HOLLAND BENCH
DESIGNED BY METRICA
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the METRICA HOLLAND BENCH and is the answer not in the manual?

Questions and answers

Related Manuals for SP01 METRICA HOLLAND BENCH

Summary of Contents for SP01 METRICA HOLLAND BENCH

  • Page 1 HOLLAND BENCH DESIGNED BY METRICA ASSEMBLY INSTRUCTIONS...
  • Page 2 DISCLAIMER ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT. A MINIMUM OF TWO PEOPLE ARE REQUIRED FOR ASSEMBLY. TO PREVENT ANY DAMAGE OF THE PRODUCT, DO NOT USE A BOX CUTTER, KNIFE OR SHARP OBJECT TO OPEN THE BOXES.
  • Page 3 ASSEMBLY INSTRUCTIONS HOLLAND BENCH WITH BACKREST S P Ø 1 D E S I G N . C O M...
  • Page 4 BOX WITH WOODEN TOP BOX WITH METAL BACKREST AND HARDWARE AND HARDWARE 8 FELT PADS, WOODEN TOP WITH CUT-OUTS FOR 2 METAL PLATES, 6 SCREWS BACKREST TUBE 2 LONG SCREWS, 12 SHORT SCREWS p. 4 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 5: Bench Assembly

    KEEP THE SCREWS IN A SECURE PLACE, YOU WILL NEED THEM FOR THE FINAL ASSEMBLY STEP. IN THE MIDDLE OF ONE OF THE LONG RAILS YOU FIND THE SP01 LOGO. THIS WILL BE YOUR BACK SIDE OF THE BENCH LATER.
  • Page 6 REMOVE THE WOODEN TOP FROM ITS PACKAGING AND PLACE IT UPSIDE DOWN ONTO A SOFT AND CLEAN SURFACE SUCH AS A BLANKET. THE SCREW HOLES SHOULD BE FACING UP. THEN REMOVE THE BACKREST TUBE WITH HARDWARE FROM ITS PACKAGING. p. 6 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 7 BENCH ASSEMBLY POSITION THE METAL PLATE INTO THE CUT-OUTS OF THE WOODEN TOP ENSURING THAT ALL HOLES MATCH. FIX THE METAL PLATE USING THE SHORT SCREWS PROVIDED WITHOUT TIGHTENING TOO MUCH. p. 7 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 8 ENSURING THAT THE ANGLE OF THE BACKREST TUBE FACES THE BACK OF THE BENCH. FROM BELOW, INSERT THE LONG CENTRAL SCREW WHICH FIXES THE BACKREST TUBE ONTO THE WOODEN SEAT. ONCE ALL SCREWS ARE INSERTED, GRADUALLY TIGHTEN ALL SCREWS. p. 8 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 9 MAKE SURE THAT THE BACKREST TUBE IS ALIGNED WITH THE BASE FRAME. NOW INSERT THE HARDWARE PROVIDED AND FIX THE TOP ONTO THE METAL STRUCTURE. GRADUALLY TIGHTEN ALL THE SCREWS. p. 9 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 10 S P Ø 1 D E S I G N . C O M HOLLAND BENCH WITH BACKREST p. 10 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 11 ASSEMBLY INSTRUCTIONS HOLLAND BENCH WITHOUT BACKREST S P Ø 1 D E S I G N . C O M...
  • Page 12 S P Ø 1 D E S I G N . C O M HOLLAND BENCH WITHOUT BACKREST PACKAGING BOX WITH METAL STRUCTURE BOX WITH WOODEN TOP AND HARDWARE 8 FELT PADS, 6 SCREWS p. 12 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 13 KEEP THE SCREWS IN A SECURE PLACE, YOU WILL NEED THEM FOR THE FINAL ASSEMBLY STEP. IN THE MIDDLE OF ONE OF THE LONG RAILS YOU FIND THE SP01 LOGO. THIS WILL BE YOUR BACK SIDE OF THE BENCH LATER.
  • Page 14 BENCH ASSEMBLY REMOVE THE WOODEN TOP FROM ITS PACKAGING AND PLACE IT UPSIDE DOWN ONTO A SOFT AND CLEAN SURFACE SUCH AS A BLANKET. THE SCREW HOLES SHOULD BE FACING UP. p. 14 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 15 NOW PLACE THE METAL BASE UPSIDE DOWN ONTO THE WOODEN TOP AND FIX IT USING THE HARDWARE PROVIDED. GRADUALLY TIGHTEN ALL SCREWS. FINALLY TURN THE BENCH AROUND PLACING IT ONTO ITS LEGS. p. 15 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 16 S P Ø 1 D E S I G N . C O M HOLLAND BENCH WITH BACKREST p. 16 © Copyright 2019 SP01 Design. All rights reserved.
