HOLLAND DESK
DESIGNED BY METRICA
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOLLAND DESK and is the answer not in the manual?

Questions and answers

Related Manuals for SP01 HOLLAND DESK

Summary of Contents for SP01 HOLLAND DESK

  • Page 1 HOLLAND DESK DESIGNED BY METRICA ASSEMBLY INSTRUCTIONS...
  • Page 2 DISCLAIMER ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT. A MINIMUM OF TWO PEOPLE ARE REQUIRED FOR ASSEMBLY. TO PREVENT ANY DAMAGE OF THE PRODUCT, DO NOT USE A BOX CUTTER, KNIFE OR SHARP OBJECT TO OPEN THE BOXES.
  • Page 3 ASSEMBLY INSTRUCTIONS HOLLAND DESK S P Ø 1 D E S I G N . C O M...
  • Page 4 PARTS BOX WITH METAL BASE BOX WITH TOP METAL BASE WITH ALREADY WOODEN TOP WITH CABLE ASSEMLBED FEET, 6 SCREWS AND MANAGEMENT HOLE AND WASHERS AND 8 FELT PADS COVER p. 4 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 5: Top Assembly

    ENSURE THAT THE ADJUSTABLE FEET ARE NOT TOO TIGHT, IN CASE LOOSEN THEM A LITTLE BIT. IF YOU WISH TO HAVE CONTRASTING FEET, ENSURE TO CHANGE THE FEET. POSITION THE FELT PADS AS SHOWN ABOVE MAKING SURE THAT THE PADS DO NOT COVER ANY HOLE. p. 5 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 6 HOLLAND DESK TOP ASSEMBLY REMOVE THE WOODEN TOP FROM ITS PACAKGING AND PLACE IT UPSIDE DOWN ON A BLANKET/ SOFT AND CLEAN SURFACE WHICH WILL NOT SCRATCH OR DAMAGE THE TOP. p. 6 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 7 TOWARDS THE CABLE MANAGEMENT HOLE. NOW INSERT THE SCREWS AND WASHERS FIXING THE STRUCTURE ONTO THE TOP USING THE PROVIDED ALLEN KEY. TIGHTEN ALL THE SCREWS AND PLACE THE DESK ON ITS LEGS. p. 7 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 8 S P Ø 1 D E S I G N . C O M HOLLAND DESK TOP ASSEMBLY INSERT THE CABLE MANAGEMENT COVER INTO THE HOLE IN THE WOODEN TOP. p. 8 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 9 S P Ø 1 D E S I G N . C O M HOLLAND DESK p. 9 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 10 ASSEMBLY INSTRUCTIONS HOLLAND DRAWER WE RECOMMEND TO MOUNT THE DRAWER BEFORE MOUNTING THE FRAME TO THE DESK TOP. S P Ø 1 D E S I G N . C O M...
  • Page 11 PLASTIC BUMPERS METAL DRAWER WITH METAL PIN AND PLATE WOODEN TOP WITH CABLE PLUS SCREW, 4 SCREWS, PLASTIC TUBE AND MANAGEMENT HOLE AND PLATES, ROUND AND SQUARE PLASTIC BUMPERS COVER p. 11 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 12: Drawer Assembly

    HOLLAND DESK DRAWER DRAWER ASSEMBLY REMOVE THE WOODEN TOP FROM ITS PACAKGING AND PLACE IT UPSIDE DOWN ON A BLANKET/ SOFT AND CLEAN SURFACE WHICH WILL NOT SCRATCH OR DAMAGE THE TOP. p. 12 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 13 DRAWER ASSEMBLY TAKE THE DRAWER AND ITS HARDWARE OUT OF THE BOX. ENSURE TO CHOOSE THE CORRECT SIDE FOR ASSEMBLY OF YOUR LEFT OR RIGHT DARWER AS THEY ARE NOT INTERCHANGEABLE. p. 13 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 14 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER DRAWER ASSEMBLY METAL PIN FIX THE METAL PIN WITH THE FOUR SHORT SCREWS PROVIDED ONTO THE TOP. p. 14 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 15 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER DRAWER ASSEMBLY PLASTIC TUBE PLASTIC DISK METAL PIN PLACE THE PLASTIC DISK AND TUBE ONTO THE ASSEMBLED METAL PIN COVERING THE METAL PARTS. p. 15 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 16 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER DRAWER ASSEMBLY PLACE THE DRAWER UPSIDE DOWN ONTO THE PIN. p. 16 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 17 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER DRAWER ASSEMBLY METAL DISK PLASTIC DISK FIRST PLACE THE PLATIC PLATE AND THEN THE METAL PLATE AND FIX EVERYTHING WITH THE SCREW PROVIDED. p. 17 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 18 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER DRAWER ASSEMBLY MAKE SURE THAT THE DRAWER IS SITTING PARALLEL ON THE TOP. p. 18 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 19 PLACE THE SELF ADHESIVE ROUND OR SQUARE RUBBER STOPPER ONTO THE CLEAN WOODEN SURFACE. IT SHOULD E POSITIONED ON THE BACK AND KEEP THE DRAWER IN POSITION. NOW PROCEED WITH THE GENERAL DESK ASSEMBLY. p. 19 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 20 S P Ø 1 D E S I G N . C O M HOLLAND DESK DRAWER p. 20 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 21 ASSEMBLY INSTRUCTIONS HOLLAND SCREEN S P Ø 1 D E S I G N . C O M...
  • Page 22 S P Ø 1 D E S I G N . C O M HOLLAND DESK SCREEN PACKAGING PARTS BOX WITH SCREEN BOX WITH METAL BRACKETS SOUND ABSORBING SCREEN CLOSED WASHER, WASHER, METAL L, SCREW p. 22 © Copyright 2019 SP01 Design. All rights reserved.

  • Page 23: Screen Assembly

    PLACE THE CLOSED WAHSER INTO THE REBATE ON ONE SIDE OF THE SCREEN. FROM THE OTHER SIDE, PLACE THE WASHER WITH HOLE INTO THE REBATE AND PLACE THE METAL L ON TOP. FIX EVERYTHING WITH THE PROVIDED SCREW AND ALLEN KEY. p. 23 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 24 PLACE ONE RUBBER POINT ONTO THE LONG SIDE OF EACH METAL BRACKET AND PLACE THE SCREEN ONTO THE WOODEN TOP KEEPING THE LONG SIDE OF THE BRACKET UNDER THE TOP. p. 24 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 25 S P Ø 1 D E S I G N . C O M HOLLAND DESK SCREEN SCREEN ASSEMBLY IF YOU WISH TO FIX THE SCREEN PERMANENTLY ONTO THE TABLE TOP, PLEASE USE THE SMALL SCREW PROVIDED. p. 25 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 26 S P Ø 1 D E S I G N . C O M HOLLAND DESK SCREEN SCREEN ASSEMBLY BY ROTATING THE METAL L YOU CAN USE THE SCREEN EITHER AS PRIVACY SCREEN OR AS MODESTY PANEL. p. 26 © Copyright 2019 SP01 Design. All rights reserved.
  • Page 27 S P Ø 1 D E S I G N . C O M HOLLAND DESK SCREEN p. 27 © Copyright 2019 SP01 Design. All rights reserved.
