read this instruction manual to the end. Before using this product, understand how to correctly use it. ask us or If you read this manual but you do not understand how to use it, your local dealer.
  • Page 10 USING THE PRODUCT SAFELY WARNING ■ Do not remove the product's covers and panels Never remove the product's covers and panels for any purpose. Otherwise, the user's electric shock or a fire may be incurred. ■ Warning on using the product The warning items given below are to avoid danger to the user's body and life and avoid the damage and deterioration of the product.
  • Page 11 USING THE PRODUCT SAFELY WARNING ■ Warning item on installation environment ● Operating temperature Use the product within the operating temperature indicated in the rating column. If the product is used with the vents of the product blocked or in high ambient temperatures, a fire may occur.
  • Page 12 USING THE PRODUCT SAFELY CAUTION ■ Input/output terminal Maximum input to the input terminals is specified to prevent the product from being damaged. Do not supply input, exceeding the specifications that are indicated in the "Rating" or "Caution on use" column in the instruction manual of the product.

  • Page 13: Getting Started

    1. GETTING STARTED This chapter provides a brief overview of the LSG-A Series, the package contents, instructions for first time use and an introduction to the front panel, rear panel and GUI. 1-1. LSG-A Series Introduction The LSG Series is a family of high-performance DC electronic loads positioned to test a wide range of different power sources.

  • Page 14: Main Features

    1-1-3. Mixing in parallel connection of LSG series and LSG-A series Basically, up to 4 units of the same type as the master are required, and up to 4 boosters can be connected to the 1050W type. Please note that the LSG-A/LSG-AH booster cannot be connected when the old LSG/LSG-H series is used as the master.

  • Page 15: Accessories

    1-2. Accessories 1-2-1. Accessories Standard Part number Description Accessories Region dependent Power cord PEL-011 Load input terminal Cover x1 M3 Screw x1 screw PEL-012 Terminal fittings: 2 sets of bolts/ nuts /springs /washers (type: M8) Terminal cover x2(Either one) M8 x 20 Spring washer Flat washer M8 nut...

  • Page 16: Package Contents

    Optional Part number Description Accessories GRA-413E Rack mount bracket for booster LSG- 2100ASH for EIA GRA-413J Rack mount bracket for booster LSG- 2100ASH for JIS GRA-414-E Rack mount frame for EIA GRA-414-J Rack mount frame for JIS CB-2420P GP-IB cable, 2.0m GTL-246 USB cable, Type A - Type B PEL-010...

  • Page 17: Appearance

    1-3. Appearance 1-3-1. Front Panel LSG-175A/LSG-175AH / LSG-350A/LSG-350AH Air inlet Preset key LCD Display Function keys Power key Main/Local FUNC/File Local Main Help/Utility File FUNC Utility Short Help Short Load On/Off Load Preset Scroll wheel Shift CAL . Number pad Clear Enter 175W...
  • Page 18 Name explanation Air Inlet The air inlet has a removable dust filter. (Front grille) Please do not lift up the product, while touching the front grille. LCD display 3.5-inch LCD display Function keys The function keys directly correspond to the soft menus at the bottom of the display.
  • Page 19 Clear/Lock Clear: Clears the current parameter Lock values. Clear Lock (Shift + Clear): Locks the front panel keys and selector knob. Number pad CAL. Lock Clear Number pad: Used to enter numerical values. P0~P9 (Preset + Number keys): Loads one of 10 preset settings. Shift Shift: Used in conjunction with other Shift...
  • Page 20 IMON Out Current monitor BNC terminal: Output connector used to monitor the current by outputting a voltage. An output voltage of 10V corresponds I MON OUT to the full scale current for the H and L ranges. 1V corresponds to the full scale current in the M range.

  • Page 21: Rear Panel

    1-3-2. Rear Panel LSG-175A/LSG-175AH / LSG-350A/LSG-350AH Frame control Remote Rear panel ports, J1, J2 sense inputs inputs V/I MON OUT Monitor Out FRAME CONT ports J3 Variable Resistor RS232/ RS485 RS232/ RS485 GPIB port 100 - 120 VAC LAN port 200 - 240 VAC 47 - 63 Hz USB device...
  • Page 22 Name explanation RS-232C Port The USB B, RS-232C/485 and GP-IB port are used for GP-IB remote control. USB B RS232 RS485 USB B port RS-232C/485 GP-IB RJ-45 24 pin RJ-45 Frame control FRAME CONT ports J1, J2 J1: The J1 is assigned to external control. J2: The J2 is used for parallel operation control.
  • Page 23 Rear Panel Input terminals Rear Panel Input Terminals. Electrically connected to the front panel input terminals. Accepts M8 bolts or M4/M3 sized screws. See page 20 ( 1-4-8. Using the Rear ) for connection details. Panel Input Terminals Remote Sensing Terminals Sensing terminals for remote sense.

  • Page 24: Display

    1-3-3. Display Mainframe status panel Date 01/Oct/2017 RS232 LOAD 0. 00 0.00 Measurement area 0.0000 CC A Value 0. 0000 setting Operation area CC B Value 0. 0000 status Fine SlewRate 140 . 00 mA/ us panel A Value Mode I Range V Range Function...

  • Page 25: First Time Use Instructions

    1-4. First Time Use Instructions Use the procedures below when first using the LSG Series to install the rack mount kit, power up the instrument, set the internal clock, restore the factory default settings and check the firmware version. Lastly, the Conventions section will introduce you to the basic operating conventions used throughout the user manual.

  • Page 26: Power Up And Self-Test

    1-4-2. Power Up and Self-Test Operation Insert the AC power cord into the power socket. Turn the external power switch (O → —) If the unit doesn’t turn on, press the On/Standby key for a second. The ON/STBY key will go from standby (red) to on (green).

  • Page 27: Setting The Date And Time

    1-4-4. Setting the Date and Time Description The date and time settings are used to time-stamp files when saving files. The date and time is shown on top of the LCD display. Utility Operation Help Shift Press > > Time Set [F4] in order, and set the date and time.

  • Page 28: Load Wiring

    1-4-5. Load Wiring Wire Gauge Before connecting the unit to a power source, the wire considerations gauge must be taken into account. Load wires must be large enough to resist overheating when a short-circuit condition occurs as well as to maintain a good regulation. The size, polarity and length of a wire are all factors in determining if a wire will withstand short circuiting.
  • Page 29 Load Line When using the LSG Series load generator, voltage drop Inductance and voltage generated due to load line inductance and Considerations current change must be taken into account. Extreme changes in voltage may exceed the minimum or maximum voltage limits. Exceeding the maximum voltage limit may damage the LSG Series.

  • Page 30: Load Wire Connections

    Limiting Load Load line inductance can be reduced in two methods. line inductance Method 1 Ensure load wires are as short as possible and twist the positive and negative load wires together. “Twisted pair” will be shown on any connection diagram where the load wires should be twisted together.

  • Page 31: Using The Front Panel Input Terminals

    1-4-7. Using the Front Panel Input Terminals Description The front panel input terminals feature polarity-distinct caps and accept M6 sized crimped terminals. The front panel input terminals on the LSG Series are physically connected to the rear panel terminals. Caution Step Turn the power off from the rear panel or put the unit into standby mode.

  • Page 32: Using The Rear Panel Input Terminals

    1-4-8. Using the Rear Panel Input Terminals Description The rear panel input terminals accept up to M8-sized crimped terminals. The rear terminals come with a load input terminal cover for safety. The front panel input terminals on the LSG Series are physically connected to the rear panel terminals.

  • Page 33: Using The Terminal Cover (Pel -011)

    1-4-9. Using the Terminal Cover (PEL -011) Description The rear panel terminal cover should be used to prevent electric shock. The rear panel terminal covers should always be used when connecting a load to the rear panel terminals. As the front panel and rear panel terminals are physically connected, the terminal cover should also be used as a safety measure when a power source is connected to the front terminals...
  • Page 34 Steps(2/2) Use your thumb to slide the terminal covers shut, as shown in the diagram below. When the top and bottom covers are flush, reinsert the screw that was removed in step 1.

  • Page 35: Using The Terminal Cover (Pel -013)

    1-4-10. Using the Terminal Cover (PEL -013) Description The flexible rear panel terminal cover should be used when the load wiring becomes too thick to be used with the PEL-011 terminal cover. This is especially true when using the load generators in parallel. Like the PEL-013 terminal cover, the PEL-011 is used to prevent electric shock.

  • Page 36: Using The Terminal Cover

    1-4-11. Using the Terminal Cover Description After connection is finished, please lock terminal cover to avoid electric shock when using the frame control terminal. Ensure the power is off, before making any connections to the booster pack. Caution Steps Install the terminal cover as shown in the picture below. LSG-H Series LSG Series 1-4-12.

  • Page 37: Remote Sense

    1-4-13. Remote Sense Description Remote sense can be used to help compensate for long cable length. The longer the cable, the higher the potential resistance and inductance, therefore a short cable is best. Twisting the cable can help reduce induced inductance and using the remote sensing terminals compensates the voltage drop seen across the load leads, especially leads with higher resistance.

  • Page 38: Firmware Update

    The LSG Series allows the firmware to be updated by end- users. Before using the LSG Series, please check the TEXIO TECHNOLOGY website or ask your local distributor for the latest firmware. Before updating the firmware, please check the firmware version and model.

  • Page 39: Conventions

    1-4-15. Conventions The following conventions are used throughout the user manual. Read the conventions below for a basic grasp of how to operate the LSG Series menu system using the front panel keys. Soft Menus The F1 to F5 function keys at the bottom of the LCD display correspond directly to the soft menus on top.
  • Page 40 Toggle Function/ Item Parameter or State Mode Parameter or State This type of soft-menu icon has the function /item on the top of the label and the selected setting or mode on the bottom of the label. Repeatedly press the associated function key (F1~F5) to cycle through each setting.

  • Page 41: Number Pad

    Parameter The scroll wheel, Enter key and number pad can be used to Input edit parameter values. Number pad Scroll wheel CAL. Lock Enter key Clear Enter Use the scroll wheel to move the cursor to the desired parameter. A scroll bar is shown when there are additional parameters off-screen.
  • Page 42 Using the **To edit a parameter using the scroll wheel, simply turn the Scroll Wheel to scroll wheel. Clockwise increases the value, Edit a counterclockwise decrease the value. Parameter** Pressing the scroll wheel when a parameter is highlighted allows you to change the step resolution. There are two different step resolution methods: Step Mode and Cursor Mode.
  • Page 43 Entering When renaming files, creating memos or notes, you will be Alphanumeric required to enter alphanumeric characters when the Characters character entry screen appears. Only alphanumeric characters as well as space [ ], underscore [_] and minus [-] characters allowed. Use the scroll wheel to move the cursor to the desired character.

  • Page 44: Help Menu

    1-4-16. Help Menu When any function key has been pressed or when a menu has been opened, the HELP key can be used to display a detailed description. Help Menu Press any function key or soft-menu key. Help Press to see the help contents on that particular function key or menu.

  • Page 45: Operation

    2. OPERATION 2-1. Basic Operation The LSG Series supports 7 main operating modes: CC, CC+CV, CR, CR+CV, CV, CP, CP+CV 2-1-1. CC Mode Description In Constant Current Mode the load units will sink the amount of current programmed. Regardless of the voltage, the current will stay the same. For more details on CC mode, please see the appendix on page 184 ( 7-5-1.
  • Page 46 Display 01/Oct/2017 RS232 LOAD 0.000 0.00 0.0000 Active setting Current setting A Current setting B CC A Value 0.0000 CC B Value 0.0000 Mode Voltage range Fine SlewRate 140.00 mA/uS A Value Mode I Range VRange Function Configure H 8.75A L 80V Static Current range...

  • Page 47: Cr Mode

    2-1-2. CR Mode Description In Constant Resistance Mode, the unit will maintain a constant resistive load by varying the current. CR mode uses Ω (resistance) or S (conductance) for the setting units. For more details on CR mode, please see the appendix on page 185 ( 7-5-2.CR Mode If you change the mode or the range when the load is already on, the load will be turned off automatically.

  • Page 48: Cr Units

    Basic CR mode configuration is complete. See page 44 ) for more configuration options. 2-2. Basic Configuration Note The current range and voltage range applies to all the operating modes. 2-1-3. CR Units The CR setting units can be set to Ω (resistance) or Description mS (conductance).

  • Page 49: Cv Mode

    2-1-4. CV Mode Description In Constant Voltage Mode, the unit will maintain a constant voltage. In CV mode you set the constant voltage level. For more details on CV mode, see the appendix on page 187 ( 7-5-4.CV Mode If you change the mode or the range when the load is already on, the load will be turned off automatically.

  • Page 50: Cp Mode

    2-1-5. CP Mode Description In Constant Power Mode, the unit will maintain a constant power by varying the current. For more details on CP mode, see the appendix on page 186 ( 7-5-3.CP Mode If you change the mode or the range when the load is already on, the load will be turned off automatically.

  • Page 51: Cv Mode

    Basic CP mode configuration is complete. See page 44 ) for more configuration options. 2-2. Basic Configuration The current range and voltage range applies to all the Note operating modes. 2-1-6. +CV Mode Description +CV mode can be added to CC, CR and CP mode. The +CV settings apply to all applicable modes.

  • Page 52: Turning On The Load

    2-1-7. Turning on the Load Description The load can be turned on and off by pressing Load key. Load key will turn orange when the load is “on”. The LOAD icon in the mainframe status panel will turn orange when the load is on. Display LOAD on RS232...

  • Page 53: Shorting The Load

    2-1-8. Shorting the Load Description The Short key can be used to simulate a short circuit of the load input terminals. A short circuit is simulated by: Setting the current to the maximum value in CC mode. Setting the resistance to the minimum value in CR mode.

  • Page 54: Safety Short

    2-1-9. Safety Short Description When activated, the safety short function only allows the short key to be used when the load is already on. Operation Main Press > Configure [F5] > Other [F2] in order, and set the Short Safety. When set to OFF, the load can be shorted at any time.

  • Page 55: Locking The Front Panel Controls

    2-1-12. Locking the Front Panel Controls Description The keys and scroll wheel on the front panel can be locked to prevent settings from being changed. Operation The keys can be locked and unlocked Lock by press Shift > Clear in order. Load key will not be locked if the load is on.

  • Page 56: Basic Configuration

    2-2. Basic Configuration The basic configuration settings are the common configuration settings that are used for each operating mode. After selecting a basic operating mode (CC, CR, CV and CP mode), the slew rate, switching function, response rate and other common parameters should be configured. 2-2-1.
  • Page 57 Operation Make sure the load is off. Main Press Select Dynamic or Static mode with the Function [F4] soft-key. A different switching mode can be set for CC, CR and CP mode. See page 45 (Static Mode Operation) for Static Mode. See page 46 (Dynamic Mode Operation) for Dynamic Mode.
  • Page 58 Dynamic Mode For dynamic mode, set the Timer1 and Timer2 Operation parameters using the scroll wheel and number pad. Timer1 sets the Level1 on-time. Timer2 sets the Level2 on-time. Take the slew rate settings into consideration when setting the timers. 01/Oct/2017 RS232 LOAD...

  • Page 59: Select The Display Units For Dynamic Mode Levels

    2-2-2. Select the Display Units for Dynamic Mode Levels Description When Dynamic mode is selected, the Level1 and Level2 values can be set to either discrete values or as a percentage of a set value. The setting applies to all applicable operation modes. By default the units are set to Value.

  • Page 60: Select The Switching Time Configuration For Dynamic Mode

    2-2-3. Select the Switching Time Configuration for Dynamic Mode Description The switching time for dynamic mode can be configured to switch between two preset on-times (Timer1, Timer2) or by setting a switching frequency and duty cycle. Operation Main Press > Configure [F5] > Other [F2] in order, and set the Dyna.

  • Page 61: Slew Rate

    2-2-4. Slew Rate Description The current slew rate can be set for CC and CR mode. The slew rate setting is used to limit the change in current when switching. For static mode, only a single slew rate can be set. Operation Make sure the load is off.

  • Page 62: Cv, +Cv Mode Response Speed

    2-2-5. CV, +CV Mode Response Speed Description The response speed setting is the response speed for the negative feedback control of the load current when used in CV, +CV mode. Response speed settings are only applicable to CV, +CV mode. Response speed settings of the +CV mode becomes same as Response speed settings of the CV mode.

  • Page 63: Cc, Cr And Cp Mode Response Speed

    2-2-6. CC, CR and CP Mode Response Speed By default, the “normal current response” speed is set to Description 1/1. The response speed can be reduced to 1/2, 1/5, 1/10. Reducing the current response speed can affect other settings such as the slew rate and soft start settings. Operation Make sure the load is off.

  • Page 64: Advanced Configuration Settings

    2-3. Advanced Configuration Settings Use the advanced configuration settings to configure settings other than those described in the basic configuration chapter. 2-3-1. Soft Start Setting Description The soft start setting is used to limit the amount of input current at start-up or from when the Von Voltage threshold is tripped.

  • Page 65: Von Voltage Settings

    2-3-2. Von Voltage Settings 2-3-2-1. Von Voltage Level Description The Von Voltage is the threshold voltage at which the load module will start to sink current. Von voltage Voltage Input voltage Time Current Load ON Input current Time Operation Main Press >...

  • Page 66: Von Voltage Latch

    2-3-2-3. Von Voltage Latch Description When Von Latch is set to OFF, the load will turn off when the voltage drops below the Von Voltage threshold level. When Von Latch is set to ON, the load will continue to sink current after being “latched”, even if the voltage drops below the Von Voltage threshold level.

  • Page 67: Timer Functions

    2-3-3. Timer Functions 2-3-3-1. Count Time Description When Count Time timer is set to on, it will count the elapsed time from when the load was turned on to when it was turned off. This function is applicable to manual and automatic shutdown (such as from protection functions such as UVP etc.) The elapsed time will be shown in the display...

  • Page 68: Auto Load Configuration

    2-3-4. Auto Load Configuration Description The LSG Series can be configured to automatically load program function, normal sequence function, fast sequence function or manual operation at startup. By default, “Auto Load” is OFF and “Auto Load On” is Load. Utility Operation Help Press...

  • Page 69: Step Resolution Configuration

    2-4. Step Resolution Configuration There are two different ways (Cursor Mode and Step Mode) to set the resolution when using the scroll wheel to edit parameters. Step Mode is the default method. Only one mode can be active at a time; when one mode is active, the other mode is deactivated.

  • Page 70: Step Mode Configuration

    2-4-2. Step Mode Configuration Description When set to Step Mode, the voltage, current, resistance and power settings can have the step resolution configured. The step resolution refers to the step resolution of the coarse adjustment for these settings. The fine adjustment cannot be configured. See the Conventions section on page 30 ( 1-4-15.

  • Page 71: Protection Settings

    Display RS232 LOAD 01/Oct/2017 Configure 8.75A Status Step (coarse/fine) Static CCH Step 0.0300 CCM Step 0.00600 CCL Step 0.300 CRH Step 3.00 Previous Parallel Knob External Menu 2-5. Protection Settings The Protection settings are used to prevent damage to the unit or the power source by excessive current, voltage or power.
  • Page 72 Display Alarm message 01/Oct/2017 RS232 LOAD 8.653 0.4327 when OCP is OCP indicator set to Load Off 50.006 OCP Alarm Please Press Enter CV A Value 80.000 To Clear Alarm CV B Value 80.000 Fine A Value Mode I Range V Range Response Configure...

  • Page 73: Opp

    2-5-2. OPP Description For OPP, the LSG Series can be configured to either limit the power or turn off the load. The OPP levels can be set to 10% higher than the rated power. Operation Main Press > Configure [F5] > Protection [F1] in order, and set the OPP Level and OPP Setting.

  • Page 74: Uvp

    2-5-3. UVP Description If the UVP is tripped, the LSG Series will turn off the load. The UVP levels can be set from 0V to 10% higher than the rated voltage. Operation Main Press > Configure [F5] > Protection [F1] in order, and set the UVP Level.

  • Page 75: Uvp Ring Time

    2-5-4. UVP Ring Time Description The UVP Ring Time settings allows the UVP alarm to keep sounding for a user-set amount of time after the UVP has been tripped. The alarm will continue ringing for the set amount of time even if the voltage rises back above the UVP level~ unless the alarm is cleared manually.

  • Page 76: Ovp

    2-5-5. OVP Description If the OVP is tripped, the LSG Series will turn off the load. The OVP levels can be set from 0V to 10% higher than the rated voltage. Operation Main Press > Configure [F5] > Protection [F1] in order, and set the OVP Level.

  • Page 77: Unreg

    2-5-6. UnReg Description The UnReg error message will appear on the LCD display when the electronic load is operating in an unregulated state. Alarm The UnReg indicator will appear on the LCD display when the set load is inadequate for the power source. To clear the UnReg indicator, increase the current of power source or reduce the load requirements.

  • Page 78: Rvp

    2-5-8. RVP Description If the RVP is tripped, the LSG Series will turn off the load. Alarm The RVP error message indicates when the terminal voltage is negative. The Enter key must be pressed to clear the alarm message. Display Alarm message 01/Oct/2017 RS232...

  • Page 79: System Settings

    2-6. System Settings The following section covers a number or miscellaneous system settings such Input control settings Sound settings Alarm tone settings Display settings Language settings Input/output trigger setting All system settings are accessible in the Utility menu. 2-6-1. Input control settings Description The Knob Type setting determines if values are updated immediately as they are edited or if they are only updated...

  • Page 80: Alarm Tone Settings

    2-6-2-2. Alarm Tone Settings Description The alarm tone for the unit can be turned on or off in the utility menu. The alarm tone can be set separately. Alarm Tone: alarm of the protection (OCP, OPP, UVP, and OVP) settings. UnReg Tone: alarm of operating in an unregulated state.

  • Page 82: Trigger Out Width

    2-6-5-2. Trigger Out Width Description The Trigger Out Width setting sets the trigger output signal’s pulse width. Default setting 10.0us Utility Operation Help Press Shift > > Other [F5] in order, and set the Trig Out width. Trig Out width: 2.5–...

  • Page 83: Go-Nogo

    2-7. Go-NoGo The Go-NoGo configuration is used to create pass/fail limits on the voltage or current input. If the voltage/current exceeds the pass/fail limits, an alarm will be output. The Go-NoGo configuration can be used with the program operation to create complex pass/fail tests.

  • Page 84: Running A Go-Nogo Test

    2-7-2. Running a Go-NoGo Test Description Go-NoGo test results are displayed in the measurement panel of LCD display. GO indicates pass (good). NG indicates fail (no good). Operation Main Press > Configure [F5] > Go-NoGo [F3] in order. Set SPEC Test to ON. When SPEC Test is ON, SPEC will appear in the operation status panel of LCD display.

  • Page 85: Save / Recall

    2-8. Save / Recall The LSG Series can save and recall system settings, preset data, memory data, Go-NoGo settings as well as normal and fast sequences to internal memory or to USB. 2-8-1. File Structure Description The LSG Series file system can save files to internal memory (Media | Memory) and external memory (Media | USB).

  • Page 86: File Types

    2-8-2. File Types Memory Data Memory data contains general settings and is used for creating programs. Memory Data contains the operating mode, range, response and Go/NoGo settings. Memory data can be stored both internally and externally to USB. Preset data and Memory data store the same contents. Internal Format M001 ~ M256 External Format...

  • Page 87: Saving Files To Internal Memory

    2-8-3. Saving Files to Internal Memory Description When saving Memory, Setup or Preset Data to internal memory, the currently active setting is saved to one of the internal memory slots. Memory Data has 256 memory slots, Setup Data has 100 memory slots and Preset Data has 10 memory slots.

  • Page 88: Saving Files To Usb Memory

    2-8-4. Saving Files to USB Memory Description When saving files to USB memory, all the memory locations from the selected data type are saved as a single file to the USB file path directory. Memory Data Media | Memory Media | USB Example M001 MXXX...

  • Page 89: Recalling Files From Internal Memory

    Operation Press Save [F3] to save. (2/2) The file will be saved to the USB file path. Save Ok will be displayed when the save has been completed. If saving-over an existing file you will be asked to confirm the save. Press the Save[F3] key to confirm.

  • Page 90: Recalling Files From Usb Memory

    File Operation FUNC Press Shift > in order. Select Memory with the Media [F1] soft-key. Select the Data Type and choose the type of file to recall. Data Type: Memory Data, Setup Data, Preset Data Select which memory slot to recall from. Memory: M001 ~ M256 Setup Memory:...
  • Page 91 Display 01/Oct/2017 RS232 LOAD Save file type 87.5mA Data Type Memory Save File 175H_01.M Static Save file Recall File 175H_02.M name Path: usb: USB file path A Value Media File Save Recall Utility Operation Insert a USB drive into the USB port. File FUNC Shift...

  • Page 92: Recall Memory Safety Setting

    2-8-7. Recall Memory Safety Setting Description By default when you try to recall a file or setting from memory, a message will appear asking you to press the Enter key to confirm. This is the standard safety measure to ensure that the wrong file/setting is not recalled.

  • Page 93: Preset

    Press Rename [F3]. Use the on-screen display to enter the filename. A maximum of 8 characters. Delete Use the scroll wheel to move the cursor to the File or Folder file/folder you wish to delete. Press Delete [F4]. Press Delete [F4] again to confirm the deletion. 2-8-9.

  • Page 94: Default Settings

    2-8-10. Default Settings 2-8-10-1. Factory Default Settings Description The factory default settings can be recalled at any time. See page 177 ( ) for a list of 7-3. LSG Series Default Settings the factory default settings. File Operation FUNC Shift Press >...

  • Page 95: Function Menu

    3. Function MENU 3-1. Function Menu Overview The Function menu can be used as a quick access hub to the Program, Normal Sequence, Fast Sequence, OCP Test, OPP Test or BATT Test function. It is also used to set Function specific settings: Function Select.

  • Page 96: Turning On The Load With The Selected Function

    After a function is selected, it is then “turned on”. PROG , NSEQ , FSEQ , OCP , OPP , BATT . MPPT will Note appear at the top of the LCD display when the selected function is on. When in the Main menu, the PROG, NSEQ,FSEQ or OCP icon will appear prominently on the LCD display to remind the operator that a function is still on.

  • Page 97: Complete Ring Time

    3-1-3. Complete Ring Time Description The Complete Ring Time function turns the alarm on for a user-set amount of time after a program, sequence or OCP Test function has finished. Operation FUNC Press Select Complete Ring Time and select how long the alarm should ring after a function has completed.

  • Page 98: Nseq Timer

    3-1-4. NSEQ Timer Description The NSEQ Timer setting determines whether the timer for the Normal Sequence function displays the elapsed time or the remaining time for both the current step and the overall test time for the sequence. Operation FUNC Press Select NSEQ Timer and select whether the current step and total test time is displayed as elapsed time...

  • Page 99: Program Function

    3-2. Program function The LSG Series can create programs that are designed to step-through up to 16 pre-set load operations. The program function is a powerful tool that can allow you to perform a number of different operations in succession. The execution time of each step is user-defined.
  • Page 100 Illustration STEP 01 STEP 02 PROGRAM 1 STEP 16 STEP 01 STEP 02 PROGRAM 2 STEP 16 STEP 01 STEP 02 PROGRAM 3 STEP 16 Setting Overview A program contains the following settings for each step: Memory: The memory location of the load operation for the selected step (M001~M256).

  • Page 101: Create A Program

    3-2-2. Create a Program Before creating a program, it is necessary to set load operation in internal memory (M001 - M256) to use for Note each step, and to save it. See the save recall chapter for further details, page 73 ( 2-8.
  • Page 102 Operation Choose the On-Time in seconds. (2/2) The on-time setting determines how long the load is turned on for the selected step. The on-time is defined as the total test time minus the off-time. On-Time: 0.1 ~ 60 seconds Choose the Off-Time in seconds. The off-time setting determines how long the load is turned off between the end of the current step and the start of the next step.

  • Page 103: Create A Program Chain

    3-2-3. Create a Program Chain Before creating a program chain, make sure a number of programs have already been saved. These will be used Note to create the program chain. Chain Setting RS232 LOAD 01/Oct/2017 Starting program Display Overview for the chain Program Chain Set Start Select...

  • Page 104: Running The Program Function

    3-2-4. Running the Program function Description Turn the road on, the program function is running. Operation FUNC Press > Program [F1] in order. Turn program mode on by setting Program [F1] to on. PROG will appear at the top of the LCD display when Program is On.

  • Page 105: Sequence Function

    3-3. Sequence function The LSG Series supports both programs function and sequences function. The essential difference between programs and sequences is that programs can use different operating modes for each step while sequences use the same operating mode throughout the whole sequence. In effect sequences are used to create complex load simulations.
  • Page 106 Edit Normal Sequence configuration is split into Timing Edit Description configuration and Data Edit configuration. Timing Edit configuration is used to configure the actual sequences, such as mode, range, loops and chains. Data Edit configuration is used to create the actual steps used in each sequence.
  • Page 107 Data Edit Each step in a normal sequence contains the following Overview setting parameters: Setting Setting Range Description Step 0001 ~ 1000 Selects and displays the current step in the sequence. The number of available steps is dependent on the number of steps added using the Insert Point [F1] functions.
  • Page 108 TRIG OUT ON, OFF When TRIG OUT is set to ON, a trigger signal is output from the TRIG OUT BNC terminal at the start of the step. See page 154 ( 4-1-16-1. ) for details. Trigger Signal Output TRIG OUT: ON Input current Time Start of step...

  • Page 109: Timing Edit Configuration

    3-3-2. Timing Edit Configuration Edit Timing Sequence number Display Start sequence RS232 LOAD 01/Oct/2017 Timing Edit for Normal Sequence Start Seq.No: Memo: No Memo Mode: Last Load: Range: ILVL Last 0.000 mA Loop: Infinity Chain: N. Seq. Edit Previous Sequence Menu Sequence settings Operation...

  • Page 110: Data Edit Configuration

    3-3-3. Data Edit Configuration Data Edit Total number of steps Display Active step number RS232 LOAD 01/Oct/2017 Data Edit for Normal Sequences Step: 0001 0001 Value: 0.000 Time: 000 H: 00 M: 00 S 0.05ms LOAD: TRIG OUT RAMP: PAUSE: Step settings Insert Delete...

  • Page 111: Running A Normal Sequence Function

    3-3-4. Running a Normal Sequence function Description Turn the road on, the Normal Sequence function is running. Operation FUNC Press > Normal Sequence [F2] in order. Turn normal sequence mode on by setting N. Seq. [F1] to on. NSEQ will appear at the top of the LCD Display when N.

  • Page 112: Fast Sequence Function Overview

    3-3-5. Fast Sequence function Overview Description A fast sequence is comprised of a user-defined number of steps that can be executed at a high frequency. Unlike normal sequences, each step in a fast sequence has the same execution time (time base). This mode is only available for CC and CR mode.
  • Page 113 Timing Edit A Fast Sequence contains the following timing settings Overview for sequence: Setting Setting Range Description Memo 12 characters A user-created note for the currently selected sequence. Mode CC, CR Operating mode for the sequence. Range ILVL Low I range, Low V range IMVL Middle I range, Low V range IHVL...
  • Page 114 Data Edit Each step in a fast sequence contains the following Overview setting parameters: Setting Setting Range Description Step 0001 ~ 1000 Selects and displays the current step in the sequence. The number of available steps is dependent on the number of steps added using the Insert Point [F1] functions.
  • Page 115 FILL Overview The FILL function is used to evenly step up the current or resistance value settings from a starting step to a finishing step. The Fill Function can be used before or after steps are added to the fast sequence. Before: Will pre-fill each value within the fill range when a new step is added.

  • Page 116: Timing Edit Configuration

    3-3-6. Timing Edit Configuration Edit Timing 01/Oct/2017 RS232 LOAD Display Timing Edit for Fast Sequence Memo: Mode: Last Load: Range: ILVL Last 0.000 mA Loop: Infinity RPTSTEP 0004 Time Base: 600.00 ms F. Seq. Edit Previous Sequence Menu Sequence Operation FUNC Press >...

  • Page 117: Data Edit Configuration

    3-3-7. Data Edit Configuration Data Edit Display Total number of steps Active step number RS232 LOAD 01/Oct/2017 Data Edit for Fast Sequences RPT:0004 Step: 0001 0005 Value: 0.000 mA TRIG OUT: Step settings Insert Delete Previous Save Fill Point Point Menu Operation FUNC...
  • Page 118 Operation Presses FILL [F4] to use the fill function. Set the FILL (2/2) parameters. See page 103 for configuration details. The fill function can be used any number of times. Start_Value, End_Value, Start_Step, End_Ste FILL Display 01/Oct/2017 RS232 LOAD Fill Edit for Fast Sequences Start_Value: 0.000 End_Value:...

  • Page 119: Running A Fast Sequence Function

    3-3-8. Running a Fast Sequence function Description Turn the road on, the Fast Sequence function is running. Operation FUNC Press > Fast Sequence [F3] in order. Turn fast sequence mode on by setting F. Seq. [F1] to on. FSEQ will appear at the top of the display when F.

  • Page 120: Ocp Test Function

    3-4. OCP Test function Description The OCP test function creates an automatic test to test the OCP of power supply products. This test will test to see when the over current protection of a power supply is tripped and return the measurements for the voltage and current when the over current protection was tripped.

  • Page 121: Ocp Test Function Setting Parameters

    3-4-1. OCP Test function setting parameters Parameters Selects one of 12 OCP test setup memories. Memo A user-created note for the currently selected OPP function. Range Select the Range of CC Mode. (High, Middle, Low) Start Current Starting start current value for the test. (Start C) End Current The current value that will end the test.

  • Page 122: Ocp Test Function Setting

    3-4-2. OCP Test function setting Operation FUNC Press > OCP [F4] > OCP ON [F1] in order. Select No.: and select a test setup memory. No.: 1 ~ 12 Set the following parameters for the selected test setup above. See page 109 for details on each parameter. Memo, Range, Start C, End C, Step C Step T, Delay, Trig V, last C Each setting parameters are saved in the internal memory.

  • Page 123: Running A Ocp Test Function

    3-4-3. Running a OCP Test function Operation FUNC Press > OCP [F4] > OCP ON [F1] in order. Turn the load on. See page 84 ( 3-1-2.Turning on the Load with the Selected ) for the load on. Function The test current will increase from the Start C value to the End C value in steps according to the Step C value, until the test has finished.

  • Page 124: Results Of Ocp Test Function

    3-4-4. Results of OCP Test function Power Source The OCP Test will return the current setting of the last step when the power supply’s OCP was tripped. OCP tripped Indicating power supply OCP was tripped. RS232 01/Oct/2017 7.498 0.00 0.0000 OCP Test Set Curr: Fetch Volt:...
  • Page 125 Power Source Config Error indicates that the power supply voltage is Config Error less than the Trig V voltage setting after the test has started. This can indicate that the power supply output is not on or that the power supply output or Trig V is incorrectly configured.

  • Page 127: Opp Test Function

    3-5. OPP Test function Description The OPP test function creates an automatic test to test the OPP of power supply products. This test will test to see when the over power protection of a power supply is tripped and return the measurements for the voltage and current when the over power protection was tripped.

  • Page 128: Opp Test Function Setting Parameters

    3-5-1. OPP Test function setting parameters Parameters Selects one of 12 OPP test setup memories. Memo A user-created note for the currently selected OPP function. Range Select the Range of CP Mode. (High, Middle, Low) Start Watt Starting start watt value for the test. (Start W) End Watt The watt value that will end the test.

  • Page 129: Opp Test Function Setting

    3-5-2. OPP Test function setting Operation FUNC Press > Next Manu [F5] > OPP [F1] in order. Select No.: and select a test setup memory. No.: 1 ~ 12 Set the following parameters for the selected test setup above. See page 116 for details on each parameter. Memo, Range, Start W, End W, Step W Step T, Delay, Trig V, last W Each setting parameters are saved in the internal memory.

  • Page 130: Running A Opp Test Function

    3-5-3. Running a OPP Test function Operation FUNC Press > Next Manu [F5] > OPP [F1] in order, and Press OPP ON [F1] to turn OPP ON. Turn the load on. See page 84 ( 3-1-2.Turning on the Load with the Selected ) for the load on.

  • Page 131: Results Of Opp Test Function

    3-5-4. Results of OPP Test function Power Source The OPP Test will return the current setting of the last step when the power supply’s OPP was tripped. OPP tripped 01/Oct/2018 50.61 50.72 4.81 10.530 0:00:07 OPP Test Fetch Watt: Fetch Volt: 60.76 4.79 Watt:...
  • Page 132 Power Source Config Error indicates that the power supply voltage is Config Error less than the Trig V voltage setting after the test has started. This can indicate that the power supply output is not on or that the power supply output or Trig V is incorrectly configured.

  • Page 134: Batt Test Function

    3-6. BATT Test function Description The BATT test function creates an automatic test to test the discharge of Battery products. The test will discharge in a fixed mode (CC, CR, CP) and will end after a defined stop point (stop voltage, stop time, stop AH) has been detected.
  • Page 135 Example: Discharge CR mode Begin Discharge Stop Volt Current Setting CR mode SlewRate = SlewRate ? Stop Time Stop AH Example: Discharge CP mode Begin Discharge Stop Volt Current Setting CP mode SlewRate = SlewRate ? Stop Time Stop AH...

  • Page 136: Batt Test Function Setting Parameters

    3-6-1. BATT Test function setting parameters Parameters BATT No. Selects one of 12 BATT test setup memories. Memo A user-created note for the currently selected BATT Test function. Mode Select a discharge operation mode. (CC, CR, CP) Range Select I Range (High, Middle, Low) and V Range (High, Low).

  • Page 137: Batt Test Function Setting

    3-6-2. BATT Test function setting Operation FUNC Press > Next Manu [F5] > BATT [F2] in order. Set the following parameters for the selected test setup above. See page 124 for details on each parameter. BATT No., Memo, Mode, Range, Setting Slew Rate=, Slew Rate? Stop Volt, Stop Time, Stop AH, Datalog timer Each setting parameters are saved in the internal memory.

  • Page 138: Running A Batt Test Function

    3-6-3. Running a BATT Test function Operation FUNC Press > Next Manu [F5] > BATT [F2] in order, and Press BATT [F1] to turn the BATT function Turn the load on. See page 84 ( 3-1-2.Turning on the Load with the Selected ) for the load on.
  • Page 139 Test stop for BATT 01/Oct/2018 time tripped 50.61 4.92 0.00 0.000 0.0832 0.4077 Complete Discharging: CC, IHVH, 5.0000 A Stop Time: 0:01:00 TEST Exit Save Result Test stop for BATT 01/Oct/2018 AH tripped 50.61 0.00 4.90 0.000 0:00:12 0.1000 0.4880 Complete Discharging: CC, IHVH, 5.0000 A Stop AH: 0.10Ah...

  • Page 140: Save The Data For Batt Test Function

    3-6-5. Save the Data for BATT Test function Operation 1. When the Battery stop voltage, stop time or stop AH was tripped. Press TEST Result [F1] to view the test result waveform. Press Esc [F1] to exit the waveform view mode. 2.

  • Page 141: Mppt

    3-7. MPPT Background The MPPT (Maximum Power Point Tracking) function of LSG series can perform IV, PV characteristics and Pmax tracking tests of solar panels. Note The firmware Ver.1.29 or later is compatible with this extended function. Operation is not supported. Features of this It is possible to test the IV and PV characteristics of solar function...
  • Page 142 IHVL(I range high, V range low) ILVH(I range low, V range high) IMVH(I range middle, V range high) IHVH(I range high, V range high) Response Set the response speed of each discharge mode. CV mode: Slow, Fast CC mode: 1, 1/2, 1/5, 1/10 Sweep Range Set the conditions for the sweep range.
  • Page 143 When CV mode is...

  • Page 144: Edit Tracking Of Mppt Function

    When CC mode is 2. Set the following parameters. MPPT No. Memo Mode Range Response Sweep Range Start C (Start V) End C (End V) Step C (Step V) Step Time Detect Short (Disable only) 3-7-1. Edit Tracking of MPPT function Background Set tracking the maximum power point of MPPT function.

  • Page 145: Auto Load Of Mppt Function

    Time Interval) Measure Set the measurement time interval (1.0s to Interval 60.0s). (Measuremen t Time Interval) Panel operation FUNC 1. Press > Next Manu[F5] > MPPT[F4] Edit Tracking[F2]. 2. Set the following parameters. Tracking Track Step Track Step Time Pmax Detection Measure Interval 3-7-2.
  • Page 147 2. Set the following parameters. Auto Load on/off Start Time Stop Time Start MPPT 1. Insert a USB flash disk into USB port in the front panel. 2. Press MPPT [F1] to enable this function to start the test. 3. Press Shift + Load key to start the test. Continue testing until the end conditions are met.
  • Page 148 Example: MPPT test results To save the test result data, press Save [F3]. To see the graph of the maximum power point tracking test, presss Detect P'max [F1]. To see the graph of the MPPT exam, Press MPPT Result [F2].

  • Page 149: Data File Of Test Result

    If you want to have a screen shot, press Save [F3]. Press Esc [F1] to exit. 3-7-3. Data file of test result Background Test result data is saved as a CSV file. Example: Test conditions and results file <DATE> Date of test <Pmax Detection Method>...
  • Page 150 Example: Results file of IV and PV characteristics test < PMAX DETECTION Pmax detection results. RESULTS > (1) Start Time Test start time (2) MAX No. Data number when Pmax is maximum (3) MAX Voltage Voltage value when Pmax is maximum (4) MAX Current Current value when Pmax is maximum (5) MAX Power...
  • Page 151 Example: Results file of MPPT test (1) Start Time Test start time (2) Stop Time Test end time VOLT(V) Measured voltage value CURR(A) Measured current value POWER(W) Measured power value...

  • Page 152: External Control

    4. EXTERNAL CONTROL 4-1. Analog Control The Analog Control subsection describes how to use the frame control ports J1 for voltage or resistance control and the ports J3 for current/voltage monitor output. The control ports J2, located under the frame control ports J1 is used for parallel control.

  • Page 153: The Ports J3

    4-1-1-2. The ports J3 Description The wire connecting with the J3, please use AWG24~28. LSG-175AH/ Please peel the coating of the wire approximately 10mm. LSG-350AH / Please insert a wire in the terminal hole while pushing the LSG-1050AH Only button on the terminal hole of the J3. See the appendix on page 181 to view the contact pin assignment of the J3.

  • Page 154: External Voltage Control - Overview

    4-1-2. External Voltage Control - Overview Description External voltage control of the CC, CR, CV, CP and Cx+CV mode is accomplished using the J1 on the rear panel. An input voltage of 0~10V corresponds to 0% ~ 100% of the rated current (CC mode), rated voltage (CV and Cx+CV mode), or rated power (CP mode).

  • Page 155: External Voltage Control - Operation

    4-1-3. External Voltage Control – Operation Description External voltage control can be used to control the current, voltage, resistance and power for CC, CR, CV, CP and Cx+CV modes. Configuration for each the operating mode is the same. CC Mode Input current = rated current ×...
  • Page 156 CP Mode Input power = rated power × (external voltage/10) Input Power full scale adjusment after adjusment Rated Power External Voltage offset adjusment before adjusment Operation Turn off the power of LSG Series and the Power source. Connect the external voltage across pins 1 (or 2, +CV only) and 3 of the J1.

  • Page 157: Adjust Offset And Full Scale With Variable Resistor

    4-1-4. Adjust offset and full scale with variable resistor Variable Resistor in rear panel LSG-175AH/ LSG-350AH/ LSG-1050AH only CC/CR/CV/CP Operation CC, CR, CV, CP Apply a voltage of 1V to pin J1-1 based on the Mode level of pin J1-3. Turn VR2 with screwdriver to adjust the value to 10% of the rating in each the operating mode.

  • Page 158: External Resistance Control - Overview

    4-1-5. External Resistance Control - Overview Description External resistance control of the CC, CR, CV and CP modes is accomplished using the J1 on the rear panel. A resistance of 0kΩ~10kΩ is used to control the input current, voltage, resistance or power on the LSG Series. The input can be configured to vary in proportion to the external resistance or the inverse.

  • Page 159: External Resistance Control - Operation

    4-1-6. External Resistance Control – Operation Description External resistance control can be used to control the current, voltage, resistance and power for CC, CR, CV and CP modes. Configuration for each the operating mode is the same. CC Mode Proportional Control: Input current = rated current ×...
  • Page 160 CV Mode Proportional Control: Input voltage = rated voltage × (external resistance/10). Inverse Control: Input voltage = rated voltage × (1 - external resistance/10). Input Inverse control Voltage full scale adjusment Proportional control Rated after adjusment Voltage External Resistance offset adjusment 0Ω...

  • Page 161: Adjust Offset And Full Scale With Variable Resistor

    4-1-7. Adjust offset and full scale with variable resistor Variable Resistor in rear panel LSG-175AH/ LSG-350AH/ LSG-1050AH only CC/CR/CV/CP Operation Connect 1kΩ between J1-1 and J1-3. Proportional control Turn VR2 with screwdriver to adjust the value to 10% of the rating in each the operating mode. Connect 10kΩ...

  • Page 162: Turning The Load On Using External Control

    4-1-8. Turning the Load On using External Control Description The load can be turned on and off with an external switch connected to pins 7 and 12 of the J1 connector. Pin Inputs Pin 7 of the J1 connector is internally pulled up to 5V with a 10kΩ...

  • Page 163: Load On/Off Status

    4-1-9. Load On/Off Status Description Pins 13 and 17 (Load On Status) of the J1 connector is used to monitor the load status (on or off). Pin out The Load On Status pin is a photo-coupled open-collector output. Photo-coupler input: 30V max, 8mA, max. 4-1-10.

  • Page 164: I Range Status

    4-1-11. I Range Status Description Pins 14 and 15 (Range Status 1&0) of the J1 connector are used to monitor the current range status. The pin out combination determines the current range status. I Range Pin 14 Pin 15 Pin out The Range Status pins are 14, 15 photo-coupled open-...

  • Page 165: External Alarm Input

    4-1-13. External Alarm input Description Pins 10 and 12 of the J1 connector are the alarm inputs. An alarm can be activated/deactivated using external control with the J1 connector. When the alarm is activated, an EXT.AL message is also output. The alarm can be activated by an external device or by a parallel slave unit.

  • Page 166: Short Control

    4-1-15. Short Control Description The Short Signal Out pins 19 and 20 of the J1 connector are 30VDC 1A relay contact outputs. These outputs can be used to drive an external relay to physically short the terminal outputs. Pin Inputs The Short Signal Out pins are normally opens until the short function is activated.

  • Page 167: Current Monitor Output

    4-1-16-2. Current Monitor Output Description The voltage output from the IMON OUT terminal and from the IMON pin on the J3 connector is used to represent the current input level. The V Range used to represent the full scale current range from the IMON OUT terminal and from the IMON pin on the J3 connector depends on the I Range settings.

  • Page 168: Voltage Monitor Output

    4-1-16-3. Voltage Monitor Output Description The voltage output from the VMON OUT terminal and from the VMON pin on the J3 connector is used to represent the LSG-175AH/ current input level. LSG-350AH/ The V Range used to represent the full scale current range LSG-1050AH from the VMON OUT terminal and from the VMON pin on the only...

  • Page 169: Parallel Operation

    LSG-2100AS(H) booster pack can be used as a slave with the LSG-1050(H). If the master unit is LSG series, LSG-A series cannot be used as a slave. Similarly, if the master unit is the LSG-H series, the LSG-AH series cannot be used as a slave.

  • Page 170: Connection

    4-2-2. Connection Description The frame control ports J1 and J2 connectors are used for control during parallel operation. Up to 5 units can be used in parallel. Only the rear panel terminals can be used for parallel operation, the front panel terminals have a lower current Note rating and thus should not be used for parallel operation.

  • Page 171: Master Auto

    Operation Make sure all load units are turned off. (1/2) Make sure the power source is turned off. Connect the load units to the power source. Ensure the wire gauge is sufficient to handle the increase in current. Connect the Master unit to the slave units via the J1 and J2 connectors*.

  • Page 172: Turning The Load On

    Operation Main On the slave units, press > Configure [F5] > (2/2) Next Menu [F4] > Parallel [F1] in order, and set Operation to Slave. RS232 LOAD 01/Oct/2017 Configure 8.75A Operation Slave Fast Parallel Booster Fine A Value Previous Parallel Knob External Menu...

  • Page 173: Connection Using Option Plate

    Main On each unit, press > Configure [F5] > Next Menu [F4] > Parallel [F1] in order. Set the unit to Master Auto the Operation setting. Turn the Parallel and Booster settings to off. 4-2-6. Connection using option plate Description This section explains how to connect in parallel using the option plate.

  • Page 174: Remote Control

    5. REMOTE CONTROL This chapter describes basic configuration of IEEE488.2 based remote control. For a command list, refer to the programming manual, downloadable from TEXIO TECHNOLOGY website, www.texio.co.jp 5-1. Interface Configuration 5-1-1. Configure to USB Remote Interface PC side connector...

  • Page 175: Configure Gp-Ib Interface

    RS-232C Connection GTL-259 GTL-259 Remarks DB-9 female RJ-45 IN Pin Assignment & Name Name Connection Shield Shield Housing Housing Twisted pair Please refer to the programming manual for RS-485. 5-1-3. Configure GP-IB Interface To use GP-IB, the optional GP-IB port must be installed. See page 176 for installation details ( 7-2.GP-IB Installation Operation...

  • Page 176: Configure Lan Interface

    Pin Assignment Signal Signal Data I/O 1-4 13-16 Data I/O 5-8 Ground (DAV) NRFD Ground (NRFD) NDAC Ground (NDAC) Ground (IFC) Ground (SRQ) Ground (ATN) SHIELD Ground Single GND 5-1-4. Configure LAN Interface LAN 設定 Connector RJ-45 AutoMDIx Speck IPv4, Socket, HTTP DHCP ON/OFF IP Address...

  • Page 177: Rs-232C/Usb Remote Control Function Check

    This should return the Manufacturer, Model number, Serial number, and Firmware version in the following format. TEXIO,LSG-AH SERIES, XXXXXXXXXXXX, V.X.X.X.X For further details, please see the programming manual, available on the TEXIO TECHNOLOGY web site Note www.texio.co.jp 5-1-6. Using RealTerm to Establish a Remote Connection Description...
  • Page 178 Operation Download RealTerm and install according to the (1/2) instructions on the RealTerm website. Connect the LSG Series via USB (page 162) or via RS-232C (page 162). If using RS-232C, make note of the configured baud rate, stop bits and parity. Go to the Windows device manager and find the COM port number for the connection.
  • Page 179 Enter the query: *idn? Click on Send ASCII. The terminal display will return the following: TEXIO, LSG-XXXXA,EXXXXXXX,VX.XX.XXX (manufacturer, model, serial number, version) If RealTerm fails to connect to the LSG Series, please check all the cables and settings and try again.

  • Page 180: Gp-Ib Function Check

    5-1-7. GP-IB Function Check Functionality Please use the National Instruments Measurement & check Automation Controller software to confirm GP-IB functionality. See the National Instrument website, http://www.ni.com NI-488.2 library is required for operation check. For further details, please see the programming manual. Note Operation Start the NI Measurement and...

  • Page 181: Lan Function Check (Http)

    The String Received text box will display the query return: TEXIO, LSG-XXXXA,EXXXXXXX,VX.XX.XXX (manufacturer, model, serial number, version) The function check is complete. 5-1-8. LAN Function Check (HTTP) Operation To check LAN communication, specify the IP address set in the LSG from the PC web browser and display the page.

  • Page 182: Lan Function Check(Socket)

    Web Control Web Control allows you to operate the panel using mouse control on the browser. 5-1-9. LAN Function Check(Socket) Background To test the socket server functionality, National Instruments Measurement and Automation Explorer can be used. Required NI-VISA Functionality To start NI Measurement and Automation Explorer (MAX), check click the NI-MAX icon on the desktop.
  • Page 183 Enter the IP address and the port number of the LSG. The port number is fixed at 2268. Click the Validate button. A popup will appear if a connection is successfully established. Click Next. Next configure the Alias (name) of the LSG connection. Example：LSG_DC1 Click finish.
  • Page 184 The IP address of the LSG will now appear under Network Devices in the configuration panel. Select this icon now. Press Open VISA Test Panel. Click the Configuration icon. Click on I/O Settings. Make sure the Enable Termination Character check box is checked, and the terminal character is \n (Value: 0x0A).
  • Page 185 The *IDN? query will return the Manufacturer, model name, serial number and firmware version in the dialog box. TEXIO LSG-350A,000000,V1.28 TEXIO,PFR-100L50,TW1234567,01.01.12345678...

  • Page 186: Faq

    The performance does not match the specification. Make sure the device is powered on for at least 30 minutes, within +20°C~+30°C. This is necessary to stabilize the unit to match the specification. For more information, contact your local dealer or TEXIO TECHNOLOGY at www.texio.co.jp...

  • Page 187: Appendix

    7. APPENDIX 7-1. Replacing the Dust Filter Description The dust filter should be replaced twice a year. Not replacing the filter will reduce performance and may cause the LSG Series to malfunction. Procedure Turn the LSG Series off completely at the rear panel power switch.

  • Page 188: Gp-Ib Installation

    7-2. GP-IB Installation Description GP-IB and LAN are the extra optional. The following instructions describe how to install the optional GP-IB card: PEL-004 if necessary. Procedure Turn off the LSG Series. Remove the two screws holding the cover on the option bay.

  • Page 189: Default Settings

    7-3. Default Settings The following default settings are the factory configuration settings. Main Settings Setup Memory Settings Item Panel Settings (all 100 sets) Current(CC) Conductance(CR) Voltage(CV) Rated value Rated value Wattage(CP) Current range Voltage range 800 V /150V 800 V /150V Load on/off Load off Load off...
  • Page 190 Main > Configure > Go-NoGo Setup Memory Settings Item Panel Settings (all 100 sets) SPEC. Test Delay Time 0.0s 0.0s Entry Mode Value Value Maximum Voltage / Maximum Voltage / High Maximum Current Maximum Current Minimum Voltage / Minimum Voltage / Minimum Current Minimum Current Main >...

  • Page 191: Frame Control Connector Contacts

    7-4. Frame Control Connector Contacts Frame control ports J1 （LSG-175AH/LSG-350AH/LSG-1050AH） Pin name Pin number Description Ext-V In / 1 Used for voltage/resistance control of CC, CR, CV Ext-R In (+) and CP mode. 0V to 10V corresponds to 0% to 100% of the rated current (CC mode), rated voltage (CV mode), or rated power (CP mode).
  • Page 192 I Range 14 Range status output. Status1(+) Open collector output by a photo-coupler. I Range Status0(+) Alarm Out(+) 16 Turns on when an alarm (OVP, OCP, OPP, OTP, RVP, or UVP) is activated or when an external alarm is applied. Open collector output by a photo- coupler.
  • Page 193 J2 Connector Pin name Pin number Description N.C. N.C. N.C. SUM I MON 4 Connect to SUM I MON of the J1 connector. PRL OUT+ 5 Used during master/slave operation. Connected to PRL IN+ of the J1. PRL OUT- 6 Used during master/slave operation. Connected to PRL IN- of the J1.
  • Page 194 Frame control ports J1（LSG-2100ASH） Pin name Pin number Description N.C. N.C. A COM 3 Connected to the negative load input terminal. SUM I MON 4 Connected to SUM I MON of the J2 connector. PRL IN+ 5 Connected to PRL OUT+ of the J2 connector. PRL IN- 6 Connected to PRL OUT- of the J2 connector.
  • Page 195 Frame control ports J2 （LSG-2100AS/SH） Pin name Pin number Description N.C. N.C. N.C. SUM I MON 4 Connect to SUM I MON of the J1 connector. PRL OUT+ 5 Used during master/slave operation. Connected to PRL IN+ of the J1. PRL OUT- 6 Used during master/slave operation.

  • Page 196: Operating Mode Description

    7-5. Operating Mode Description 7-5-1. CC Mode CC Mode When the unit is set to CC mode it will operate as a constant current load when connected to a constant voltage source. This means the unit will sink a designated amount of current, up to the rated power level, regardless of the voltage.

  • Page 197: Cr Mode

    7-5-2. CR Mode CR Mode When the unit is set to CR mode it will operate as a constant resistance load when connected to a constant voltage (CV) or constant current (CC) source. This means the unit will maintain a set resistance, up to the rated power, regardless of the load voltage or current.

  • Page 198: Cp Mode

    7-5-3. CP Mode CP Mode When the unit is set to CP mode it will operate as a constant power operation when connected to a constant voltage source. This means the unit will maintain a set CP setting value, up to the rated current or voltage level, regardless of the load voltage.

  • Page 199: Cv Mode

    7-5-4. CV Mode CV Mode When the unit is set to CV mode it will operate as a constant voltage operation when connected to a constant current source. This means the unit will maintain the CV setting value, up to the rated power, regardless of the input current.

  • Page 200: Lsg-350A

    M Range L range 7-6-2. LSG-350A H range...

  • Page 201: Lsg-1050A

    M Range L Range 7-6-3. LSG-1050A H Range...

  • Page 202: Lsg-2100As

    M Range L Range 7-6-4. LSG-2100AS...

  • Page 203: Lsg-Ah Operating Area

    7-7. LSG-AH Operating Area 7-7-1. LSG-175AH H Range M Range L Range...

  • Page 204: Lsg-350Ah

    7-7-2. LSG-350AH H Range M Range L Range...

  • Page 205: Lsg-1050Ah

    7-7-3. LSG-1050AH H Range M Range L Range...

  • Page 206: Lsg-2100Ash

    7-7-4. LSG-2100ASH H Range M Range L Range...

  • Page 207: Lsg Series Specifications

    7-8. LSG Series Specifications The specifications apply when the LSG Series is powered on for at least 30 minutes to warm-up to a temperature of 20˚C to 30˚C, unless specified otherwise. All specifications apply when using the rear panel terminals. If the front panel terminals are used or if operating with long cables, remote sense must be connected to the terminals.

  • Page 208: Cr Mode

    L Range Resolution H Range 10mA M Range 0.1mA 0.2mA L Range 0.01mA 0.02mA 0.1mA Accuracy of Setting /500 kΩ H, M Range ±(0.2 % of set + 0.1 % of f.s. ) + Vin /500 kΩ L Range ±(0.2 % of set + 0.1 % of f.s.) + Vin Parallel ±(1.2% of set +1.1% of f.s.

  • Page 209: Cv Mode

    Accuracy of Setting /500 kΩ H, M Range ±(0.5 % of set + 0.5 % of f.s. ) + Vin /500 kΩ L Range ±(0.5 % of set + 0.5 % of f.s.) + Vin *1 Siemens[S] = Input current[A] / Input voltage[V] = 1 / resistance[Ω] *2 Converted value at the input current.

  • Page 210: Slew Rate

    L Range 0.1mW 0.1mW Accuracy of Setting / 500kΩ ±(0.6 % of set + 1.4 % of f.s. ) + Vin *1 It is not applied for the condition of the parallel operation. *2 M range applies to the full scale of H range. *3 Vin = Input terminal voltage of electric load.

  • Page 211: Dynamic Mode

    Ammeter H Range 0.000A~35.000A 0.000A~70.000A 0.00A~210.00A M Range 0.000A~3.5000A 0.000A~7.0000A 0.00A~21.000A L Range 0.00mA~350.00mA 0.00mA~700mA 0.0mA~2100.0mA Accuracy Stand alone: ±(0.2% of rdg +0.3% of f.s * Parallel Operation: ±(1.2% of rdg +1.1% of f.s.) Wattmeter 0.00W~175.00W 0.00W~350.00W 0.00W~1050W H, M Range L(CC/CR/ 0.000W~52.500W 0.000W~ 105.000W 0.00W~315.00W...
  • Page 212 Slew Rate Setting Range (CR Mode) H Range 250uA/us~250mA/us 500uA/us~500mA/us 1.6mA/us~1.6A/us M Range 25uA/us~25mA/us 50uA/us~50mA/us 160uA/us~160mA/us 2.5uA/us~2.5mA/us 5uA/us~5mA/us 16uA/us~16mA/us L Range Slew Rate Resolution Resolution Setting 250mA/us~2.5A/us 500mA/us~5A/us 1.6A/us~16A/us Resolution 100uA 200uA 600uA Setting 25mA/us~250mA/us 50mA/us~500mA/us 160mA/us~1.6A/us Resolution 10uA 20uA 60uA Setting 2.5mA/us~25mA/us 5mA/us~50mA/us...

  • Page 213: Soft Start

    Resistance Accuracy of setting (set > 0.03% of f.s) /500 kΩ H, M Range ±(0.5 % of set + 0.5 % of f.s. ) + Vin /500 kΩ L Range ±(0.5 % of set + 0.5 % of f.s.) + Vin set = Vin / Rset f.s.
  • Page 214 Overpower protection(OPP) 0.1W ~ 192.5W 0.3W ~ 385W 1W ~ 1155W or 110% of the maximum power of each range Load off or limit selectable Overheat protection(OTP) Turns off the load when the heat sink temperature reaches 95 °C Undervoltage protection(UVP) Turns off the load when detected.

  • Page 215: Lsg-H Series Specifications

    7-9. LSG-H Series Specifications The specifications apply when the LSG-H Series is powered on for at least 30 minutes to warm-up to a temperature of 20˚C to 30˚C, unless specified otherwise. All specifications apply when using the rear panel terminals. If the front panel terminals are used or if operating with long cables, remote sense must be connected to the terminals.

  • Page 216: Cc Mode

    7-9-3. CC Mode Model LSG-175AH LSG-350AH LSG-1050AH Operating Range H Range 0A~8.75A 0A~17.5A 0A~52.5A M Range 0A~0.875A 0A~1.75A 0A~5.25A L Range 0mA~87.5mA 0mA~175mA 0A~0.525A Setting Range H Range 0A~9.1875A 0A~18.3750A 0A~55.126A M Range 0A~0.91875A 0A~1.83750A 0A~5.5126A L Range 0mA~91.875mA 0mA~183.750mA 0A~0.55126A Default Setting H Range...

  • Page 217: Cr Mode

    7-9-4. CR Mode Model LSG-175AH LSG-350AH LSG-1050AH Operating Range H Range 1.75S~30uS 3.5S~60uS 10.5S~180uS (571mΩ~33.3kΩ) (285mΩ~16.6kΩ) (95.2mΩ~5.55kΩ) M Range 175mS~3uS 350mS~6uS 1.05S~18uS (5.71Ω~333kΩ) (2.85Ω~166kΩ) (952mΩ~55.5kΩ) L Range 17.5mS~0.3uS 35mS~0.6uS 105mS~1.8uS (57.1Ω~3.33MΩ) (28.5Ω~1.66MΩ) (9.52Ω~555kΩ) Setting Range H Range 1837.50mS~0mS 3675.00mS~0mS 11025.0mS~0mS (0.54422Ω~ (0.27211Ω~ (0.09070Ω~...

  • Page 218: Cv Mode

    7-9-5. CV Mode Model LSG-175AH LSG-350AH LSG-1050AH Operating Range H Range 5V~800V L Range 5V~80V Setting Range H Range 0V~840.00V L Range 0V~84.000V Resolution H Range 20mV L Range Accuracy of Setting H, L Range ± (0.2 % of set + 0.2 % of f.s.) Input current variation H, L Range 80mV...

  • Page 219: Slew Rate

    7-9-7. Slew Rate Model LSG-175AH LSG-350AH LSG-1050AH Setting Range (CC Mode) 0.1400mA/us~ 0.280mA/us~ 0.840mA/us~ H Range 140.0mA/us 280.0mA/us 840.0mA/us 0.01400mA/us~ 0.0280mA/us~ 0.0840mA/us~ M Range 14.000mA/us 28.00mA/us 84.00mA/us L Range 1.400uA/us~ 2.80uA/us~ 0.00840mA/us~ 1400.0uA/us 2800uA/us 8.400mA/us Setting Range (CR Mode) H Range 0.01400mA/us~ 0.0280mA/us~ 0.0840mA/us~...

  • Page 220: Meter

    7-9-8. Meter Model LSG-175AH LSG-350AH LSG-1050AH Voltmeter H Range 0.00V~800.00V L Range 0.000V~80.000V Accuracy ± (0.1 % of rdg + 0.1 % of f.s.) Ammeter H Range 0.0000A~8.7500A 0.000A~17.500A 0.000A~52.500A M Range 0.00000A~0.87500A 0.0000A~1.7500A 0.0000A~5.2500A L Range 0.000mA~87.500mA 0.000mA~175.00mA 0.00mA~525.00mA Accuracy Stand alone:：±(0.2 % of rdg + 0.3 % of f.s Parallel Operation: ±...
  • Page 221 Slew Rate Setting Range (CC Mode) H Range 0.1400mA/us~ 0.280mA/us~ 0.840mA/us~ 140.0mA/us 280.0mA/us 840.0mA/us M Range 0.01400mA/us~ 0.0280mA/us~ 0.0840mA/us~ 14.000mA/us 28.00mA/us 84.00mA/us L Range 1.400uA/us~ 2.80uA/us~ 0.00840mA/us~ 1400.0uA/us 2800uA/us 8.400mA/us Slew Rate Setting Range (CR Mode) H Range 0.01400mA/us~ 0.0280mA/us~ 0.0840mA/us~ 14.000mA/us 28.00mA/us...
  • Page 222 Current Accuracy ±0.4% of f.s. Model LSG-175AH LSG-350AH LSG-1050AH Resistance Setting Range H Range 1837.50mS~0mS 3675.00mS~0mS 11025.0mS~0mS (0.54422Ω~ (0.27211Ω~ (0.09070Ω~ 33333.3Ω,OPEN) 16666.7Ω,OPEN) 5555.56Ω,OPEN) M Range 183.750mS~0mS 367.500mS~0mS 1102.50mS~0mS (5.44218Ω~ (2.72109Ω~ (0.90703Ω~ 333333Ω,OPEN) 55555.6Ω,OPEN) 166666Ω,OPEN) L Range 18.3750mS~0mS 36.7500mS~0mS 110.250mS~0mS (54.4218Ω~ (27.2109Ω~ (9.07029Ω~ 3333333Ω,OPEN)

  • Page 223: Soft Start

    7-9-10. Soft Start Operation Mode CC,CR Selectable Time Range OFF, 1~ 200ms / Res: 1ms Time Accuracy ±(30%of set + 100us) 7-9-11. Remote Sensing Voltage that can be Compensated 2V for a single line 7-9-12. Protection Function Model LSG-175AH LSG-350AH LSG-1050AH Overvoltage protection(OVP) Turns off the load at 110% of the rated voltage...

  • Page 224: Lsg-A/Lsg-Ah Specifications

    7-10. LSG-A/LSG-AH Specifications 7-10-1. Sequence Normal Sequence Operation mode CC, CR, CV, CP Maximum number of steps 1000 Step Execution Time 0.05ms ~ 999h 59min Time resolution 0.05 ms (0.05ms ~1 min) 100 ms (1 min ~1 h) 1 s (1 h ~10 h)/10 s (10 h ~100 h) 1 min (100 h ~999 h 59 min) Fast Sequence Operation mode...

  • Page 225: Analog External Control

    7-10-3. Analog External Control Load on/off Control Input Turn on the load with low (or high) TTL level signal. Load on Status Output On when the load is on. (open collector output by a photo coupler) Range Switch Input Switch ranges L, M, and H using a 2-bit signal. Range Status Output Outputs range L, M, or H using 2-bit signal.

  • Page 226: Front Panel Bnc Connector

    7-10-4. Front Panel BNC Connector TRIG OUT Trigger output: Approx. 4.5V pulse width: Approx. 2us, output impedance: Approx. 500Ω. Outputs a pulse during sequence operation and switching operation. I MON OUT Current monitor output. LSG-A : 1V f.s. (H or L range) and 0.1V f.s. (M range) LSG-AH:10V f.s.
  • Page 227 Relative ≤80%RH(no condensation) Humidity Environment Indoor, Altitude < 2000m,Overvoltage categoryⅡ EN61010-1(Class1,Pollution 2),2014/35/EU Conformity EN61326-1（Class A), 2014/30/EU Conformity Battery Litium metal type CR123A x 1...

  • Page 228: Dimensions

    7-11. Dimensions 7-11-1. LSG-175A/ LSG-175AH/ LSG-350A/ LSG-350AH 213.8 Local Main File FUNC Utility Help Short Load Preset Shift CAL. Lock Clear Enter 175W 5 - 800V 0 - 8.75A V MON OUT I MON OUT TRIG OUT 400.5 464.4...

  • Page 229: Lsg-1050A / Lsg-1050Ah

    7-11-2. LSG-1050A / LSG-1050AH 441.4 427.8 Loc al Mai n Fil e F UNC Util ity Help Short Load O n/ Of f Preset Shift 1050W I MON TRIG C AL. Lo ck 1.5 - 150V Clear Ent er 0 - 70A 400.5 464.4 7-11-3.
