Components parts
Number
Parts name
1
Body
2
Bonnet
3
Plate
4
Gasket
5
Element
6
Spring
7
Diaphragm Ass'y
8
Screw
9
Tapping screw
10
3 port valve
Material
ADC
resin
resin
HNBR
resin
SUS
HNBR 、 resin
SUS
Carbon tool steel
(Chromated)
Components parts
Number
1
2
3
4
5
6
7
8
9
Components parts
Number
Parts name
1
Body
2
Bonnet
3
Guide bushing
4
Diaphragm Ass'y
5
O-ring
6
Screw
Parts name
Body
Bonnet
Diaphragm Ass'y
Spring
Snap ring
Steel ball
Screw
Brass(Electroless nickel plating)
Speed controller
Material
ADC
ADC
resin
FKM、resin
FKM
SUS
Material
ADC
ADC
FKM、resin
SUS
SUS
SUS
SUS
FKM
