- Page 1 Installation and User Manual RANGE HOODS 520, 523, & 527 MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 BEFORE INSTALLATION ....... 4 Product Specifications . -
Page 5: Important Safety Instructions
• The installer should leave these instructions with the consumer who should retain for local inspectors’ use and for future reference. • Due to the size and weight of ZLINE range hoods, two-person installation is highly recommended. • Use care when handling the range hood, chimney cover, baffle filters, and any parts or accessories, as sharp edges may lead to injury. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • Ducted range hoods MUST ALWAYS be vented to the outdoors or in some instances converted to recirculate the air. All ZLINE hoods come with a transition piece with a built-in damper. • Some existing installations may already have an external damper at the exit point of the home.
- Page 7 DO NOT vent exhaust into spaces between walls, crawl spaces, ceilings, attics, basements, or garages. • All ZLINE range hoods are ETL-listed, ensuring all parts were tested for safety and meet industry standards and regulations. • You must purchase appropriate flexible ducting and any additional items to vent the hood in accordance with government codes.
-
Page 8: Before Installation
BEFORE INSTALLATION PARTS NEEDED • Marker or pencil • Utility knife • Measuring tape • Level • Powered drill • Flat-blade and Phillips screwdriver PARTS SUPPLIED DESCRIPTION IMAGE Undercabinet Range Hood Single-piece Chimney Wall Mount Anchors Wall Mount Screws Flat Head Screws (optional for single-piece chimney) Wall Mount Bracket Screws Round Head Screws for Ducting Transition Piece Washers... -
Page 9: Product Specifications
BEFORE INSTALLATION PRODUCT SPECIFICATIONS Sizes 30"–48" 54"–60" 520-30, 520-36, 520-42, 520-48 520-54, 520-60 Models 523-30, 523-36, 523-42, 523-48 523-54, 523-60 527-30, 527-36, 527-42, 527-48 527-54, 527-60 Seamless Stainless Steel, Seamless Stainless Steel, Body Design Satin Finish Satin Finish 120VAC/60Hz (USA & 120VAC/60Hz (USA &... -
Page 10: Product Dimensions
BEFORE INSTALLATION PRODUCT DIMENSIONS 520 Series (Models 520-30, 520-36, 520-42, 520-48) 520 Series (Models 520-54, 520-60) - Page 11 BEFORE INSTALLATION PRODUCT DIMENSIONS 523 Series (Models 523-30, 523-36, 523-42, 523-48) 523 Series (Models 523-54, 523-60)
- Page 12 BEFORE INSTALLATION PRODUCT DIMENSIONS 527 Series (Models 527-30, 527-36, 527-42, 527-48) 527 Series (Models 527-54, 527-60)
- Page 13 BEFORE INSTALLATION PRODUCT DIMENSIONS Rear knockout hole dimensions 30"–42" models 54" & 60" models 1/4" (7 mm) 1" (25 mm) 6" (152 mm) 7 1/2" (191 mm)
- Page 14 BEFORE INSTALLATION PRODUCT DIMENSIONS Hood-mounting bracket dimensions 1/4" (7 mm) 1" (25 mm) 6" (152 mm) 7 1/2" (191 mm)
-
Page 15: Circuit Diagrams
BEFORE INSTALLATION CIRCUIT DIAGRAMS 30"–48" models WARNING Risk of electrical shock. This range hood must be properly grounded by a qualified electrician in accordance with all applicable national and local electrical codes. Before connecting wires, switch power off at the service panel and lock it to prevent power from being switched on accidentally. -
Page 16: Ventilation And Clearances
BEFORE INSTALLATION VENTILATION AND CLEARANCES Cabinet or Single-Piece Cabinet Chimney (Optional) Height Range Hood Height Under Cabinet Range Hood Min: 30" Max: 36" Ceiling Height Countertop/Stove NOTE: recommended height to install your hood is 30" 36" (762 mm) minimum and 36" Counter (914 mm) maximum above your range top or cook top. -
Page 17: Venting Requirements
• Determine the location of the venting pipe from the hood to the outside of your home before installation. • Ducting is not provided with your ZLINE range hood. It’s recommended to use solid ducting made of galvanized steel or another appropriate rigid metal ducting whenever possible for the lowest noise and highest flow. -
Page 18: Venting Methods
BEFORE INSTALLATION Side Wall Cap VENTING METHODS This range hood is factory set for venting through the roof or wall. Vent work can terminate either through the roof or wall. To vent through a wall, use a 90° elbow. Below are examples of appropriate ducting options. - Page 19 BEFORE INSTALLATION To avoid damage to your hood or potential future injury, use care to prevent any debris from entering the vent opening. WARNING 4" (102 mm) wide 4" (102 mm) wide Figure 1 Figure 2 Figure 3 Prior to installation, determine the location of the venting pipe from the hood to the outside. Refer to “Venting Requirements”...
-
Page 20: Installation
INSTALLATION INSTALLATION OPTIONS INSTALLATION - OPTION 1 1. Measure the distance between stove top and the bottom Figure 4 of range hood. A distance of 30" to 36" (762 mm to 914 mm) is recommended. Center the hood beneath the cabinet so it is flush with the front of the cabinet. -
Page 21: Final Installation Steps
INSTALLATION FINAL INSTALLATION STEPS 1. Once the hood is secure, attach the appropriate ducting for your hood to the ducting transition piece that was previously installed. See Figure 7 below. 2. Connect the range hood to a designated standard outlet (120-VAC, 60Hz, AC only) or cut off the plug and connect three wires (black, white, green) to house wires and secure with wire connectors/wire nuts. -
Page 22: Baffle Filters
INSTALLATION Baffle Filters and Stainless Steel Spacers: 5. To install baffle filters and stainless spacer(s), refer to the images below and Figure 10 30" Range Hood on the previous page: Angle the baffle filter toward the back of hood. Push the filter up until almost level. -
Page 23: Operation
OPERATION BUTTON PANEL FUNCTIONS NOTE: While some range hood models, depending on manufacture date, may have different button layouts, operation is largely the same. Decrease Increase Speed Speed LED Light LED Speed Indicator Indicators Light Control Power Control (On/Off) FAN SPEED AND LIGHT CONTROLS The four main buttons control the intensity of the Lights, Fan Speed Control (Quiet, Low, Medium and High) and Power (On/Off). -
Page 24: Light Control
OPERATION 3-MINUTE DELAY • While fans are operating, press the Power Control (On/Off) button once. The LED Speed Indicators for the active power level will flash, and fans will turn off after 3 minutes. • During the 3-minute delay, changing speeds will not affect the countdown. •... -
Page 25: Cleaning And Maintenance
CLEANING AND MAINTENANCE Never clean the range hood while the power is on. Always unplug the unit or switch the electrical breaker to the off position. Do not put your hand or body WARNING parts inside the hood’s motor while in operation. Do not operate the hood when filters are removed. -
Page 26: Replacing Light Bulbs
CLEANING AND MAINTENANCE REPLACING LIGHT BULBS Never replace light bulbs while the power is on. Always unplug the unit or switch the electrical breaker to the off position. This range hood uses 20-watt, 12-volt WARNING halogen bulbs. Do not handle halogen bulbs with bare fingers, as this will leave oily residue on bulbs and may shorten the life of the bulb. -
Page 27: Troubleshooting
Make sure the power is on high speed for heavy cooking. If a problem cannot be resolved after following the instructions in this manual, please contact ZLINE Customer Service at 1-614-777-5004. Never attempt to WARNING repair or disassemble a faulty range hood. Always consult a professional. -
Page 28: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath (“ZLINE”) range hood parts will be warrantied for three years from the original date of product delivery for the original purchaser of the product. ZLINE warranty periods begin from the original date of product delivery and solely cover the original purchaser of the product, delivered new and in its original carton. - Page 29 If ZLINE is unable to replace the defective part after a reasonable number of attempts, ZLINE reserves the right to offer to replace the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
-
Page 30: Serial Number Location
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help. - Page 31 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of ZLINE’s range hood Installation and User Manuals. Need to purchase a part or accessory for your ZLINE product? Visit...
- Page 32 1.0.0 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
