- Page 1 Installation Guide Comet Series Speed Gate Applicable Model(s): Comet-S1000, Comet-S1200 Version: 1.1 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Revision History
Revision History Description Revision Date Author Reviewer Yang Kaijin Original Document 08/09/2023 V1.0 The appearance of the device Yang Kaijin and wiring diagram have been 02/23/2024 V1.1 changed. -
Page 3: Installation Requirements
1 Installation Requirements It is recommended that the device be installed on a level and solid floor. If the floor is uneven or not strong enough to hold the device in place, resurface the floor or use a pedestal mount to alleviate the change problem. -
Page 4: Installation
3 Preparation Before installing the device, make sure that you have the following items: Screwdriver Pencil Electric Drill Wrench Hex Wrench Cutting Machine Hammer Tapeline Note: Except for the hex wrench, all other tools should be provided by you. 4 Installation After checking the list to ensure all devices and items are correct, transport the device to its installation location. - Page 5 Remove the two screws hidden under the top lid, then open and flip the top lid of the device (Same for the slave). ② Flip the top lid ① Remove the screws Remove the mounting rail from the device (Same for the slave). Remove the ①...
- Page 6 Remove the master's power supply cover. Carry the mounting rail to the location where it will be mounted. Use a pencil to mark down the screw holes, wire holes, and conduits of the mounting rail. ① 1300mm Screw Hole Wire Hole...
- Page 7 ② L: ≥93mm W: 60mm L: ≥927mm Conduit W: 30mm Note: For device safety and future maintenance, when installing, encase the power cable, network cable, and tether cable within a PVC pipe with a 20mm diameter. The conduit diameter should exceed 20mm; this guide recommends using a 30mm diameter as an example.
- Page 8 Use a cutting machine to create two conduits on the ground according to the marking of the mounting rail. One conduit should have a length greater than or equal to 93mm, a width of 60mm, and a depth of 100mm. The other conduit should have a length greater than or equal to 927mm, a width of 30mm, and a depth of 100mm.
- Page 9 Reposition the mounting rail at the installation site and verify if the drilled holes and conduits align with the marks on the mounting rail. Place the 20mm diameter PVC pipe into the conduit.
- Page 10 Insert the power cable and ethernet cable into the PVC pipe to connect the power supply and access controller. Master Master Power Supply...
- Page 11 Pull the tether cable out of the master, insert it through the PVC pipe buried in the conduit, and connect it to the Slave. Then, turn on the power switch to test if the device is working properly. The tether cable consists of three cables that connect to the master and slave turnstile control boards, the master and slave motor drive, and the light control board.
- Page 12 If all functions of the device are normal, disconnect the power supply, then insert the bolts and secure them with a hammer. Finally, insert the washers and nuts and tighten with a wrench to secure the mounting rails. Bolt Washer Pour the concrete to fill the conduit Pour Concrete...
- Page 13 Secure the master and slave to the mounting rails separately. ② Fasten the master and slave to the mounting rails ① with a security screw Align the master and slave with the mounting rails Close the top lid, and secure it with screws (Same for the Slave). ①...
- Page 14 Close the master's power supply cover. Assemble the swing arm by yourself. Refer to the diagram below for installation instructions. (Same for the Slave) ② ①...
- Page 15 Cover the master and slave with dust plugs. Dust Plugs We suggest marking a warning line on the floor to remind the user, when installation is being completed. It reminds the user to wait outside the warning line until the previous user have completed the verification process and passed through the turnstile...
-
Page 16: Wiring Diagram
5 Wiring Diagram Wiegand Wiegand Wiegand Wiegand RS485 485B 485A 485A 485B 485B 485A 485A 485B... - Page 17 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
