Page 1: Service Manual
Service manual Heat pump for sanitary water WP2 LF-202S WP2 LF-302S ID.: 17-16-24-3007-05 / 6.2017 SERVICE SERIAL NUMBER OF DATE OF INTRODUCTION REVISION THE INTRODUCTION EXCEPTION OF CHANGES OF CHANGES 116240875 116240860 18.6.2016... - Page 2 This document is copyrighted. Any use outside the provisions of the copyright law without the permission of Kronoterm d.o.o. is illegal and punishable by law. All previous versions of this document are void. We reserve the right to make changes and printing errors.
-
Page 3: Table Of Contents
1. Table of Contents Table of Contents ....................2 Structure of serial number ..................3 Components ......................3 Cover removal – cover of electronic ..............7 Electrical wiring diagram ..................8 Technical data ......................10 ID.: 17-16-24-3007-05 6.2017... -
Page 4: Structure Of Serial Number
2. Structure of serial number Example: 116390001-WXXYYZZZZ W XX YY ZZZZ Serial number in current year KRONOTERM Year Calendar week (0001, 0002, 0003, etc.) 3. Components ID.: 17-16-24-3007-05 6.2017... - Page 5 ID.: 17-16-24-3007-05 6.2017...
- Page 6 TALLY WP2 LF-202S Number Name Ident For serial numbers: BOILER 200 L 2222000077136 AGREGATE COVER 2222000076047 COVER RIM 2222000076030 AIR CONNECTOR 2222000077303 SILVER FRONT 2222000081058 FLANGE COVER 2222000082086 COMPRESSOR 2222000034764 COMPRESSOR -alternative 2222000062620 117100228 from: DIFFUSER 2222000076078 FAN 220 2222000077327...
- Page 7 TALLY WP2 LF-302S Number Name Ident For serial numbers: BOILER 270 L 2222000077556 AGREGATE COVER 2222000076047 COVER RIM 2222000076030 AIR CONNECTOR 2222000077303 SILVER FRONT 2222000081058 FLANGE COVER 2222000082086 COMPRESSOR 2222000034764 COMPRESSOR -alternative 2222000062620 117100228 from: DIFFUSER 2222000076078 FAN 220 2222000077327 FAN HOLDER 2222000076924 EVAPORATOR...
-
Page 8: Cover Removal - Cover Of Electronic
4. Cover removal – cover of electronic To get acces to electronic components of the device it is necessary to remove the screws (Imbus 4) on the cover of the device. Lift the cover up and remove it (1). Push the front cover of the electronic up in the direction of the arrow (2) and pull it out towards you (3). -
Page 9: Electrical Wiring Diagram
5. Electrical wiring diagram Compressor - generator Relay panel Display Compressor capacitor Temperature probe NTC - evaporator Pressure switch Optitronic keyboard Temperature probe NTC - water Safety thermostat Connecting clips for regulating fan speed Electrical clip Connecting clip for the supply cable Standard supply cable with plug Connectors for the external signal Electric heater... - Page 10 Picture 1: El. Electrical wiring diagram WP2 LF-202S and WP2 LF-302S ID.: 17-16-24-3007-05 6.2017...
-
Page 11: Technical Data
6. Technical data Product: Device for heating DHW with guided air Model: WP2 LF-202S WP2 LF-302S Thermal power: 1850 (3350)* Electrical power: 440 (1940 )* Max. electrical power: 560 (65 ° C) (2060)* El. heater: 1500 Power supply: ~ 230 R134a (1,2 kg) –... - Page 12 Company headquarters and production Kronoterm d.o.o. Trnava 5e 3303 Gomilsko Tel.: (00386) 3 703 16 20 | Fax: (00386) 3 703 16 33 | Web-page: www.kronoterm.com E-mail: info@kronoterm.com | Customer support and service.: (00386) 3 703 16 26 | E-mail.:...
