Stinger SRX-JK11128 Manual

Introduction and Features
The SRX-JK11128 is a complete radio installation kit for 2011-2018 Jeep Wrangler JK and the Stinger ix212 Infotainment system.
All modules and cables are included to retain important features of the factory system, including: steering wheel-mounted radio
controls, USB port, factory amplifier and AM/FM reception. Data integration with the vehicle and the Stinger ix212 adds advanced
vehicle information, performance gauges, off-road enhancements, four programmable camera triggers, and factory amplifier
control. Plug & Play wiring harnesses, along with a "zero-modify" mounting system, allow for a quick and easy installation without
the need to cut or splice any factory wiring or modifying the vehicle trim panels or sub-dash.
Important Notes
We recommend reading this manual thoroughly to familiarize yourself with the entire process prior to
beginning the installation. Although this kit does not require any modifications to the vehicle, it does
require following the steps as shown to ensure it is installed correctly with no damage to the vehicle.
1. Does not retain the following factory features:
● Uconnect
®
● SiriusXM Satellite Radio
®
2. To retain SiriusXM Satellite Radio would require purchasing a SXV300 SiriusXM tuner.
Recommended Tools
Plastic Panel Tool
7mm, 10mm Socket
Ratchet
terms OEM, Jeep®, Wrangler®, and Gladiator® all terms are used strictly for identification purposes only. It is
#1 Phillips Screwdriver
#2 Phillips Screwdriver
Flathead Screwdriver
Stinger Solutions is not affiliated with FCA US LLC. Jeep® is a registered trademark of FCA US LLC. The
not implied that any part listed is a product of, or approved by, Fiat Chrysler Automobiles.
Flush Cutters Painters Tape
Wire Feeder
Cloth Tape
© 2024 Stinger
SRX-JK11128
Installation & Integration Kit
for 2011-2018 Jeep Wrangler JK
®
Rev: V1
Date:122624
Page 1
