IN HOUSE ASSEMBLY TEMPLATE
MOBILE STORAGE CABINET W/ PEGBOARD
NOTE:
1.
MODEL VIEWS MAY NOT REPRESENT EXACT MODEL PURCHASED
WMSC-3135, WMSC-3735, & WMSC-3735BL SERIES
ASSEMBLY INSTRUCTIONS
B
UPDATED CASTER STEP
3/7/2024
RJM
A
CREATED ASSEMBLY INSTRUCTIONS
11/7/14
EMR
REV.
DESCRIPTION
DATE
NAME
REVISION LEVEL
DATE
ALL DIMENSIONS ARE IN INCHES UNLESS
DWN
11/7/14
EMR
NOTED OTHERWISE
BY:
DWN:
DECIMALS: .X = ± .030
APR
DATE
.XX = ± .020
BY:
APR:
.XXX = ± .010
ANGLES: = ± 1°0'
APR
DATE
CABINET SQUARENESS = ± .0625
BY:
APR:
CONFIDENTIAL:
ALL DESIGN RIGHTS RESERVED
THE INFORMATION, DATA, DESIGN, AND DRAWINGS EMBODIED
IN THIS DOCUMENT AND ALL REPRODUCTIONS THEREOF ARE
THE EXCLUSIVE PROPERTY OF DIVERSIFIED WOODCRAFTS, INC.
THESE DOCUMENTS ARE SUPPLIED WITH THE UNDERSTANDING
1447
THAT THEY WILL NOT BE DISCLOSED TO THIRD PARTIES WITHOUT
WRITTEN CONSENT OF DIVERSIFIED WOODCRAFTS, INC. ANY
N/A
REPRODUCTION IN PART OR WHOLE WITHOUT WRITTEN
ECN No.
CONSENT IS SUBJECT TO LEGAL ACTION.
300 South Krueger Street
Suring, WI 54174
diversifiedwoodcrafts.com
TITLE:
MOBILE STORAGE CABINET W/ PEGBOARD
ASSEMBLY INSTRUCTIONS
SCALE:
DRAWING NUMBER:
WMSC SERIES
NTS
SHEET:
REVISION:
REV B
1 OF 6
Advertisement
Table of Contents
Related Manuals for DIVERSIFIED SPACES WMSC-3135 Series
Summary of Contents for DIVERSIFIED SPACES WMSC-3135 Series
- Page 1 IN HOUSE ASSEMBLY TEMPLATE MOBILE STORAGE CABINET W/ PEGBOARD WMSC-3135, WMSC-3735, & WMSC-3735BL SERIES ASSEMBLY INSTRUCTIONS DATE ALL DIMENSIONS ARE IN INCHES UNLESS 11/7/14 NOTED OTHERWISE DWN: 300 South Krueger Street DECIMALS: .X = ± .030 NOTE: DATE .XX = ± .020 APR: Suring, WI 54174 .XXX = ±...
-
Page 2: Tools Required
IN HOUSE ASSEMBLY TEMPLATE ASSEMBLY COMPONENTS TOOLS REQUIRED ITEMS INCLUDED PART # PART DESCRIPTION " WRENCH CASTERS 100081 CASTER,4IN SWIVEL TOP PLATE, W/BRAKE ADJUSTABLE PLIERS CASTER HARDWARE KIT 206509 CASTER,ASSY,HDWRE,16-SCREW,16-NUTS HOOK KIT 229752 HOOK KIT FOR WMSC-3735 QTY: 15 DATE ALL DIMENSIONS ARE IN INCHES UNLESS 11/7/14 NOTED OTHERWISE... - Page 3 IN HOUSE ASSEMBLY TEMPLATE HARDWARE REQUIRED FOR STEP DESCRIPTION PART NUMBER CASTERS 100081 CASTER HARDWARE KIT 206509 STEP 1: LAY CABINET ON ITS BACK. ATTACH CASTERS FROM INSIDE THE CABINET USING PROVIDED HARDWARE LISTED ABOVE. **SEE NOTE** **NOTE** BE SURE CABINET IS ON A CLEAN SURFACE TO PREVENT DAMAGE DOOR, BOTTOM DRAWER, AND HARDWARE...
- Page 4 IN HOUSE ASSEMBLY TEMPLATE HARDWARE REQUIRED FOR STEP DESCRIPTION PART NUMBER SHELF CLIPS 100027 STEP 2: TIP CABINET UP. INSERT SHELF CLIPS IN DESIRED LOCATION. PLACE SHELF ON CLIPS, MAKING SURE IT IS LEVEL. ADJUSTABLE SHELF DATE ALL DIMENSIONS ARE IN INCHES UNLESS 11/7/14 NOTED OTHERWISE DWN:...
- Page 5 IN HOUSE ASSEMBLY TEMPLATE STEP 3: SET CABINET IN DESIRED LOCATION. PLACE HOOKS ON PEGBOARD (NOT SHOWN). DATE ALL DIMENSIONS ARE IN INCHES UNLESS 11/7/14 NOTED OTHERWISE DWN: 300 South Krueger Street DECIMALS: .X = ± .030 NOTE: DATE .XX = ± .020 APR: Suring, WI 54174 .XXX = ±...
-
Page 6: Maintenance And Repair
Butcher Block (Varnished Tops) Maintenance & Repair PRODUCT SPILLS • Be sure any spills are cleaned up immediately. Excessive moisture and certain chemicals allowed to stand on a finished surface can cause damage. •. Clean spills or soiled areas with a damp cloth and dry thoroughly. • Periodically, apply a coat of spray wax, paste wax, or lemon oil to finished surface. This will enhance and protect the finish and insure a moisture barrier is intact in the event the finish becomes scratched or worn. SCRATCHES & DENTS • Minor scratches and dents can be easily repaired by rubbing the affected area with steel wool or fine grit (#220) sandpaper. Remember, when rubbing or sanding always sand with the grain of the wood. Feather edges of repair in to the surrounding area. Remove all dust and residue and apply a coat of clear lacquer type finish or paint. Clear lacquer type finish can be purchased at most paint or hardware stores. Small cans of touch-up paint are available form your dealer or representative. Paint colors can easily be matched at most paint stores. Confine touch-up only to the area that was sanded. Remember, follow manufacturing directions on product label when refinishing. • Major scratches and gouges where large portions of wood have been removed or damaged should be handled by a professional experienced in furniture repair with the proper tools and equipment. MINERAL STREAKS • Mineral Streaks – Natural Coloring of wood due to mineral deposits in the tree. Repair is not required and will add to the individuality of your table. Sizes can range up to a 1/4" wide and up to 3" in length.
