- Page 1 INSTALLATION INSTALLATION INSTRUCTIONS Technician HYDRO S2 Indoor unit System ADAPT, VERSI...
- Page 2 Related Rights Act and without the express consent of Kronoterm d.o.o. (hereinafter: Kronoterm) is illegal and punishable by fine. We reserve the right to make changes. Despite taking extensive care to ensure the accuracy of all pictures and descriptions, Kronoterm reserves the right to make corrections, changes to technical details, and changes to pictures with no prior notice.
-
Page 3: Table Of Contents
APPLIANCE ITSELF ..............6 INCLUDED PARTS FOR INDOOR UNIT HYDRO S2 ..................6 INSTALLATION ������������������������������������������������������������ 7 INSTALLING THE HYDRO S2 INDOOR UNIT ...7 INSTALLING THE HYDRO S2 INDOOR UNIT AND HYDRO A2 WALL MOUNT ..........9 INSTALLING THE HYDRO S2 INDOOR UNIT AND HYDRO P2 WALL MOUNT ..........12... -
Page 4: Important Information
Installation instructions Hydro S2 System ADAPT, Versi IMPORTANT INFORMATION NOTE These instructions describe the appliance Read these instructions thoroughly before installation and maintenance process. Only beginning installation� properly qualified individuals may install or maintain Kronoterm appliances. Read the Any processing or replacement of the instructions thoroughly before installation, appliance’s original integral parts will... -
Page 5: Safety Warnings And Instructions
Installation instructions Hydro S2 System ADAPT, Versi 1�3� SAFETY WARNINGS AND WARNING INSTRUCTIONS This appliance is not to be played with� DANGER The appliance may only be used by people who have learned about its safe operation Do not clean the appliance or interfere with and who understand the potential dangers it while it is in operation�... -
Page 6: Disposing Of Packaging And The
Installation instructions Hydro S2 System ADAPT, Versi 1�4� DISPOSING OF PACKAGING AND THE APPLIANCE ITSELF Separate packaging according to its material� Remove the appliance in accordance with valid legislation on electronic waste� 1�5� INCLUDED PARTS FOR INDOOR UNIT HYDRO S2... -
Page 7: Installation
Position of the indoor unit Mark on the wall the position of the holes for the mount. See page 7 for instructions on installing the Hydro S2 indoor unit and Hydro wall mount. See page 9 for instructions on installing the Hydro S2 indoor unit and Hydro A2 wall mount�... - Page 8 Installation instructions Hydro S2 System ADAPT, Versi Figure 4: Drilling holes into the wall Figure 6: Affixing the mount on the wall 1. Drill a hole for the appropriate wall inserts Ø8. 1. Screw in the screws and affix the mount on the wall.
-
Page 9: Hydro A2 Wall Mount
Installation instructions Hydro S2 System ADAPT, Versi 2�1�4� ATTACHING THE PIPES TO THE OUTDOOR 2�2� INSTALLING THE HYDRO S2 INDOOR UNIT UNIT AND HYDRO A2 WALL MOUNT 2�2�1� INCLUDED PARTS FOR THE HYDRO A2 WARNING WALL MOUNT You received the following components upon delivery... - Page 10 Installation instructions Hydro S2 System ADAPT, Versi 2�2�3� INSTALLING THE HYDRO A MOUNT CAUTION Choose the right insert based on the type of wall construction and in consultation with a construction expert� 47,5 Figure 12: Marking the spot for the hole in the wall Position of the Ø...
- Page 11 Installation instructions Hydro S2 System ADAPT, Versi Figure 18: Connecting the indoor unit to the mount 1. Insert the included M8 screws into the holes shown, along with the washers and the nuts. 2. Screw in the screws. Figure 16: Affixing the mount 2�2�5�...
-
Page 12: Hydro P2 Wall Mount
Installation instructions Hydro S2 System ADAPT, Versi 2�2�6� CONNECTING THE PIPES TO THE DHW 2�3� INSTALLING THE HYDRO S2 INDOOR SYSTEM AND HEATING SYSTEM UNIT AND HYDRO P2 WALL MOUNT 2�3�1� INCLUDED PARTS FOR THE HYDRO P2 WALL MOUNT You received the following (extra) components upon... - Page 13 Installation instructions Hydro S2 System ADAPT, Versi 2�3�3� INSTALLING THE HYDRO P MOUNT CAUTION Choose the right insert based on the type of wall construction and in consultation with a construction 47,5 expert� Figure 23: Marking the spot for the hole in the wall Position of the Ø8 holes...
- Page 14 Installation instructions Hydro S2 System ADAPT, Versi Figure 29: Connecting the indoor unit to the mount 1. Insert the included M8 screws into the holes shown, Figure 27: Affixing the mount along with the washers and the nuts. 1. Screw in the screws.
- Page 15 Installation instructions Hydro S2 System ADAPT, Versi 2�3�6� CONNECTING THE PIPES TO THE HEATING SYSTEM Figure 33: Connecting the pipe to the heating system – supply pipe and heating DHW – return pipe Heating DHW* – return pipe – G5/4’’ IT Figure 31: Connecting the pipe sets to the buffer tank Heating/cooling* –...
-
Page 16: Drain
Installation instructions Hydro S2 System ADAPT, Versi WARNING CAUTION If you do not connect the DHW reservoir to the indoor The condensation drain must have a trap, otherwise unit, you must shut connections 3 and 4 with caps� the appliance could be damaged�... -
Page 17: Turning On The Electricity
Installation instructions Hydro S2 System ADAPT, Versi TURNING ON THE ELECTRICITY 3�2� WHERE TO CONNECT THE ELECTRIC ELEMENTS Electrical system elements connect to the terminals in 3�1� PREPARATION electrical box. 3�1�1� REMOVING THE FRONT SIDE PANEL Figure 39: Connection spots... - Page 18 Installation instructions Hydro S2 System ADAPT, Versi DANGER Before turning the appliance on, one of the manufacturer’s authorized technicians must inspect L3L2 L1 N the electrical connection to ensure the appliance’s proper and efficient operation� UNAUTHORIZED PERSONS ARE STRICTLY PROHIBITED FROM TAMPERING WITH THE ELECTRICAL WIRING�...
-
Page 19: Connecting The Controller And The Thermostats
Installation instructions Hydro S2 System ADAPT, Versi 3�5� CONNECTING THE COMMUNICATION CABLE TO THE OUTDOOR UNIT Ready the communication cable (FTP 5e) for connection between the indoor unit and outdoor unit L3L2 L1 N as follows: 5,7,6,8 Figure 43: Connecting the single-phase power cable Figure 45: Preparation of FTP cable to the terminals for a 4 kW electric heating appliance�... -
Page 20: Connecting The Signaling Components
Installation instructions Hydro S2 System ADAPT, Versi 3�6� CONNECTING THE SIGNALING 3�6�2� CONNECTING THE TEMPERATURE COMPONENTS SENSOR OF HEATING/COOLING LOOP 1 The number of controlling components (circulation pumps, mixing valves, temperature sensors, etc.) depends on the heating/cooling system and the MODBUS manner in which it was wired. - Page 21 Installation instructions Hydro S2 System ADAPT, Versi 3�6�4� CONNECTING THE CIRCULATION PUMP 3�6�6� CONNECTING THE TEMPERATURE TO CIRCULATE DHW SENSOR FOR THE DHW TANK MODBUS P. SUPPLY MODBUS P. SUPPLY 12 V 28-19-36-6663-00 12 V 28-19-36-6663-00 ~400 V ~230 V...
-
Page 22: Technical Characteristics
Installation instructions Hydro S2 System ADAPT, Versi TECHNICAL CHARACTERISTICS 4�1� CONNECTIONS OF THE KSM REGULATOR MODBUS P. SUPPLY 12 V 28-19-36-6663-00 Figure 53: Regulator KSM Label Description Label Description Temperature – DHW tank Output – cooling Temperature – outdoor O 11+ Output –... -
Page 23: Maintenance
Installation instructions Hydro S2 System ADAPT, Versi MAINTENANCE CAUTION The wiring and other hardware must be inspected visually once per year� If any faults or malfunctions are found, contact an authorized technician� Order a service inspection from an authorized technician once per year�... - Page 24 Kronoterm d.o.o. Trnava 5e, 3303 Gomilsko, SLO T +386 3 703 16 20 www.kronoterm.com info@kronoterm.com...
