LOUIE
DESIGNED BY TOM FEREDAY
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Louie and is the answer not in the manual?

Questions and answers

Related Manuals for SP01 Louie

Summary of Contents for SP01 Louie

  • Page 1 LOUIE DESIGNED BY TOM FEREDAY ASSEMBLY INSTRUCTIONS...
  • Page 2 DISCLAIMER THE ASSEMBLY INSTRUCTIONS ARE TO BE USED AS A GUIDE SHOWING THE CONCEPT OF THE TABLE. IT WILL NOT BE NECESSARILY IDENTICAL TO THE TABLE YOU HAVE PURCHASED. ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT.
  • Page 3 BOX WITH TERRACOTTA BASE METAL STRUCTURE (TUBE, TOP, BASE PLATE), TERRACOTTA BASE ADHESIVE PADS SUITABLE FOR OUTDOOR, 2 SCREWS, 1 PLASTIC SLEEVE, 1 METAL PIN + 1 SPARE METAL PIN p. 3 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 4 S P Ø 1 D E S I G N . C O M LOUIE TABLE STRUCTURE ASSEMBLY REMOVE ALL PARTS FROM THE PACKAGING, PLACING THEM ONTO A SOFT AND CLEAN SURFACE SUCH AS A BLANKET IN ORDER TO PROTECT THE LACQUER SURFACE. p. 4 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 5 PLACE THE METAL BASE PLATE UPSIDE DOWN, MAKING SURE THAT THE CORRECT SIDE IS FACING UP. STICK THE 6 PROVIDED SELF-ADHESIVE RUBBER PADS ONTO THE BOTTOM SIDE OF THE METAL BASE PLATE, TAKING CARE TO NOT COVER ANY SCREW HOLE. p. 5 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 6: Top View

    LOUIE TABLE STRUCTURE ASSEMBLY TOP VIEW BOTTOM VIEW FIX THE METAL STEM ONTO THE BASE PLATE USING THE PROVIDED HARDWARE. MAKE SURE THAT THE TWO PARTS ARE FITTED TOGETHER WELL. p. 6 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 7 S P Ø 1 D E S I G N . C O M LOUIE TABLE TERRACOTTA ASSEMBLY PUT THE PLASTIC SLEEVE OVER THE TERRACOTTA BASE. p. 7 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 8 POSITION THE TERRACOTTA PIECE ONTO THE METAL BASE PLATE. MAKE SURE THAT THE TERRACOTTA IS SITTING FLAT AND CENTRED ON THE BASE PLATE. PLACE THE RUBBER PADS ONTO THE METAL PLATE MAKING SURE THAT THEY SIT DIRECTLY UNDER THE TERRACOTTA PIECE. p. 8 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 9: Top Assembly

    S P Ø 1 D E S I G N . C O M LOUIE TABLE TOP ASSEMBLY FIX THE TOP ONTO THE METAL STEM USING THE PROVIDED METAL PIN. MAKE SURE THAT THE TABLE TOP SITS FIRMLY ON THE STRUCTURE. p. 9 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 10 S P Ø 1 D E S I G N . C O M LOUIE TABLE p. 10 © Copyright 2019 SP01 Design. All rights reserved.
