PART IDENTIFICATION CHART
Use the drawings below to identify the small parts used for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number after the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether it
has been preassembled. Extra parts may be included.
M6 x 16mm
M8 Locknut
M8 x 20mm
Screw (63)–4
(17)–2
Screw (29)–4
M8 x 70mm Screw
M8 x 58mm Bolt
(46)–4
(24)–2
5
