- Page 1 Installation and User Manual OUTDOOR GRILL HOODS GOi, GOU, & GOW MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ......1 BEFORE INSTALLATION ......... . 5 Ventilation and Clearances . -
Page 5: Important Safety Instructions
• The installer should leave these instructions with the consumer who should retain for local inspectors’ use and for future reference. • Due to the size and weight of ZLINE range hoods and grill hoods, two-person installation is highly recommended. - Page 6 Never use abrasive powders or liquids. • All ZLINE range hoods and grill hoods are ETL-listed, ensuring all parts were tested for safety and meet industry standards and regulations.
- Page 7 • Before installing your unit, test the grill hood for proper functionality by plugging it into an appropriate outlet and testing the fan and lights. Do not install any appliance if it has missing or broken parts. If units arrive damaged, contact ZLINE Customer Service at 1-614-777-5004 for help.
- Page 8 • DO NOT USE WATER, including wet dish clothes or towels - a violent steam explosion may result. WARNING: ZLINE grill hoods are designed for outdoor use only in barbecue grill and other outdoor cooking environments. Do not install or operate this...
-
Page 9: Before Installation
BEFORE INSTALLATION VENTILATION AND CLEARANCES It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and cause a fire hazard. Hoods mounted too high will be hard to reach and will lose performance and efficiency. 36"... -
Page 10: Before Installation
1,000 CFM per cap. VENTING REQUIREMENTS • Ducting is not provided with your ZLINE grill hood. It’s recommended to use solid ducting made of galvanized steel or another appropriate rigid metal ducting whenever possible for the lowest noise and highest flow. -
Page 11: Installation
BEFORE INSTALLATION FOR THE MOST EFFICIENT AND QUIET OPERATION • A minimum of 8" (203 mm) round (standard for this grill hood) or 3 1/4 x 10" (83 mm x 254 mm) rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. -
Page 12: Before Installation
BEFORE INSTALLATION SMOKE CAPTURE RECOMMENDATIONS Smoke and hot air from an outdoor barbecue grill rises quickly, especially as the lid is opened. Not only does the smoke rise fast, but it is usually deflected forward (toward the cook) beyond the grill hood’s capture area by the shape and position of the lid itself. Heavy, fast rising smoke is a challenge even for high-performance grill hoods, but there are some things you can do to enhance your outdoor hood’s performance. - Page 13 BEFORE INSTALLATION • Turn the hood on high 2-3 minutes prior to placing food on a grill or other cooktop below. If there is no wind or wind drafts, an upward flowing air “curtain” will be created by the hood’s suction that moves air up the sides and front of the cooking surface. This upward moving air curtain will help capture much of the smoke.
-
Page 14: Product Specifications
BEFORE INSTALLATION PRODUCT SPECIFICATIONS Models GOi, GOU, GOW Series Power Rating 120VAC/60Hz (USA & Canada standard) Motor Input Power 720W (360W+360W) Amperes Levels Of Speed Control 4 Levels Airflow 2000CFM (1000 x2) Number of Motors Dual Motor Motor Type Dual Chamber Ultra Quiet... -
Page 15: Parts Needed
ISLAND MODELS BEFORE INSTALLATION PARTS NEEDED • Power Drill • Flat Head/Phillips Screwdrivers • Drill Bits • Tape Measure • Masking Tape • Pencil/Marker • Metal or Aluminum HVAC Tape • Plumb Bob/Laser Level • Scissors/Box Cutter • 2x4s or Appropriate Framing Material* * 2x4s and other additional framing material may be required if installing extra supports, or if ceiling joists are not available in installation location. - Page 16 ered drill ISLAND MODELS BEFORE INSTALLATION blade and Phillips screwdriver BEFORE INSTALLATION SUPPLIED IMAGE PARTS SUPPLIED PARTS NEEDED RIPTION IMAGE • Marker or pencil DESCRIPTION IMAGE • Utility knife cabinet Range Hood • Measuring tape Island Grill Hood • Level •...
-
Page 17: Product Dimensions
ISLAND MODELS BEFORE INSTALLATION PRODUCT DIMENSIONS 20 9/16" (522 mm) 16 5/16" (414 mm) 2 x 19 11/16" (500 mm) (telescoping sleeves) 39 3/4" (1010 mm) - Page 18 ISLAND MODELS INSTALLATION PREPARE DUCTWORK Plan where your ductwork will be located. Install the proper sized ductwork and exterior roof cap, depending on where you will be venting your hood to the exterior. Ductwork should be ready to hook up to the hood before beginning installation. See venting requirements. S L A N D H O O D I N S T A L L A T I O N First, Draw These Markings on the Installation Area Ceiling: •...
- Page 19 ISLAND MODELS INSTALLATION S L A N D H O O D I N S T A L L A T I O N STEP 1 nstallation area ceiling Mark Ceiling nstallation area. • Find the joists in your ceiling. •...
- Page 20 I S L A N D H O O D I N S T A L L A T I O N ISLAND MODELS INSTALLATION arks from Step 1. These holes should hit ming. where the ducting will go and nish STEP 3 Install Support Brackets: t ceiling and screw securely into place.
- Page 21 ISLAND MODELS INSTALLATION I S L A N D H O O D I N S T A L L A T I O N STEP 5 er support brackets, covering the ceiling Attach Hood • Secure it to the base of your hood before mounting. ceiling bracket.
-
Page 22: Parts Supplied
UNDERCAB MODELS BEFORE INSTALLATION PARTS NEEDED • Pencil/Marker • Utility Knife • Tape Measure • Level • Powered Drill • Flat Head/Phillips Screwdrivers PARTS SUPPLIED DESCRIPTION IMAGE Undercabinet Grill Hood Wall Mount Bracket Screws 4 x 25 mm Wall Mount Bracket Screws 4 x 12 mm Flat Head Screws (optional for single-piece chimney) Round Head Screws for Ducting Transition Piece Ducting Transition Piece... - Page 23 UNDERCAB MODELS BEFORE INSTALLATION PRODUCT DIMENSIONS...
- Page 24 WALL MODELS BEFORE INSTALLATION RE INSTALLATION PARTS NEEDED • Power Drill • Flat Head/Phillips Screwdrivers • Drill Bits • Tape Measure NEEDED • Masking Tape ker or pencil • Pencil/Marker • Metal or Aluminum HVAC Tape y knife • Plumb Bob/Laser Level suring tape wdriver •...
- Page 25 Undercabinet Range Hood Two-piece Chimney WALL MODELS BEFORE INSTALLATION Wall Mount Bracket Screws 4 x2 5 Wall Mount Bracket Screws 5 x12 Round Head Screws for Chimney 4X8 Round Head Screws for Chimney 4 X 1 2 DESCRIPTION IMAGE Round Head Screws for Ducting Transition Piece 4 Plastic Anchors Plastic Anchors Nuts...
- Page 26 WALL MODELS BEFORE INSTALLATION PRODUCT DIMENSIONS 31 5/16" (795 mm) 2 x 15 3/4" (400 mm) (telescoping sleeves) 15 3/4" (400 mm)
-
Page 27: Undercab & Wall Models
UNDERCAB & WALL MODELS INSTALLATION PREPARATION Remember to plug in and test the hood before installation. When planning for the installation of the hood, please include an opportunity to access the top of the hood when the installation is complete. This is necessary for service and or replacing parts over time as several fasteners will need to be accessed. -
Page 28: Installation
UNDERCAB & WALL MODELS INSTALLATION W A L L H O O D I N S T A L L A T I O N STEP 1 • lnstall the wall bracket at a predetermined First draw these markings on the installation area wall location that complies with the height •... - Page 29 W A L L H O O D I N S T A L L A T I O N UNDERCAB & WALL MODELS INSTALLATION ceiling, matching the center STEP 3 - WALL HOOD ONLY of the installation area. Hang Grill Hood and Connect: s on the wall and drill the holes •...
- Page 30 UNDERCAB & WALL MODELS INSTALLATION STEP 4 • Hang the hood on the wall bracket. You will see 2 rectangular openings between the wall mount bracket and the hood itself. These two openings will be installed over and down into the corresponding openings on the wall bracket. Once in place, secure the wall mount bracket to the wall bracket with the appropriate screws for the material you are mounting to.
-
Page 31: Motor Rotation (Optional)
UNDERCAB MODELS INSTALLATION MOTOR ROTATION (OPTIONAL) GETTING STARTED The motor position directly from the factory is used when running vertical pipe for your venting. The motors can be rotated to allow for ducting from the rear of the unit if top ducting is not possible. - Page 32 UNDERCAB MODELS INSTALLATION STEP 6: ATTACH THE MOTOR Re-attach the motor to the cover plate. Start with the center screw, which was the last screw removed when the motor was dis-attached. Once the initial screw is in place, attach the remaining screws to hold the motor onto the cover plate.
-
Page 33: Grease Tunnel Installation
INSTALLATION GREASE TUNNEL INSTALLATION Install the two grease tunnels in the front and back of the unit. When installed, these tunnels will accept the baffle filters on the bottom side. The front grease tunnel will provide a barrier between the filters and the control knob connections. The rear grease tunnels are installed in the rear channel at the back of the unit. -
Page 34: Baffle Filter Installation
INSTALLATION BAFFLE FILTER INSTALLATION Never work on or clean the hood while power is on. Always unplug the unit or switch the electrical breaker to the off position. WARNING Install all baffle filter handles to the filters using the round head screws. Some filters cover the front section of the hood and some cover the back There is an equal number of filters in the front and the back. -
Page 35: Operation
OPERATION USER MANUAL | USER MANUAL | Control Panel Control Panel BUTTON PANEL FUNCTIONS To power on the hood, flip the switch on the right. Turn on the fan any time that a barbecue or other cooktop below is in use. A) LEFT FAN: A) LEFT FAN: A. -
Page 36: Cleaning And Maintenance
CLEANING AND MAINTENANCE Never clean the grill hood while the power is on. Always unplug the unit or switch the electrical breaker to the off position. Do not put your hand or body parts WARNING inside the hood’s motor while in operation. Do not operate the hood when filters are removed. - Page 37 CLEANING AND MAINTENANCE CLEANING BAFFLE FILTERS • All ZLINE hoods come with stainless steel baffle filters. They should be inspected for grease accumulation periodically. The baffle filters can be washed in a dishwasher or in a sink with hot, soapy water. Simple periodic cleaning will ensure maximum filter effectiveness.
-
Page 38: Troubleshooting
TROUBLESHOOTING ISSUE SOLUTION Turn on power at circuit breaker panel or fuse box. Check for No response tripped breaker or blown fuse under the black plastic cover on the (control panel not rear of the hood. responding, blower not working) Make sure hood power cable is plugged in and powered. - Page 39 Reference "Blower system seems weak" on the previous page. If a problem cannot be resolved after following the instructions in this manual, please contact ZLINE Customer Service at 1-614-777-5004. Never attempt to WARNING repair or disassemble a faulty hood. Always consult a professional.
-
Page 40: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath (“ZLINE”) grill hood parts will be warrantied for three years from the original date of product delivery for the original purchaser of the product. ZLINE warranty periods begin from the original date of product delivery and solely cover the original purchaser of the product, delivered new and in its original carton. - Page 41 If ZLINE is unable to replace the defective part after a reasonable number of attempts, ZLINE reserves the right to offer to replace the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
-
Page 42: Serial Number Location
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help. - Page 43 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of ZLINE’s range/grill hood Installation and User Manuals. Need to purchase a part or accessory for your ZLINE product? Visit...
- Page 44 1.1.0 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
