  • Page 1 SMITH DESIGNED BY METRICA ASSEMBLY INSTRUCTIONS...
  • Page 2 DISCLAIMER ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT. A MINIMUM OF TWO PEOPLE ARE REQUIRED FOR ASSEMBLY. TO PREVENT ANY DAMAGE OF THE PRODUCT, DO NOT USE A BOX CUTTER, KNIFE OR SHARP OBJECT TO OPEN THE BOXES.
  • Page 3 ASSEMBLY INSTRUCTIONS SMITH TABLE WITH WOOD TOP S P Ø 1 D E S I G N . C O M...
  • Page 4 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP PACKAGING PARTS BOX WITH FRAME BOX WITH LEGS AND TOP WOODEN TOP WITH LEG WITH METAL L, METAL FRAME WITH SCREWS FOR ASSEMBLY WOODEN SIDES p.
  • Page 5 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP TOP DISASSEMBLY PLACE THE FRAME WITH THE ALREADY ASSEMBLED TOP UPSIDE DOWN ONTO A SOFT AND CLEAN SURFACE SUCH AS A BLANKET.
  • Page 6 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP TOP DISASSEMBLY UNSCREW THE TOP COMPLETELY AND SET ASIDE. THE TOP WILL BE REASSEMBLED AT THE END. p. 6 © Copyright 2019 SP01 Design.
  • Page 7 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP STRUCTURE ASSEMBLY LOOSEN GENTLY ALL THE SCREWS WHICH FIX THE WOODEN SIDES ONTO THE METAL FRAME. DO NOT UNSCREW THE WOODEN SIDES.
  • Page 8 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP STRUCTURE ASSEMBLY ON A BLANKET, TILT THE METAL FRAME ONTO THE SIDE AND PLACE ONE SET OF THE LEGS INTO POSITION. ENSURE THAT THE METAL L SITS CORRECTLY IN ITS POSITION.
  • Page 9 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP STRUCTURE ASSEMBLY NOW INSERT THE SCREWS FIXING THE METAL L ONTO THE WOODEN SIDES AND TIGHTEN. REPEAT THE STEP ON THE OTHER SIDE.
  • Page 10 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH WOOD TOP STRUCTURE ASSEMBLY TIGHTEN ALL THE SCREWS WHICH FIX THE WOODEN SIDES ONTO THE METAL FRAME. MAKE SURE THAT ALL SCREWS ARE TIGHTENED.
  • Page 11 PLACE THE TABLE TOP ON A BLANKET WITH THE UNDERSIDE FACING UP. PLACE THE ASSEMBLED TABLE STRUCTURE ONTO THE WOODEN TOP AND GENTLY REASSEMBLE THE TOP WITH ALL SCREWS. DO NOT OVER-TIGHTEN THE SCREWS. p. 11 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 12 S P Ø 1 D E S I G N . C O M SMITH TABLE PLACE THE TABLE ON ITS LEGS, MAKING SURE THAT IT IS STABLE. IF THE TABLE STRUCTURE IS MOVING TOO MUCH, RE-CHECK THAT ALL SCREWS ARE TIGHTENED CORRECTLY. p. 12 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 13 ASSEMBLY INSTRUCTIONS SMITH TABLE WITH GLASS TOP S P Ø 1 D E S I G N . C O M...
  • Page 14 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP PACKAGING PARTS BOX WITH FRAME WOODEN CRATE WITH GLAS TOP BOX WITH LEGS METAL FRAME WITH SELF-ADHESIVE RUBBERS LEG WITH METAL L,...
  • Page 15 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP STRUCTURE ASSEMBLY PLACE THE FRAME UPSIDE DOWN ONTO A SOFT AND CLEAN SURFACE SUCH AS A BLANKET ON THE FLOOR. GENTLY LOOSEN THE SCREWS WHICH FIX THE WOODEN SIDES ONTO THE METAL FRAME.
  • Page 16 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP STRUCTURE ASSEMBLY ON A BLANKET, TILT THE METAL FRAME ONTO THE SIDE AND PLACE ONE SET OF THE LEGS INTO POSITION. ENSURE THAT THE METAL L SITS CORRECTLY IN ITS POSITION.
  • Page 17 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP STRUCTURE ASSEMBLY NOW INSERT THE SCREWS FIXING THE METAL L ONTO THE WOODEN SIDES AND TIGHTEN. REPEAT THE STEP ON THE OTHER SIDE.
  • Page 18 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP STRUCTURE ASSEMBLY TIGHTEN ALL THE SCREWS WHICH FIX THE WOODEN SIDES ONTO THE METAL FRAME. MAKE SURE THAT ALL SCREWS ARE TIGHTENED.
  • Page 19 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP STRUCTURE ASSEMBLY IF THE TABLE STRUCTURE IS MOVING TOO MUCH, RE-CHECK THAT ALL SCREWS ARE TIGHTENED CORRECTLY. p. 19 © Copyright 2019 SP01 Design.
  • Page 20 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP GLAS TOP ASSEMBLY INSIDE THE PACKAGING/ATTACHED TO THE GLASS TOP ARE SELF-ADHESIVE RUBBER PADS. GLUE THE RUBBER PADS ONTO THE WOODEN STRUCTURE AS SHOWN ABOVE.
  • Page 21 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP GLAS TOP ASSEMBLY PLACE THE GLASS TOP ONTO THE STRUCTURE. THE TOP SHOULD HAVE A CONSISTENT 2MM SHADOW LINE ON ALL SIDES.
  • Page 22 S P Ø 1 D E S I G N . C O M SMITH TABLE WITH GLASS TOP p. 22 © Copyright 2019 SP01 Design. All rights reserved.
