LING
DESIGNED BY METRICA
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the LING and is the answer not in the manual?

Questions and answers

Related Manuals for SP01 LING

Summary of Contents for SP01 LING

  • Page 1 LING DESIGNED BY METRICA ASSEMBLY INSTRUCTIONS...
  • Page 2 DISCLAIMER THE ASSEMBLY INSTRUCTIONS ARE TO BE USED AS A GUIDE SHOWING THE GENERAL ASSEMBLY OF THE PRODUCT. IT WILL NOT BE IDENTICAL TO THE PRODUCT YOU HAVE PURCHASED. ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT.
  • Page 3 S P Ø 1 D E S I G N . C O M LING PACKAGING PARTS BOX WITH WOOD STRUCTURE BOX WITH UPHOLSTERY WOODEN STRUCTURE SEAT AND BACKREST CUSHION, UPHOLSTERED BACK PANEL, HARDWARE p. 3 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 4 S P Ø 1 D E S I G N . C O M LING ASSEMBLY REMOVE THE WOODEN STRUCTURE FROM THE PACKAGING AND PLACE IT WITH ITS LEGS ONTO THE FLOOR. p. 4 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 5 REMOVE THE UPHOLSTERY AND THE HARDWARE FROM ITS PACKAGING AND PLACE IT ON A CLEAN SURFACE. TAKE THE UPHOLSTERED BACKREST PANEL AND DETACH THE HARDWARE BAG; THE SCREW USED TO FIX THE HARDWARE BAG TO THE PANEL IS NOT REQUIRED FOR ASSEMBLY. p. 5 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 6 SCREW THE PIN ONTO THE PANEL ENLARGING THE FABRIC HOLES; THE HOLE IN THE PIN MUST BE POSITIONED VERTICALLY, OTHERWISE YOU WON`T BE ABLE TO INSERT THE SECURITY PIN AFTERWARDS. p. 6 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 7 S P Ø 1 D E S I G N . C O M LING ASSEMBLY PLACE THE PANEL ON THE BACK INSERTING THE PINS INTO THE WOODEN STRUCTURE (1). MOUNT THE SECURITY PIN WITHOUT TIGHTENING (2). p. 7 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 8 S P Ø 1 D E S I G N . C O M LING ASSEMBLY MOUNT THE LOWER PART OF THE PANEL TO THE UNDERSIDE OF THE WOODEN FRAME USING THE HARDWARE PROVIDED. FINALLY, GRADUALLY TIGHTEN ALL THE SCREWS WITHOUT USING FORCE. p. 8 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 9 PLACE THE SEAT CUSHION WITH THE ZIPPER FACING THE BACKPANEL ONTO THE FRAME, THE HIGHER CUSHION EDGE IS ON THE FRONT. FINALLY PLACE THE BACKREST CUSHION WITH THE ZIPPER FACING DOWN. p. 9 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 10 S P Ø 1 D E S I G N . C O M LING p. 10 © Copyright 2019 SP01 Design. All rights reserved.
