  • Page 1 Installation and User Manual WALL RANGE HOODS zlinekitchen.com...
  • Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
  • Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.

  • Page 4: Table Of Contents

    Designer Wall Hood Installation ..... . 1 1 CrownSound Installation ......17 ™...

  • Page 5: Important Safety Instructions

    • The installer should leave these instructions with the consumer who should retain for local inspectors’ use and for future reference. • Due to the size and weight of ZLINE range hoods, two-person installation is highly recommended. • Use care when handling the range hood, chimney cover, baffle filters, and any parts or accessories, as sharp edges may lead to injury.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS • Ducted range hoods MUST ALWAYS be vented to the outdoors or in some instances converted to recirculate the air. All ZLINE hoods come with a transition piece with a built-in damper. • Some existing installations may already have an external damper at the exit point of the home.
  • Page 7 DO NOT vent exhaust into spaces between walls, crawl spaces, ceilings, attics, basements, or garages. • All ZLINE range hoods are ETL-listed, ensuring all parts were tested for safety and meet industry standards and regulations. • You must purchase appropriate flexible ducting and any additional items to vent the hood in accordance with government codes.

  • Page 8: Before Installation

    BEFORE INSTALLATION RANGE HOOD MEASUREMENTS NOTE: The recommended height to install your hood is 30" (762 mm) minimum and 36" (914 mm) maximum above your cooking surface. These distances allow for optimal venting efficiency. The height of your chimney will vary depending on model of hood, as well as the height of your kitchen ceiling.
  • Page 9 BEFORE INSTALLATION PARTS Unpack your range hood upon delivery and inspect to ensure all parts are included: DESCRIPTION IMAGE Main hood with lights and button panel pre-installed 2. Adjustable chimney covers — two 16" (407 mm) telescoping pieces 3. Transition piece (for 6" or 8"/ for 152 mm or 203 mm)* *Wall hoods with single motors come with a square-to-round transition piece that includes a back draft damper.
  • Page 10 BEFORE INSTALLATION DUCTING REQUIREMENTS NOTES: • Ducting is not provided with your ZLINE range hood. It’s recommended to use solid ducting made of galvanized steel or another appropriate rigid metal ducting whenever possible for the lowest noise and highest flow.

  • Page 11: Installation

    INSTALLATION WALL HOOD INSTALLATION MOUNTING DIRECTIONS 1. Based on the width of your hood, measure to find the center of the wall. Mark a line and measure to the left and right to find your two mounting points. Make sure the mounting points are level and mark the area with a pen.
  • Page 12 INSTALLATION WALL HOOD INSTALLATION 5. Install the transition piece on top of the range hood by securing it with screws (Item No. 15) provided. Some hoods require 4 screws, others require 6. NOTE: In some models, the transition piece will already be installed. Figure 4 6.
  • Page 13 INSTALLATION WALL HOOD INSTALLATION 8. Place the two-part telescoping chimney on top the hood. Slide the inside section up until the vertical vent slots are visible, then attach the top portion to the mounting bracket with 2 screws (Item No. 14). Secure the lower portion to the hood with 2 screws (Item No.
  • Page 14 INSTALLATION WALL HOOD INSTALLATION If you purchased specialty crown molding to install with your range hood, follow these instructions before attaching the ducting and chimney sections. 1. Secure the crown molding bracket to the ceiling directly above the range hood by using the hardware provided with the crown molding.

  • Page 15: Installation

    INSTALLATION DESIGNER WALL HOOD INSTALLATION DESIGNER HOOD MEASUREMENTS Scan for a designer wall range hood installation tutorial video. Please note that depending on model of range hood, some installation processes may vary.
  • Page 16 INSTALLATION DESIGNER WALL HOOD INSTALLATION PARTS Unpack your range hood upon delivery and inspect to ensure all parts are included: DESCRIPTION IMAGE Main hood with lights and button panel pre-installed 2. Adjustable chimney covers — two 16" (407 mm) telescoping pieces 3.
  • Page 17 INSTALLATION DESIGNER WALL HOOD INSTALLATION NOTE: Like other wall hoods, use a maximum of 40' (12192 mm) of ductwork and minimize use of elbows. You must establish a minimum of 12" (305 mm) of vertical airflow from the top of the hood before executing any 90° turn. No more than 3 elbows are allowed; each 90°...
  • Page 18 INSTALLATION DESIGNER WALL HOOD INSTALLATION 4. Install the transition piece on top of the range hood by securing it with screws (Item No. 14) provided. Some hoods require 4 screws, others require 6. Figure 3 5. Secure your ducting connection to the transition piece using foil-backed tape to hold it into place top of the hood.
  • Page 19 INSTALLATION DESIGNER WALL HOOD INSTALLATION 7. After precisely measuring the distance between the top of the range hood and your ceiling, have a trained professional cut your one-piece designer chimney to the desired length; you must leave a 2 1/4" (57 mm) gap between the chimney and ceiling in order to install the crown molding.
  • Page 20 INSTALLATION INSTALLING OR REPLACING A RANGE HOOD HANDLE If you’ve purchased a ZLINE range hood with a stainless steel handle — or if you’re installing an Autograph Edition handle with Champagne Bronze, Polished Gold, or Matte Black accents, an example of which is below — use the following installation process.

  • Page 21: Crownsound Installation

    Frequency: 120VAC/60 Hz | Power: 10 W If you’ve purchased a ZLINE range hood with CrownSound , follow these installation steps. ™ NOTE: Recirculating your range hood is not possible with CrownSound installation. ™ Scan here for a CrownSound ™...
  • Page 22 The crown should cover the gap. Ensure that it installs properly and is level. Figure 3 Figure 3 4. Open the phone’s Bluetooth settings and find “ZLINE Audio.“ When the connection is successful, a chime will sound. Figure 4 Figure 4 NOTE: CrownSound moldings carry a one-year parts warranty.

  • Page 23: Operation

    OPERATION Button Control Panel Operational Manual BUTTON FUNCTIONS (SOME MODELS HAVE DIFFERENT CONTROL PANEL LAYOUTS) Light High Speed Power Power-Off Delay Medium 2 Speed Low Speed Blower Speed Indicator Medium 1 Speed • Power: Turn ON/OFF the range hood and activate the power-off delay timer. •...

  • Page 24: Replacing Parts

    REPLACING PARTS HOW TO REPLACE THE BUTTON PANEL 1. Remove baffle filters from underneath the hood. 2. Locate the back of the button panel. 3. Remove screws from each side of the button panel. 4. Disconnect the panel from the cord connecting to the circuit board, an overlay of which is included below.

  • Page 25: How To Replace The Circuit Board

    REPLACING PARTS HOW TO REPLACE THE CIRCUIT BOARD 1. Turn the power off at the breaker and unplug the range hood. 2. Remove screws from the top of the circuit board cover (circled in blue below). 3. Take a picture of the wiring layout (this will help you put the circuit board back together properly).

  • Page 26: How To Replace The Light Bulbs In Your Range Hood

    REPLACING PARTS HOW TO REPLACE THE LIGHT BULBS IN YOUR RANGE HOOD 1. Turn the power off at the breaker and unplug the range hood. 2. Remove baffle filters from underneath the hood. 3. Squeeze the LED light assembly out until it falls out of the socket as noted in the images below.

  • Page 27: How To Replace The Capacitor

    REPLACING PARTS HOW TO REPLACE THE CAPACITOR 1. Turn the power off at the breaker and unplug the range hood. 2. Remove screws from the circuit board cover in a similar fashion as page 21. 3. Remove the screw securing the capacitor (circled in blue) to the circuit board. Figure 1 4.

  • Page 28: How To Replace The Transformer

    REPLACING PARTS HOW TO REPLACE THE TRANSFORMER 1. Turn the power off at the breaker and unplug the range hood. 2. Remove screws from the circuit board (circled in blue) cover in a similar fashion. Figure 1 3. Locate the wire coming from the transformer (circled in pink) to the circuit board and remove the two wired connections from the circuit board.
  • Page 29 REPLACING PARTS SINGLE MOTOR ELECTRICAL DIAGRAM ground ground...
  • Page 30 REPLACING PARTS DUAL MOTOR ELECTRICAL DIAGRAM ground ground ground...

  • Page 31: How To Replace Professional Series Baffle Channels And Filters

    HOW TO REPLACE PROFESSIONAL SERIES BAFFLE CHANNELS AND FILTERS Covering models 696, 697, and KECOM. ZLINE’s professional series range hoods are equipped with two removable dishwasher-safe baffle channels in which the filters rest. To install the channels, place them inside the hood under the front and back edges of the hood.

  • Page 32: How To Replace Spring-Loaded Baffle Filters

    REPLACING PARTS Edges on the baffle filters and baffle channels may be sharp — please use caution when installing and removing. Use of gloves during installation is WARNING highly recommended. Do not attempt to disassemble baffle filters, as the process may result in injury. HOW TO REPLACE SPRING-LOADED BAFFLE FILTERS If your range hood has baffle filters with a knob, to remove the filter from the hood, pull back toward the wall and then tilt the knob side of the baffle filter downward.

  • Page 33: How To Replace Or Change Charcoal Filters

    REPLACING PARTS HOW TO REPLACE OR CHANGE CHARCOAL FILTERS It is recommended to use ducting to direct vent your range hood whenever possible If your situation does not allow for a direct vent installation, carbon charcoal filters are available to recirculate the air through your hood.

  • Page 34: How To Clean And Replace The Grease Cup

    REPLACING PARTS HOW TO CLEAN AND REPLACE THE GREASE CUP A removable plastic grease cup is designed to catch excess grease at the bottom of the motor. It’s recommended to remove it every 2–3 months, wash it, then re-install it. To remove or install the grease cup, remove the baffle filters on your hood and slide the cup it into brackets located at the bottom of the motor.

  • Page 35: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS NOTE: Some of these questions are specific to certain types of ZLINE range hoods and as such may not be applicable to some models. Are ZLINE range hoods considered type 1 or type 2? Type 1 — these types of range hoods are used with ranges, cooking surfaces, and appliances that produce grease and smoke.
  • Page 36 It is better to duct your range hood to the outside, but if this is not possible, ductless is an acceptable alternative. Many ZLINE range hoods have the capability to be converted to ductless. Ductless is when the air circulates through charcoal filters to remove odors, grease, smoke, etc.
  • Page 37 DO NOT vent exhaust air back into the spaces within the walls, ceilings, attics, crawl spaces, or garages. A buildup of humidity and grease could cause damage and/or a fire risk to your home. How many devices can the CrownSound speakers sync to at a time? ™...

  • Page 38: Troubleshooting

    Check if the electrical Bluetooth settings to allow time for “ZLINE Audio” connections are secure. the CrownSound to pair. If “ZLINE ™ won’t appear in the A chime will sound if the Audio” still will not appear, call Bluetooth settings.
  • Page 39 TROUBLESHOOTING ISSUE POSSIBLE CAUSE / SOLUTION Check electrical connections. My range Check that all connections to the circuit board are secure. hood does not have power. If problem still exists, please call our customer service line. Were the fan speeds checked fan speeds prior to installation? Is the ducting clear? Check to make sure motor is attached to housing.
  • Page 40 TROUBLESHOOTING ISSUE POSSIBLE CAUSE / SOLUTION Was the unit plugged in and was the fan checked before installation? What distance is the hood mounted above the cooking surface? Make sure the distance is 30"–36" (762 mm–914 mm). Is the range hood width the correct size for the cooking surface? Does the hood move enough CFM in relationship to the BTUs of the cooking surface? Remember —...

  • Page 41: Warranty

    WARRANTY COVERAGE ZLINE Kitchen and Bath (“ZLINE”) range hood parts will be warrantied for three years from the original date of product delivery for the original purchaser of the product. ZLINE warranty periods begin from the original date of product delivery and solely cover the original purchaser of the product, delivered new and in its original carton.
  • Page 42 All warranty procedures must be followed to maintain warranty coverage. If ZLINE is unable to replace the defective part after a reasonable number of attempts, ZLINE reserves the right to offer to replace the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
  • Page 43 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
  • Page 44 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of ZLINE’s range hood Installation and User Manuals. Need to purchase a part or accessory for your ZLINE product? Visit...
  • Page 45 2.0.1 zlinekitchen.com 1-614-777-5004 contact@zlinekitchen.com...
