ENGLISH
MultiPlus 230V
15kVA
Rev 00 - 03/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiPlus 12/3000/120-50 230V VE.Bus and is the answer not in the manual?

Questions and answers

Summary of Contents for Victron energy MultiPlus 12/3000/120-50 230V VE.Bus

  • Page 1 ENGLISH MultiPlus 230V 15kVA Rev 00 - 03/2024...
  • Page 2: Table Of Contents

    MultiPlus 230V Table of Contents 1. IMPORTANT SAFETY INSTRUCTIONS - Save these instructions! ............1 2. Description ..........................3 2.1. Boats, vehicles and other stand-alone applications ..............3 2.2. On-grid and off-grid systems combined with PV ................. 3 2.3. Battery charger ......................4 2.3.1.
  • Page 3 MultiPlus 230V 8.4. D: Three-phase connection diagram ..................31 8.5. E: Charge algorithm ....................... 32 8.6. F: Temperature compensation chart ..................33 8.7. G: Enclosure dimensions ....................34...
  • Page 4: Important Safety Instructions - Save These Instructions

    MultiPlus 230V 1. IMPORTANT SAFETY INSTRUCTIONS - Save these instructions! In general Please read the documentation supplied with this product first, so that you are familiar with the safety signs and directions before using the product. SAVE THESE INSTRUCTIONS — THIS MANUAL CONTAINS IMPORTANT SAFETY INSTRUCTIONS This product is designed and tested according to international standards.
  • Page 5 MultiPlus 230V Store the product in a dry environment; the storage temperature should range from -20°C to 60°C. Refer to the battery manufacturer's manual for information on transport, storage, charging, recharging, and disposal of the battery. Symbol on the enclosure Symbol description Caution, risk of electric shock...
  • Page 6: Description

    MultiPlus 230V 2. Description 2.1. Boats, vehicles and other stand-alone applications The basis of the MultiPlus is an extremely powerful sine inverter, battery charger and transfer switch in a compact casing. Important features: Automatic and uninterruptible switching In the event of a supply failure or when the generating set is switched off, the inverter/charger will switch over to inverter operation and take over the supply of the connected devices.
  • Page 7: Battery Charger

    MultiPlus 230V • start (with a preset delay) at a preset load level. • Stop at a preset battery voltage, or • stop (with a preset delay) after the bulk charge phase has been completed, and/or • stop (with a preset delay) at a preset load level. Autonomous operation when the grid fails Houses or buildings with solar panels or a combined micro-scale heating and power plant or other sustainable energy sources have a potential autonomous energy supply which can be used for powering essential equipment (central heating pumps,...
  • Page 8: More On Batteries And Battery Charging

    MultiPlus 230V 2.3.4. More on batteries and battery charging Our book "Energy Unlimited" offers further information on batteries and battery charging and is available free of charge on our website. It can be downloaded from: https://www.victronenergy.com/upload/documents/Book-Energy-Unlimited-EN.pdf, or a hard copy can be ordered from: https://www.victronenergy.com/orderbook For more information on adaptive charging, please refer to the technical paper: Adaptive charging, how it...
  • Page 9: Operation

    MultiPlus 230V 3. Operation 3.1. On/Off/Charger Only Switch When switched to ‘on’, the inverter/charger is fully functional. The inverter will come into operation, and the LED ‘inverter on’ will light up. An AC voltage connected to the ‘AC in’ terminal will be switched through to the ‘AC out’ terminal, if within specifications. The inverter will switch off, the ‘mains on’...
  • Page 10: Led Indications

    MultiPlus 230V To activate: Switch rapidly from ‘on’ to ‘charger only’ and leave the switch in this position for ½ to 2 seconds. Switch rapidly back from ‘charger only’ to ‘on’ and leave the switch in this position for ½ to 2 seconds. Switch once more rapidly from ‘on’...
  • Page 11 MultiPlus 230V Low battery pre-alarm The battery voltage is getting low. The battery is almost fully exhausted. The "low battery"LED is blinking. Low battery alarm The inverter has switched off due to low battery voltage. The "low battery" LED is blinking. Temperature pre-alarm The internal temperature is reaching a critical level.
  • Page 12 MultiPlus 230V Ripple alarm The inverter has switched off due to excess ripple voltage on the battery terminals. The "overload" and "low battery" LEDs are both Bulk charging The AC input voltage is switched through and the charger operates in bulk mode. The "bulk" LED is on. BatterySafe The mains voltage is switched through and the charger is on.
  • Page 13: Shut Down Procedure

    MultiPlus 230V PowerControl The AC input is switched through. The AC output current is equal to the preset maximum input current. The charge current is reduced to 0A. The "mains on" LED is blinking. PowerAssist The AC input is switched through, but the load requires more current than the preset maximum input current.
  • Page 14: Installation

    MultiPlus 230V 4. Installation This product may only be installed by a qualified electrical engineer. This product is not suitable for direct connection to a vehicle's electrical system. It should be connected to a dedicated DC system that includes a dedicated service or house battery, appropriate fusing, and the appropriate gauge of DC wiring.
  • Page 15 MultiPlus 230V WARNING – RISK OF EXPLOSIVE GASES) WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST IMPORTANCE THAT EACH TIME BEFORE SERVICING THE UNIT IN THE VICINITY OF THEBATTERY, YOU READ THIS MANUAL AND FOLLOW THE INSTRUCTIONS EXACTLY.
  • Page 16: Vibration Management

    MultiPlus 230V 4.2. Vibration management CAUTION When integrating inverter/chargers with generators in a single enclosure (hybrid generators), using shock mounts is mandatory. They mitigate damage risk to the inverter/charger by absorbing the generator's operational energy, thus extending component lifespan. Key criteria for selecting shock mounts include: •...
  • Page 17: Connection Of The Ac Cabling

    MultiPlus 230V 4.4. Connection of the AC cabling This is a safety class I product (supplied with a ground terminal for safety purposes). Its AC input and/or output terminals and/or grounding point on the outside of the product must be provided with an uninterruptible grounding point for safety purposes.
  • Page 18: Programmable Relay

    MultiPlus 230V See Appendix A for the location of the connector. 4.5.2. Programmable relay The product is equipped with a programmable relay. The relay can be programmed for all kinds of other applications however, for example as a starter relay for a generator. See Appendix A for the location of the connector.
  • Page 19 MultiPlus 230V The inverter/charger is unsuitable for a three-phase delta (Δ) configuration. Page 16 Installation...
  • Page 20: Configuration

    MultiPlus 230V 5. Configuration This section is intended mainly for stand-alone applications. Settings may only be changed by a qualified electrical engineer. Read the instructions thoroughly before implementing changes. During the configuration of the charger, the AC input must be removed. 5.1.
  • Page 21 MultiPlus 230V Input frequency range Input frequency range accepted by the MultiPlus. The MultiPlus synchronises within this range with the AC input frequency. The output frequency is then equal to the input frequency. Adjustability: 50, 60 or 45 – 65 Hz. Input voltage range Voltage range accepted by the MultiPlus.
  • Page 22 When WeakAC is on, the maximum charge current is reduced by approximately 20%. BoostFactor Change this setting only after consulting with Victron Energy or with an engineer trained by Victron Energy! Page 19 Configuration...
  • Page 23: Configuring

    MultiPlus 230V Programmable relay The relay can be programmed for all kinds of other applications, for example as a starter relay for a generator. Auxiliary AC output (AC-out-2) Intended for non-critical loads and directly connected to the AC input. With current measurement circuit to enable PowerAssist. 5.3.
  • Page 24: Error Indications

    MultiPlus 230V 6. Error Indications With the procedures below, most errors can be quickly identified. If an error cannot be resolved, please refer to your Victron Energy supplier. Our recommendation is to use the Victron Toolkit app to find the description of all possible LED alarm codes. See here for download information: https://www.victronenergy.com/support-and-downloads/software#victron-toolkit-app.
  • Page 25: Special Led Indications

    MultiPlus 230V Problem Cause Solution Check your batteries. Charger is in ‘Bulk protection’ mode You can reset the error mode by The charger does not thus, the maximum bulk charging switching the unit off and back operate. time of 10 hours is exceeded. on again.
  • Page 26: Ve.bus Led Indications

    MultiPlus 230V If the "inverter on" LED flashes in phase opposition, this is a VE.Bus error code (see next chapters). 6.3. VE.Bus LED indications Equipment included in a VE.Bus system (a parallel or 3-phase arrangement) can provide so-called VE.Bus LED indications. These LED indications can be subdivided into two groups: OK codes and error codes.
  • Page 27 MultiPlus 230V flashing Bulk LED on Absorption LED flashing Float LED flashing Bulk, Absorption Description Cause/solution , Float LEDs Device is switched off because one of the other phases in the Check the failing phase. system has switched off. The system is not properly configured. Reconfigure the system.
  • Page 28 Update the firmware in the last device that was switched on. Should not occur. Switch all equipment off, and then on Internal error. again. Contact Victron Energy if the problem persists. Page 25 Error Indications...
  • Page 29: Technical Specifications

    MultiPlus 230V 7. Technical specifications MultiPlus 230V 48/15000/200-100 PowerControl / PowerAssist Input voltage range: 187 - 270 VAC, AC input Input frequency: 50 - 60Hz Cos φ >0.8 Maximum feed through current 100A INVERTER Input voltage range 38 – 66V Output voltage: 230 VAC ±...
  • Page 30 MultiPlus 230V MultiPlus 230V 48/15000/200-100 Maximum altitude 2000m ENCLOSURE Material & Colour Alluminium, blue RAL 5012 Protection category IP 20 Battery-connection Four M8 bolts (2 positive and 2 negative connections) 230VAC connections Bolts M6 Weight 70 kg Dimensions h x w x d 571 x 423 x 334 mm STANDARDS EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC...
  • Page 31: Appendix

    MultiPlus 230V 8. Appendix 8.1. A: Connection overview Load connection. AC out 1. Left to right: N (neutral) and L (phase). Load connection. AC out 2. Left to right: N (neutral) and L (phase). AC input: Left to right: N (neutral) and L (phase). External current sensor.
  • Page 32 MultiPlus 230V Terminal for: top to bottom: 12V 100mA Programmable contact K1 open collector 70V 100mA External ground relay + External ground relay – Aux input 1 + Aux input 1 – Aux input 2 + Aux input 2 – Temperature sense + 10.
  • Page 33: B: Block Diagram

    MultiPlus 230V 8.2. B: Block diagram * See table in Chapter 4.2 ‘Recommended DC fuse’ 8.3. C: Parallel connection diagram Page 30 Appendix...
  • Page 34: D: Three-Phase Connection Diagram

    MultiPlus 230V 8.4. D: Three-phase connection diagram Page 31 Appendix...
  • Page 35: E: Charge Algorithm

    MultiPlus 230V 8.5. E: Charge algorithm 4-stage charging: Bulk Entered when charger is started. Constant current is applied until nominal battery voltage is reached, depending on temperature and input voltage, after which constant power is applied up to the point where excessive gassing starts (resp 14.4V, 28.8V or 57.6 temperature compensated).
  • Page 36: F: Temperature Compensation Chart

    MultiPlus 230V 8.6. F: Temperature compensation chart The above chart displays the default output voltages for Float and Absorption at 25 °C for 12 and 24V battery banks. For a 48V battery bank, multiply the 24V voltages by 2. Reduced Float voltage follows the Float voltage, and Raised Absorption voltage follows the Absorption voltage. Temperature compensation does not apply in adjust mode.
  • Page 37: G: Enclosure Dimensions

    MultiPlus 230V 8.7. G: Enclosure dimensions Page 34 Appendix...
