iFIT NordicTrack G LE User Manual
iFIT NordicTrack G LE User Manual

iFIT NordicTrack G LE User Manual

Recumbent bike

Advertisement

Quick Links

nordictrack.com
Model No. NTEX99025.0
Serial No.
Write the serial number in the space
above for reference.
For service at any time, go to
my.iFIT.com or scan the QR code
below. DO NOT CONTACT THE
STORE.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Serial
Number
Decal
USER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the NordicTrack G LE and is the answer not in the manual?

Questions and answers

Summary of Contents for iFIT NordicTrack G LE

  • Page 1 Write the serial number in the space above for reference. Serial Number Decal For service at any time, go to my.iFIT.com or scan the QR code below. DO NOT CONTACT THE STORE. CAUTION Read all precautions and instructions in this manual before using this equipment.
  • Page 2 Note: The decal(s) may not be shown at actual size. NORDICTRACK and IFIT are registered trademarks of iFIT Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC. The Bluetooth word ®...
  • Page 3 To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. iFIT assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK G LE RECUMBENT BIKE. Cycling manual. To help us assist you, note the product model ® is an effective exercise for increasing cardiovascular number and serial number before contacting us (see fitness, building endurance, and toning the body.
  • Page 5 PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number after the key number is the quantity needed for assembly.
  • Page 6 ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 5. • Place all parts in a cleared area and remove the • Assembly can be completed using the included packing materials. Do not dispose of the packing tools.
  • Page 7 3. Set a sturdy piece of packing material under the front of the Frame (1). Orient the Front Stabilizer (15) as shown. Attach the Front Stabilizer to the Frame (1) with two M10 x 122mm Screws (65). Then, remove the packing material. 4.
  • Page 8 5. Avoid pinching the wires. Slide the Upright (2) onto the Frame (1). Avoid pinching the wires Attach the Upright (2) with four M10 x 62mm Screws (70); start all four Screws, and then tighten them. 6. Press the Front Shield (58) onto the Frame (1) and onto the Right Front Shield (14) and the Left Front Shield (not shown).
  • Page 9 7. See the inset drawing. Grip the connector on the end of the Main Wire (43). Then, press the small latch (C) on the wire pull (B), and remove the wire pull. Then, remove the wire pull (B) from the Control Wire (42). Discard the wire pulls and the wire ties (A).
  • Page 10 9. Orient the Lower Console Cover (57) as shown, and press it onto the back of the Console (4). Then, orient the Upper Console Cover (69) as shown, and press it onto the back of the Console (4). 10. Attach the Seat Frame (10) and the attached Seat (9) to the Seat Carriage (41) with four M8 x 18mm Screws (67);...
  • Page 11 11. Slide the Backrest Frame (81) onto the Seat Frame (10). Attach the Backrest Frame (81) with four M6 x 30mm Screws (75) and four M6 Washers (88); start all four Screws, and then tighten them. 12. Identify the Right Pedal (21). Using your fingers, turn the Right Pedal about halfway into the Right Crank Arm (23).
  • Page 12 13. Plug the Power Adapter (51) into the receptacle (H) on the left side of the exercise bike. Note: To plug the Power Adapter (51) into an outlet, see HOW TO PLUG IN THE POWER ADAPTER on page 13. 14. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly and that it functions properly.
  • Page 13 HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER ADAPTER HOW TO ADJUST THE PEDAL STRAPS To tighten a pedal IMPORTANT: If the exercise bike has been exposed strap (C), pull down- to cold temperatures, allow it to warm to room tem- ward on the end of perature before you plug in the power adapter (A).
  • Page 14 HOW TO USE THE CONSOLE With an iFIT subscription, you can access a large and FEATURES OF THE CONSOLE varied library of thousands of destination and studio The console offers a selection of features designed to workouts, create your own workouts, track your work- make your workouts more effective and enjoyable.
  • Page 15 Pulse (BPM and heart symbol)—Your heart rate HOW TO USE THE MANUAL MODE when you use a compatible heart rate monitor (see page 21). 1. Turn on the console. To turn on the console, press any button on the Resistance (RESIST)—The resistance level of the console or simply begin pedaling.
  • Page 16 You can also customize the scan mode to display 5. Pause or end the workout. only the desired workout information in the repeat- ing cycle. To pause the workout, simply stop pedaling. When the workout is paused, the time will flash in the display.
  • Page 17 4. Select an iFIT workout. The console offers access to a large and varied library In the iFIT app, touch the buttons at the bottom of of iFIT workouts when you download the iFIT app to the screen to select either the home screen (Home your smart device and connect it to the console.
  • Page 18 To disconnect your smart device from the console, first select the disconnect option in the iFIT app. Software Version Number—The software version Then, press and hold the iFIT Sync button on the number will appear in the display. console until the LED on the console turns solid green or the Bluetooth symbol disappears from the Unit of Measurement—The currently selected...
  • Page 19 Total Time—The word TIME will appear in the Demo Mode—The currently selected demo mode display. The display will show the total number of option will appear in the display. The console hours that the exercise bike has been used. features a demo mode, designed to be used if the exercise bike is displayed in a store.
  • Page 20 HOW TO USE THE CHARGING PORT HOW TO USE THE SOUND SYSTEM The console features a charging port to charge USB-C 1. Make sure that your device’s Bluetooth setting compatible devices, such as smartphones and tablets, is turned on, and hold your device near the while you exercise.
  • Page 21 HOW TO USE AN OPTIONAL HEART RATE To connect your Bluetooth Smart heart rate moni- tor to the console, press the iFIT Sync button on the MONITOR console; the console pairing number will appear in the Whether your goal display. When your heart rate monitor is connected, the is to burn fat or to LED on the console will flash red twice.
  • Page 22 FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 23 If further Shields (13, 14); make sure to note which Screw assistance is needed, you remove from each hole. Then, carefully remove go to my.iFIT.com, scan the Left Front Shield. the QR code at the right, or call 1-833-680-IFIT Next, locate the Reed Switch (46).
  • Page 24 Next, loosen the M6 x 20mm Hex Screw (84). Then, CONSOLE TROUBLESHOOTING tighten the M10 x 50mm Hex Screw (83) until the Drive If the console does not turn on, make sure that the Belt (47) is tight. When the Drive Belt is tight, tighten power adapter is fully plugged in.
  • Page 25 EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 26 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 27 NOTES...
  • Page 28 PART LIST Model No. NTEX99025.0 R0724B Key No. Qty. Description Key No. Qty. Description Frame Reed Switch/Wire Upright Drive Belt Foot Stabilizer Cap Console Clip Nut Rail Flange Screw Adjustment Bar Power Adapter M6 x 16mm Screw Shield Disc Backrest Right Rear Shield Seat Left Rear Shield...
  • Page 29 Key No. Qty. Description Key No. Qty. Description M8 Split Washer M6 x 65mm Bolt Crank Cap M6 Locknut Barrel Nut M6 Small Washer Tree Fastener – Assembly Tool M10 Flange Nut – User’s Manual M6 Split Washer Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
  • Page 30 EXPLODED DRAWING A Model No. NTEX99025.0 R0724B...
  • Page 31 EXPLODED DRAWING B Model No. NTEX99025.0 R0724B...
  • Page 32 (5) if the product is modified to alter functionality or capability without the written permission of iFIT, or (6) if the product is used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by iFIT.
