- Page 1 INSTALLATION INSTALLATION INSTRUCTIONS Instalater ADAPT Heat pump System ADAPT...
- Page 2 Installation instructions ADAPT System KRONOTERM INSTRUCTION SYSTEM Document is a part of the KRONOTERM instruction system, which follows the project’s lifecycle from design phase to service support. Installation instructions are the basis for a professional approach to implementing the KRONOTERM heat pump system.
-
Page 3: Table Of Contents
Installation instructions ADAPT System T A B L E O F C O N T E N T IMPORTANT INFORMATION ......... 4 SYMBOLS ..................4 GENERAL WARNINGS ............4 SAFETY WARNINGS AND INSTRUCTIONS ....5 DISPOSING OF PACKAGING AND THE APPLI- ANCE ITSELF ................ -
Page 4: Important Information
Only Before beginning installation, read properly qualified individuals may install or these instructions thoroughly. maintain Kronoterm appliances. Read the Any processing or replacement of instructions thoroughly before installation, the appliance’s original integral parts as the instructions contain extensive will void the manufacturer’s warranty... -
Page 5: Safety Warnings And Instructions
Installation instructions ADAPT System 1.3. SAFETY WARNINGS AND ATTENTION INSTRUCTIONS Do not clean the appliance or interfere DANGER with it while it is in operation. Only a qualified electrician can Do not clean the appliance or interfere connect the appliance’s power cable with it while it is in operation. -
Page 6: Disposing Of Packaging And The Appliance Itself
Installation instructions ADAPT System 1.4. DISPOSING OF PACKAGING AND WARNING THE APPLIANCE ITSELF This appliance is not to be played with. Separate packaging according to its The appliance may only be used by material. people who have learned about its safe The appliance contains fluorinated greenhouse gas. -
Page 7: Transport And Storage
Installation instructions ADAPT System INSTALLATION NOTE Refer to these ADAPT heat pump installation instructions for information on location, clearance, and the appliance’s base. Ensure that the installation location is always accessible to hand-held transport equipment (e.g. hand trucks, dollies) for installation, maintenance, and servicing. -
Page 8: Installing The Appliance
Installation instructions ADAPT System 2.1. INSTALLING THE APPLIANCE 2.1.2. REMOVING THE TRANSPORT PROTECTION 2.1.1. REMOVING THE GUARDS AND SIDE TX30 PANELS Figure 5: Removing the transport screws Use a screwdriver (TX30) to remove the transport screws holding the heat pump onto the pallet Figure 3: Removing the side panels (Figure 5). -
Page 9: Attaching The Condensate Drain
Installation instructions ADAPT System 2.1.3. PLACEMENT ON THE BASE WARNING This appliance is very heavy. 4 people are needed to move it and lift it. Use the moving straps and other transport equipment to move the appliance. Figure 9: Straightening and affixing to the base 1. -
Page 10: Connecting The Pipe
Installation instructions ADAPT System 2.3. CONNECTING THE PIPE Under the evaporator pan there is the condensate drain and a heating cable. Connect the pipe to the appliance as shown in Figure 11 WARNING Clean the pipe thoroughly and remove any pollutants from it before attaching it to the appliance. -
Page 11: Turning On The Electricity
(2) and then lifting it (3). Table 1: Dimensions of the cables and fuses Heat pump Cable (mm²) FUSES ADAPT 0312 1F 3 x 2,5 1 x C20 ADAPT 0312 3F 5 x 2,5 3 x C10... - Page 12 Installation instructions ADAPT System 2.4.1.1. THREE-PHASE CONNECTION Fuse box 3N ~400 V/50 HZ Communication cable ATTENTION Cable gland Power cable The three-phase power supply must be connected in the right phase order. Wire the power cable (4) into the electrical box (1) (Figure 17) through the cable gland (3) (see Table 1).
-
Page 13: Placement Of Side Panels
Installation instructions ADAPT System PLACEMENT OF SIDE PANELS Fuse box Gland for the communication cable CLICK! Communication cable (see the specifications in the technical details) Terminals for the communication cable Grounding the communication cable shield CLICK! Thread the communication cable (3) (Figure 19) through the cable gland (2). -
Page 14: Maintenance
Installation instructions ADAPT System MAINTENANCE ATTENTION Order a service inspection from an authorized technician once per year. Use a soft rag and mild soap to clean the appliance. 17-19-45-6699-07... - Page 15 Installation instructions ADAPT System 17-19-45-6699-07...
- Page 16 KRONOTERM D.O.O. Trnava 5e, 3303 Gomilsko, SLO T +386 3 703 16 20 www.kronoterm.com info@kronoterm.com...
