Arista 7300 Series Quick Start Manual

Modular data center switch
Hide thumbs Also See for 7300 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
QUICK START GUIDE
7300 Series
Modular Data Center Switch
DCS-7304
DCS-7324
Arista.com
DCS-7308
DCS-7316
DCS-7328
DCS-7304/8X3
Arista Networks
PDOC-00040-17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arista 7300 Series

Summary of Contents for Arista 7300 Series

  • Page 1 QUICK START GUIDE 7300 Series Modular Data Center Switch DCS-7304 DCS-7308 DCS-7316 DCS-7324 DCS-7328 DCS-7304/8X3 Arista Networks PDOC-00040-17 Arista.com...
  • Page 2 The trademarks, logos, and service marks ("Marks") displayed in this documentation are the property of Arista Networks in the United States and other countries. Use of the Marks is subject to the Arista Networks Terms of Use Policy, available at www.arista.com/en/terms-of-use. Use of marks belonging to other parties is for...

  • Page 3: Table Of Contents

    Contents Contents Chapter 1: Overview..................1 1.1 Scope..............................1 1.2 Receiving and Inspecting the Equipment..................1 1.3 Installation Process..........................1 1.4 Safety Information..........................2 1.5 Obtaining Technical Assistance......................2 1.6 Specifications............................. 3 Chapter 2: Preparation..................7 2.1 Site Selection.............................7 2.2 Tools Required for Installation......................8 2.3 Electrostatic Discharge (ESD) Precautions..................9 Chapter 3: Rack Mounting the Switch............
  • Page 4 A.3 Fan and Fabric Status Indicators....................34 A.4 Power Supply Status Indicators......................35 Appendix B: Fabric and Fan-only Module Description......37 B.1 Handling Fabric Modules........................ 38 B.1.1 Removing Fabric Modules....................39 B.1.2 Inserting Fabric Modules....................40 B.2 Handling Fan-only Modules......................41 B.2.1 Removing Fan-only Modules.....................41 B.2.2 Inserting Fan-only Modules....................

  • Page 5: Chapter 1: Overview

    Chapter 1 Overview Scope This guide is intended for properly trained service personnel and technicians who need to install Arista Networks Data Center Switches. This guide is intended for the following Arista Networks Data Center Switches: DCS-7304 DCS-7308 DCS-7316 DCS-7324...

  • Page 6: Safety Information

    Obtaining Technical Assistance Any customer, partner, reseller or distributor holding a valid Arista Service Contract can obtain technical support in any of the following ways: • Email: support@arista.com. This is the easiest way to create a new service request.

  • Page 7: Specifications

    (0 to 10,000 feet) (0 to 10,000 feet) Relative Humidity 5 to 90% 5 to 90% 5 to 90% Cooling 6000 W maximum 9000 W maximum 12000 W maximum Table 2: 7300 Series Power Specifications lists power specifications of modular switch components.
  • Page 8 Table 2: 7300 Series Power Specifications Module Type Part Number Power Draw Typical / Maximum Supervisor Modules DCS-7300(-D)-SUP 65 W / 80 W Linecard Modules DCS-7300X-32Q-LC 219 W / 372 W DCS-7300X-64S-LC 166 W / 232 W DCS-7300X-64T-LC 279 W / 430 W...
  • Page 9 Overview Table 3: 7300X Series Chassis Model Fabric Module Fan-only Module Fan Spare Line Card Power Supply DCS-7304 DCS-7304X-FM-F DCS-7304-S-FAN-F FAN-7002-F DCS-7300X- 32Q-LC PWR-3K-AC-F (Forward) DCS-7300X- 64S-LC PWR-2700-DC-F DCS-7300X- 64T-LC DCS-7304 DCS-7304X-FM-R DCS-7304-S-FAN-R FAN-7002-R DCS-7300X- 32Q-LC PWR-3K-AC-R (Reverse) DCS-7300X- 64S-LC PWR-2700-DC-R DCS-7300X- 64T-LC DCS-7308...
  • Page 10 50 or 60 Hz with switch. PWR-2700-DC-R DCS-7304 -48 to -60 VDC 100 A DC Adapter One DC adapter Reverse (Red) (Arista part per power supply PWR-2700-DC-F DCS-7308 80 A Forward (Blue) number 2 compression DCS-7316 CON-00581) lugs per DC...

  • Page 11: Chapter 2: Preparation

    Chapter 2 Preparation Site Selection Describes the location specifications. Consider the following criteria when selecting a site to install the switch: Floor Space: Install the switch in an area that provides adequate clearance for removing front and rear components. The following figure displays switch clearance requirements. Figure 2-1: Switch Component Removal Footprint 1.

  • Page 12: Tools Required For Installation

    Orient the switch to ensure the air intake modules face the cool aisle. If the airflow direction is incompatible with the installation site, contact your sales representative to obtain modules that circulate air in the opposite direction. • Rack Space: Install the switch in a 19" rack or cabinet. The switch height depends on the switch model, as specified in the Table 1: 7300 Modular Switch and Component Specifications.

  • Page 13: Electrostatic Discharge (Esd) Precautions

    Preparation Two-Post Conventional Rack • Screws or rack mounting nuts and bolts. • Screwdriver. Four-Post Tool-less Rack No additional equipment is required. Four-Post Conventional Rack • Screws or rack mounting nuts and bolts. • Screwdriver. Electrostatic Discharge (ESD) Precautions Observe these guidelines to avoid ESD damage when installing or servicing the switch. •...

  • Page 14: Chapter 3: Rack Mounting The Switch

    Chapter 3 Rack Mounting the Switch Important: The rack mounting procedure is identical for all modular switches. Illustrations in this chapter depict the mounting of an unpopulated DCS-7304 chassis. Les procédure de montage du bâti est identique pour tous les commutateurs modulaires. Illustrations dans ce chapitre montrent le montage d’un châssis de DCS-7304 inhabité.

  • Page 15: Inserting The Switch Into The Rack

    Rack Mounting the Switch 1. Orient the switch chassis and the two center-mount brackets (Figure 3-1: Attaching the Center-mount Brackets). Figure 3-1: Attaching the Center-mount Brackets Position the flanges that attach to the rack posts toward the front of the chassis. 2.

  • Page 16: Four-Post Rack Mount

    2. Move the chassis to the rack using a mechanical lift (Figure 3-3: Lifting the Switch Chassis). If modules are inserted in the chassis, use the lift carefully to avoid damaging any components. Figure 3-3: Lifting the Switch Chassis 3. Lift the chassis into the rack. 4.
  • Page 17 Rack Mounting the Switch The finished assembly for rack mounting the device is shown in the Figure 3-5: Left Shelf – Inner View. Detailed mounting instructions for all rack types start from Shelf Installation. Figure 3-4: Switch Shelves Installed Note: The parts list for rack kit installations for round and threaded hole racks are listed in the Parts List.
  • Page 18 Left Shelf – Inner View displays latches that are closed. The insets display open latches The inner side of each shelf is oriented toward the center of the rack. Figure 3-5: Left Shelf – Inner View 1 Front post attachments 4 Rear post attachments 7 Stabilizer bar (left shelf only) 2 Front latch (closed)

  • Page 19: Component Placement

    Rack Mounting the Switch Rack posts and guide pins inserted into the rack are visible from the outer side of the ear (Inset B). To install ears into posts with threaded or round holes, remove both plugs from each ear (if required for rail set), then install the ears with screws that fit the rack.

  • Page 20: Switch Mounting Process

    3.2.3 Switch Mounting Process The switch mounting process consists of three steps: 1. Installing the shelves. 2. Installing the mounting ears. 3. Placing and securing the switch upon the shelves. 3.2.3.1 Shelf Installation The installation process for each shelf is identical. The shelves must be installed on the same horizontal level. In the following section, inner side illustrations feature the left shelf, and outer side illustrations feature the right shelf.
  • Page 21 Rack Mounting the Switch 4. Glide the slide-end to a position outside its rear rack post (Figure 3-10: Adjusting the Right Shelf). Figure 3-10: Adjusting the Right Shelf 1 Front left rack post 2 Front right rack post 3 Rear right rack post 5.
  • Page 22 Perform the following procedure for each mounting ear: 1. Install the mounting ear on the front post by inserting the front rack plugs (if present) and guide pins in the racks specified for the switch model that is being installed (Figure 3-12: Attaching the Right Mounting Ear).
  • Page 23 Rack Mounting the Switch 1. Rotate the stabilizer bar from the left shelf toward the right shelf such that the nob at the end of the stabilizer bar inserts into the notch at the rear of the ledge of the right shelf. Figure 3-13: Both Switch Shelves Installed 2.

  • Page 24: Chapter 4: Powering The Modular Switch

    Specifications for information regarding your specific system. The Table 8: Power Supply Capacity and Requirements for 7300 Series Modular Switches list the nyumber of modules each chassis can contain and the minimum operating requirements for each model. Table 8: Power Supply Capacity and Requirements for 7300 Series Modular Switches...

  • Page 25: Cabling The Ac Power Supply

    Powering the Modular Switch Cet équipement doit être mis à la terre. Ne jamais modifier le conducteur de terre. Cet appareil nécessite de protection contre les surintensités. Cabling the AC Power Supply 4.1.1 Grounding the Switch After mounting the switch into the rack, connect the switch to the data center ground. Figure 4-1: Grounding Pad and ESD Grounding Pad Sockets display the grounding pads' location on the front panel (left illustration)

  • Page 26: Connecting Power Cables To An Ac Power Supply

    4.1.2 Connecting Power Cables to an AC Power Supply Figure 4-2: Power Input Sockets display an AC power supply module, including the power input socket. Figure 4-2: Power Input Sockets The power supplies require power cables that comply with the IEC-320 C19 plug. The accessory kit provides 14 AWG and C19 to C20 power cables.

  • Page 27: Dc Power Supplies

    Le - 48V et câbles de batterie-retour sont une paire courir à côté de l'autre et doivent être à peu près la même longueur. 4.2.1 DC Power Supplies The 7300 Series chassis supports two DC power supplies (Figure 4-4). Only specified power supplies are available for use in a particular switch configuration.

  • Page 28: Wire And Lug Preparation

    1 Primary ground 4.2.2 Wire and Lug Preparation Before installing, remove power from DC circuits by turning off the power line servicing the circuits. Prepare the stranded wiring before you begin a DC power installation. 1. Stranded copper wiring is required. •...

  • Page 29: Pwr-3K-Dc-Blue Power Supply

    Powering the Modular Switch 2. Select agency-approved compression (pressure) lugs for wiring terminations with a single 5/16" mounting hole. Two-hole lugs should have 1/4" mounting holes on 5/8" centers. The PWR-2700W-DC-R ground lug is a right-angle lug. Check the terminations for the appropriate wire size.
  • Page 30 4.3.2 Connecting the Ground to PWR-2700-DC-R Power Supply The primary ground on the system requires a 2 – 4 AWG 5/16 inch lug per power supply. Figure 4-8: PWR-2700-DC-R Power Supply displays the PWR-2700-DC-R power supply without the DC adapter. Figure 4-8: PWR-2700-DC-R Power Supply 1 Primary ground 1.

  • Page 31: Chapter 5: Connecting Serial And Management Cables

    Supervisor modules contain console, management, and USB ports. Figure 5-1: Supervisor Ports (DCS-7300(- D)-SUP) displays status LED and port locations on the 7300 Series Modular switch supervisor. Figure 5-1: Supervisor Ports (DCS-7300(-D)-SUP) 1 Status LED 5 Fabric module status LED...

  • Page 32: Connecting Linecard Modules And Cables

    Connecting Linecard Modules and Cables Install required SFP, SFP+, and QSFP+ optic modules in linecard module ports (Figure 5-2: SFP or SFP+ Ports). Connect cables as required to linecard module ports or RJ45 ports. Figure 5-2: SFP or SFP+ Ports CAUTION: Excessive bending can damage interface cables, especially optical cables.

  • Page 33: Chapter 6: Configuring The Switch

    Chapter 6 Configuring the Switch Arista switches ship from the factory in Zero Touch Provisioning (ZTP) mode. ZTP configures the switch without user intervention by downloading a startup configuration file or a boot script from a location specified by a DHCP server. To manually configure a switch, ZTP is bypassed. The initial configuration provides one username (admin) that is accessible only through the console port because it has no password.
  • Page 34 11. When the management port IP address is configured, use this command to access the switch from a host using the address configured in Step 9: ssh admin@192.0.2.8 Refer to the Arista Networks User Manual for complete switch configuration information.

  • Page 35: Appendix A: Status Indicators

    Appendix A Status Indicators This section discusses the several status indicators, their location, and the meaning of their display status. Supervisor Module While the front panel of each switch can house two supervisors, switch operations require only one. Supervisors display switch component status and contain Ethernet management and console ports. Fabric and Fan-only Module Description displays the supervisor location on each switch.

  • Page 36: Linecard Module Indicators

    Table 9: Supervisor Activity LED States LED Name LED State Supervisor State Status Module failed or is improperly inserted. Green Supervisor operating normally. Module failed. Active Supervisor is not active. Green Supervisor is active and controlling the switch. Component Activity Status LEDs LEDs located below the vents and left of the input ports display summary indicators for power supplies, fabric modules, fan modules, and line cards.
  • Page 37 Status Indicators The figures in Linecards indicate the location of the LEDs on each linecard. Figure A-2-left displays the status LED and Port LEDs on the left side of the DCS-7300X-64S-LC linecard. Figure A-2-right displays the status LED and Port LEDs on the left side of the DCS-7300X-32Q-LC linecard. Figure A-2: Linecard Status LEDs (DCS-7300X-LC) 1 Status LED 2 Upper port status LED...

  • Page 38: Fan And Fabric Status Indicators

    Table 11: Linecard Status LED States LED State Status Linecard not inserted. Green Linecard is operating normally. Yellow Linecard administratively shut down. Module has failed. The linecard provides LEDs for each port module socket: • Figure A-2: Linecard Status LEDs (DCS-7300X-LC) display SFP module LEDs.

  • Page 39: Power Supply Status Indicators

    Status Indicators The fan and fabric module indicators are displayed in the Figure A-4: Fan Status and Fabric Status LEDs. The fan handle indicates the fan direction. All fan modules must have the same color handle. Figure A-4: Fan Status and Fabric Status LEDs 1 Handle (color indicates airflow orientation) 3 Fan module installation indicator 2 Fabric status LED...
  • Page 40 • Rear panel modules and front panel modules have different color handles. Figure A-5: Power Supply 1 Release 3 DC OK LED 5 AC OK LED 2 Ejector (color indicates 4 Fault LED airflow orientation) Table 15: Power Supply Status interprets the states of the Power Supply Status LED.

  • Page 41: Appendix B: Fabric And Fan-Only Module Description

    Appendix B Fabric and Fan-only Module Description Each switch has four rear slots for fabric modules. In addition to providing the data transport media, fabric modules contain fan modules that circulate air through the switch. Proper switch operation requires the population of each rear slot.
  • Page 42 Note: On the 7308, if a fan-only module is not inserted, a metal piece covers the slot, as shown below. 1 Metal covering Part Numbers Table 16: Fabric and Fan-only Module Part Numbers lists the part numbers of Fabric and Fan-only Modules. Table 16: Fabric and Fan-only Module Part Numbers Switch Model Fabric Module...

  • Page 43: Handling Fabric Modules

    Fabric and Fan-only Module Description Handling Fabric Modules Figure B-2: Locking Mechanism: DCS-7316 Fabric depicts a DCS-7316 chassis with the inner two fabric modules installed. Lock levers are shown in the open and closed position, along with the button that releases them into the open position.

  • Page 44: Inserting Fabric Modules

    5. Grasp the module frame and pull it until it is completely outside the chassis. Figure B-3: Fabric Module Removal: Initial Position and Opening the Lock-Levers Figure B-4: Fabric Module Removal: Edging the Module Out and Closing the Lock-Levers The DCS-7316 fabric module is almost three feet long and weighs close to 40 pounds. Use necessary precautions to safely manage the component outside of the chassis.

  • Page 45: Handling Fan-Only Modules

    Fabric and Fan-only Module Description 2. Slide the module into the chassis until it’s within three to four inches of being fully inserted (Fabric Module- right). 3. Press the Release Button to release the lock levers into the open position (Fabric Module-left).

  • Page 46: Inserting Fan-Only Modules

    4. Return the lock levers to the closed position. 5. Grasp the module frame and pull the module until it is completely outside of the chassis. B.2.2 Inserting Fan-only Modules The fabric module insertion process is the inverse of the removal procedure. These instructions describe the method of inserting the fabric module into a chassis.

  • Page 47: Appendix C: Parts List

    Adapter), Terminal Block, M4 Lug. RJ-45 Patch Panel Cable, 2 meters. RJ-45 to DB9 Adapter Cable, 2 meters. Warning: All provided power cables are for use only with Arista products. Câbles d’alimentation doivent être utilisés uniquement avec des produits de Arista. Warning:...

  • Page 48: Four-Post Rack Mount Parts

    Four-Post Rack Mount Parts Quantity Description Mounting Ears Left shelf Right shelf Figure C-2: Four-Post Rack Mount Parts 1 Left shelf 2 Right shelf 3 Mounting ears Four-Post Rack Mount Kit (Optional - 106-575-074-00) Part Number Quantity Description Rack Type 036-030-014 M610 clip nuts Round hole...
  • Page 49 Parts List Quantity Description Center-mount brackets. 16 (DCS-7304) M4x8 panhead Phillips screws. 20 (DCS-7308) Figure C-3: Two-Post Rack Mount Parts 1 Center-mount brackets (7308 only) 2 Center-mount brackets (7304 only) 3 M4x8 panhead Phillip Screws...

  • Page 50: Appendix D: Front Panels

    Appendix D Front Panels This Front Panel section displays the front panel of all switches covered by this guide. DCS-7304 and DCS-7324 Front Panel (fully populated) 1 Supervisor modules (slots 1-2) 2 Linecard modules (slots 3-6) 3 Power supply modules 4 Earth grounding pads (behind covers)
  • Page 51 Front Panels DCS-7308 and DCS-7328 Front Panel (fully populated) 1 Supervisor modules (slots 1-2) 2 Linecard modules (slots 3-10) 3 Power supply modules 4 Earth grounding pads (behind covers)
  • Page 52 DCS-7316 Front Panel (fully populated) ESD grounding port Linecard modules (slots 3-10) Supervisor modules (slots 1-2) Linecard modules (slots 11-18) Power supply modules...

  • Page 53: Appendix E: Rear Panels

    Appendix E Rear Panels This Rear panel section displays the rear panel of all switches covered by this guide. DCS-7304 and DCS-7324 Rear Panel 1 ESD grounding port 2 Fabric modules 3 Fan modules DCS-7308 and DCS-7328 Rear Panel 1 ESD grounding port 2 Fabric modules 3 Fan modules...
  • Page 54 DCS-7316 Rear Panel 1 ESD grounding port 2 Fabric modules 3 Fan modules 4 Power Supply Modules...

  • Page 55: Appendix F: Linecards

    Appendix F Linecards This linecard section displays the linecards supported by modular switches covered by this guide. DCS-7300X-32Q-LC 1 Status LED 2 10G/40G port LEDs DCS-7300X-64S-LC 1 Status LED 3 10G/40G Port LEDs 2 10G upper port LEDs 4 10G lower port LEDs DCS-7300X-64T-LC 1 Status LED 3 10G/40G Port LEDs...
  • Page 56 DCS-7320X-32C-LC and DCS-7300X3-32C-LC 1 Status LED 2 100G port LEDs DCS-7300X3-48YC4-LC 1 Status LED 3 QSFP 100G port LEDs 2 SFP 25G port LEDs 4 SFP 25G port LEDs...

  • Page 57: Appendix G: Taiwan Rohs Information

    Appendix G Taiwan RoHS Information This section provides the Taiwan RoHS information for switches covered by this guide. For the Taiwan BSMI RoHS Table, go to https://www.arista.com/assets/data/pdf/AristaBSMIRoHS.pdf.
